- Page 1 USER'S MANUAL GAMING CHAIR CB10172...
- Page 2 ○ ○ ○ ○ ○ ○ ○ Safety and Compliance ◆ Please wear the gloves when assembling ,avoid scratching your hands. ◆ Please take the bolts out carefully ◆ Please read the instructions completely before assembly. ◆ Remove all parts from the carton and ensure all parts are included prior to assembly.
- Page 3 Contents Make sure that the package contains the following parts ○ ○ ○ A Back cushion (1) B Seat cushion (1) C Arms (2) ○ ○ ○ D Mechanism (1) E Gas lift (1) F Star base (1) ○ ○ ○...
- Page 4 Assembly Instructions Step 1: Turn the star base upside down,then press the casters into the holes at the end of each. Steps 2:Turn the star base upright and insert the lift with cover into the center hole of the star base.(The gas lift cover has been removed when products leave the factory.)
- Page 5 Step 3: Attach the arms to the seat cushion using four (H) bolts,and two (P) bolts and two (M) plastic washers ussing the 6mm wrench (N). Step 4: Align the mechanism over the pre-drilled holes underneath the seat cushion.Make sure that the front of the mechanism is facing the front of the seat cushion.
- Page 6 Step 5: Use two (J) bolts and two (L) big washers to connect the back lift (R) to the back cushion (A),which needs to be inserted into the hole of the back lift alignment mechanism.Using two (S) small bolts to connect the steel plate cover ( Q ) to back using the 6mm wrench (N).
- Page 7 Step 6:Turn the seat cushion upright and align the center hole of the mechanism over the lift, then push the seat cushion down onto the lift firmly until the connection is secure. Caution: For your safety,before using your chair, make sure that all of the bolts are fully tightened.
- Page 8 Adjustments Adjusting the seat height ● To raise your seat, lean forward to lift your body weight from the seat,then pull down the control handle (1). ● To lower the seat, pull down the control handle (1) while you‘re seated.
- Page 9 Adjustments backrest height ● To raise the backrest,turn the handle(3) and then raise the backrest to your desired height. ● To lower the backrest, turn the handle (3) and then press the backrest down to your desired height.
- Page 10 To operate the tilt lockout ●To a certain extent,you can control your chair to tilt backward by pulling the handle upwards ●To allow your chair to tilt back freely ,flip the control handle (2) to the top. ●To prevent your chair from tilting back,flip the control handle (2) to the bottom.
-
Page 11: After Sales Service
After-Sales Service How to remove and replace office chair and seat plate. 1.Hammer the seat plate 2.Hammer the gas lift (see (see pictures) until the 5-star pictures) until the gas lift falls base falls down. down. 3.Insert the gas lift into 5-star base, 4.Finish.
