Restorable Optical Cordless Mouse
USER'S MANUAL
Model #: MWP41-L
System Requirement
Mouse compatible with standard Microsoft OS
rd
3
button and wheel function require Win 98/ 2000/ ME/ NT/ XP
Compatible with MAC
Before you begin
Keep this installation guide for future reference! It contains Important
Troubleshooting Information.
Keep your old PS/2 mouse as a back-up device.
Getting Started
Congratulations on your purchase of an 800dpi restorable Cordless Optical
Mouse. By using the advanced RF technology a 360°operation is possible and
no line-of-sight is required between the receiver and the mouse. The 800dpi
high resolution will bring users the best operation accuracy and efficiency,
especially when the pixel of display over 1024*768 pixel. It operates at twice the
speed and only requires 1/4 of the space in comparison to a 400dpi mouse.
Battery or current consumer is always the key issue for a wireless product. In
MWP41-L, two methods designed for power saving, the patent of ID power on/
off function and receiver store switch.
MWP41-L can be power off by pressing ID button for 3 sec. There is a
switch is the reviver store. By putting the receiver into the mouse, the power can
be shout down. The way to open the top cover and store the receiver is other
unique patent showing this mouse. By these special designs you will find it is so
good to have a mouse like MWP41-L.
1
Advertisement
Table of Contents
Related Manuals for Dexin MWP41-L
Summary of Contents for Dexin MWP41-L
- Page 1 MWP41-L, two methods designed for power saving, the patent of ID power on/ off function and receiver store switch. MWP41-L can be power off by pressing ID button for 3 sec. There is a switch is the reviver store. By putting the receiver into the mouse, the power can be shout down.
- Page 2 Package Contains Your MWP41-L Mouse package includes the following: Mini cordless optical mouse Sub-thumb size receiver User’s manual CD-ROM Driver for Windows 98/2000/ME/NT/XP(Optional) 2 AAA size alkaline batteries Note：If any part is missing, please contact your dealer for a replacement immediately.
- Page 3 Hardware Installation Guide (Mouse) Step 1. Take out the receiver and Inserting the Batteries 1. Open the top cover as follow 2. A small in front of the mouse button case. Push it and open the top case. 3. Take the receiver out and put 2 AAA batteries in correct place. 4.
- Page 4 1. Plug into USB Port 2. Click (ID button) 3. Click (ID button) 4. Click the receiver’s connect button once (located on the back of the receiver) within 5 seconds after clicking the connect button on the mouse. The LED will start blinking, when the connection is established.
- Page 5 Operation Guide Power off the mouse 1. Be sure the mouse is NOT in sleep mode. If it is, press any key to wake it up. 2. Press and hold the Connect button on the bottom of the mouse for more than 2 seconds.
-
Page 6: General Specifications
GENERAL SPECIFICATIONS 800dpi hardware resolution Restorable sub-thumb size receiver. Digital Radio Frequency wireless mouse with receiver 1 channels and 256 ID selections for your options to prevent interruption 3 buttons design with scrolling wheel Ergonomic design for comfortable grip. 2 AAA batteries to operate the mouse. Electromagnetic Characteristics (EMC) This unit complies with Part 15 of FCC Rules. - Page 7 Receiver: 5V DC (powered by USB port) Operating Current Transmitter: 28 mA, operate on a white paper Receiver: 60 mA typical Standby Current 15 mA Sleep Current 150uA...
-
Page 8: Troubleshooting
Troubleshooting 1. Mouse does not function If mouse is not functional, please turn off the computer first. Check the receiver and make sure it is firmly attached to the USB port of the computer. Check the placement of batteries and see if they are properly connecting. "+"... - Page 9 “connection”. Note: Avoid using this device on a metal surface because a large surface of iron, aluminum, copper, or other metal may act like a shielding to the RF antenna of the mouse and the receiver. 3. Interference with other RF wireless mouse If the interference comes from other same model of RF wireless mice, please “Setting up connection between mouse and receiver”...
-
Page 10: Important Note
Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.
