D-Link DIS-100E Series Quick Installation Manual

DIS-100E Series Unmanaged
Industrial Fast Ethernet Switch
Quick Installation Guide
Overview
The DIS-100E Series Unmanaged Industrial Fast Ethernet
Switch solutions are designed for supporting standard
industrial applications without complex setup, allowing for
a truly plug-and-play network.
If the equipment is used in a manner not specified by the
manufacturer, the protection provided by the equipment
may be impaired.
Package Checklist
Please verify that the box contains the following items:
Item Quantity
Unmanaged switch 1
Wall-mount plates 2
DIN rail clip 1
M4 Screws
(for the wall mount plates & 4
DIN clip)
DC power terminal block 1
RJ-45/SFP protective cap 2-4
Quick Installation Guide 1
Safety Instructions
When a connector is removed during installation, testing,
or servicing, or when an energized fiber is broken, a risk of
ocular exposure to optical energy that may be potentially
hazardous occurs, depending on the laser output power.
The primary hazards of exposure to laser radiation from an
optical-fiber communication system are:

Damage to the eye by accidental exposure to a beam
emitted by a laser source.

Damage to the eye from viewing a connector attached
to a broken fiber or an energized fiber.
Documentation Conventions
The following conventions are used in this quick installation
guide to emphasize information that will be of interest to
the reader.
DANGER — The described activity or situation might or
will cause personal injury.
WARNING — The described activity or situation might
or will cause equipment damage.
CAUTION — The described activity or situation might or
will cause service interruption.
NOTE — The information supplements the text or
highlights important points.
Dimension Illustration
(unit: mm)
5-Port Model
8-Port Model
1
