  • Page 1 50J6 Receiver, RF Keyless Entry System...

  • Page 2: Table Of Contents

    Table of contents Constitution of the Radio Frequency Keyless Entry system with Door Lock Controller for vehicle ..................User’s manual (provisionally) ................Block diagram ....................Specification ....................Circuit diagram ................... Parts layout (front)..................Pattern layout ..................Parts list ...................... Connector ..........…..........Photographs ....................

  • Page 3: Constitution Of The Radio Frequency Keyless Entry System With Door Lock

    1. Constitution of the Radio Frequency Keyless Entry System with Door Lock Controller for vehicle The radio frequency keyless entry is a system that it controlls locking and unlocking the door by wireless remote controller. This system consists of two components. The TRANSMITTER is a device that transmits the signal when the button is pressed.

  • Page 4: User's Manual (Provisionally)

    2. User’s manual (provisionally) REMOTE TRANSMITTER You can lock and unlock your vehicle with the remote transmitter. LOCK When you push the LOCK button, all the doors will lock. You cannot lock any of the doors with the remote transmitter if any door is open or the key is in the ignition switch.

  • Page 5: Block Diagram

    3. Block diagram This is the block diagram concerning to the receiver. 12V (car battery) POWER SOURCE(5V) EEPROM data RECEIVING MODULE output DRIVING DOOR CIRCUIT MOTOR Figure 3.1 block diagram of the receiver - 3 -...

  • Page 6: Specification

    4. Specification 4.1 RF block Local clock frequency 325.8MHz Frequency generation Crystal resonator Modulation Single Superheterodyne ±200KHz Bandwidth Sensitivity 30dBuV 4.2 Others 50 mm× 40 mm×25 mm Dimension Weight 25 g Battery Power Source (DC 5V) Operation Voltage DC 5V, 10mA -30℃...

  • Page 7: Pcb

    5. PCB 5.1 Circuit diagram Figure 5.1 Circuit diagrams - 5 -...

  • Page 8: Parts Layout (Front)

    5.2 Parts layout Figure 5.2 Parts layout (front) - 6 -...

  • Page 9: Pattern Layout

    5.3 Pattern layout Figure 5.3 Pattern layout (front) - 7 -...
  • Page 10 igure 5.4 pattern layout (back) - 8 -...

  • Page 11: Parts List

    5.4 Parts list PART NAME MANUFACTURE TYPE SPECIFICATION REMARKS WAVE DETECTION IC INFINEON TDA5211GEG 28-PIN SAW FILTER EPSON FF-555 315.1M 315.1MHz SAW1 CERAMIC FILTER MURATA SFECV10M7JA00-R0 3-PIN CRYSTAL RIVER FCX-03-10.18125 CI=150Ω CL=SERIES OSCILLATOR -30-30 10.18125MHz+387Hz DOUBLE TRANSISTOR UPA801-T1 6-PIN MINI MOLD 2SC4226(X2) TRANSISTOR ROHM...
  • Page 12 PART NAME MANUFACTURE TYPE SPECIFICATION REMARKS TANTALUM CAPACITOR MURATA GRM31CB10J106KC01L 10uF ,6.3V C100 3216 SIZE CHIP CAPACITOR MURATA CCM-L10CH1H220J-T2 22pF 1005 SIZE CHIP INDUCTOR MURATA LQP18MN10NG00D 10nH 1608 SIZE CHIP INDUCTOR MURATA LQW18AN33NG00D 33nH LX2,LX3 1608 SIZE CHIP INDUCTOR MURATA LQP15MN33NG00D 33nH 1005 SIZE...
  • Page 13 PART NAME MANUFACTURE TYPE SPECIFICATION REMARKS CASE F-PLUS BLACK BASE F-PLUS BLACK NAME PLATE AMEMIYA NOTE: G8D-246S-B SHEET No ( 3 / 3 ) DETEAILED LISY OF PARTS DWG NO.

  • Page 14: Connector

    5.5 Connector This is the pin assignment of the connector. No. I/O Assignment Memorandum １ INPUT Battery ２ − (Not used） ３ INPUT Battery saving ４ OUTPUT SIGNAL Active Lo ５ Ground - 9 -...
