Telnova Technology Co.,Ltd
This module is limited to OEM installation ONLY
Features
. Bluetooth V2.1+EDR specification support
. A2DPv1.2
. AVRCPv1.0
. HFPV1.5
Applications
. This module applies only to the following Bluetooth speaker:
Manufacturer : Telnova Technology Co.,Ltd
Producted name: Bluetooth Spesaker
Model name: MBT-80C
Brand name:N/A
Block Diagram
This is part circuit structure: The encoder IC BK3221(OSC26MHz), it is a single chip radio and
basedand is for Bluetooth 2.4GHz systems including enhanced data rates(EDR) to 3MBPS; The
FLASH W25080B, it is a single chip 8 megabit(1024X8-bit-/512kx16-bit) Flash memoy, CMos
3.0 Volt-only. The module Supports Bluetooth v2.1. the Frequency range: 2402-2480MHz. The
module also has necessary balun and bandpass filters to interface with a build-in PCB antenna,
which forms a very cost effective radio subsystem.
Bluetooth Module for Audio Application
F6088 Class2 Bluetooth Module
1
Advertisement
Related Manuals for Telnova F6088
Summary of Contents for Telnova F6088
- Page 1 Telnova Technology Co.,Ltd This module is limited to OEM installation ONLY Bluetooth Module for Audio Application F6088 Class2 Bluetooth Module Features . Bluetooth V2.1+EDR specification support . A2DPv1.2 . AVRCPv1.0 . HFPV1.5 Applications . This module applies only to the following Bluetooth speaker: Manufacturer : Telnova Technology Co.,Ltd...
- Page 2 Telnova Technology Co.,Ltd Physical Layout and Size...
- Page 3 Telnova Technology Co.,Ltd Pins Configurations General Electrical Specification...
-
Page 4: Radio Characteristics
Telnova Technology Co.,Ltd Radio Characteristics... -
Page 5: Installation Diagram
3 Up to five exceptions are allowed in v2.0 of the Bluetooth specification 4 Up to three exceptions are allowed in v2.0 of the Bluetooth specification 5 Measured at F0 = 2441MHz Installation diagram Module Installation location( Telnova Technology Co.,Ltd MBT-80C Bluetooth Spesaker) Module Installation location... -
Page 6: Fcc Statement
Label requirements: Contains Transmitter Module FCC ID: WY9-F6088 Host use instruction: The module must install and work with a speaker, The speaker’s manufacturer is Telnova Technology Co., Ltd.. MBT-80C The Host mode name: BLUETOOTH SPEAKER The Host Brand Name: N/A FCC RF Exposure Requirement At least 20cm separation distance between the antenna and the user’s body must be maintained at all times. - Page 7 This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. 3.A label must be affixed to the outside of the end product into which the F6088 Module is incorporated, with a statement similar to the following: For F6088: This device contains FCC ID: WY9-F6088.
- Page 8 OEM LABELING REQUIREMENTS FOR END-PRODUCT The F6088 module is labeled with its own FCC ID Certification Number. The FCC ID certification numbers are not visible when the module is installed inside another device, as such the end device into which the module is installed must display a label referring to the enclosed module.
- Page 9 FCC and Industry Canada multi-transmitter product procedures. The end product with an embedded FCC ID: WY9-F6088 Module may also need to pass the FCC Part 15 unintentional emission testing requirements and be properly authorized per FCC Part 15.
