RECBOT BUILDING INSTRUCTIONS
Collect parts and tools from the lists below:
1
Materials
Screw, 8-32 x 1/4" Long
Screw, 8-32 x 1/2" Long
Screw, 8-32 x 3/8" Long
Motor Screw, Long [1/2"]
Nut, 8-32 Keps
Shaft, 3" long
Shaft, 2" long
Shaft Collar
4.6mm Plastic Spacer
Bearing, Flat
Bearing Pop Rivets
Standoff, 3" Long
Standoff, 2" Long
Standoff, 1" Long
Gear, 12 tooth
Gear, 36 tooth
Gear, 60 tooth
Chassis Rail, 16 hole
Chassis Bumper, 15 hole
C-Channel, 1x2x1x15 hole
C-Channel, 1x2x1x25 hole
Plate, 5 x 15 hole
Bar, 25 hole
Small Low Friction VEX Wheel
VEX Microcontroller*
VEX Motor w/ Clutch
7.2V Robot Battery*
Optical Shaft Encoder*
Limit Switch*
Ultrasonic Rangefinder*
Potentiometer*
RF Receiver Module*
Receiver Antenna Sleeve*
Receiver Antenna Sleeve Holder*
* Not included in Protobot Robot Kit
© Carnegie Mellon Robotics Academy / For use with VEX
Quantity
42
6
9
6
37
6
2
17
10
15
24
4
4
2
2
4
4
4
2
2
1
1
2
4
1
3
1
2
1
1
1
1
1
1
Robotics Systems
®
Tools
Zip Tie, 4" Long
Allen Wrench 3/32"
Allen Wrench 5/64"
Open End Wrench 1/4"
Pliers*
Hacksaw*
ROBOTC
Quantity
4
1
1
1
1
1
RECBOT 1.0 • 2
