- Page 1 STANDARD RF OPTICAL MOUSE USER’ S MANUAL Model #: MWP5016...
-
Page 2: Getting Started
Congratulations on your purchase of an RF (Radio Frequency) wireless & multimedia mouse. By using the advanced RF technology, a 360° of operation is possible, and no line-of-sight is required between the receiver and the mouse. The MWP5016 Mouse doesn't have to aim at the receiver when using. -
Page 3: Installation Guide
PC Installation Guide Step 1. Connecting the Receiver By using this MWP5016 mouse, you need to keep a free USB port for the included receiver. Please follow the steps below to finish the connecting: 1. - Page 4 Step 3. Connecting the power 1. Connect the AC plug of power adaptor into AC power outlet. 2. Connect the DC output connector of the adaptor into the female DC jack on the back of charger. 3. Then the red LED will be lighten on. Step 4.
- Page 5 Channel switch (Inside the battery cover) ID switch ID switch Channel switch Fig-3.2 Fig-3.1 GENERAL SPECIFICATIONS Digital Radio Frequency wireless mouse with receiver 2 channels and 256 ID selections for your options to prevent interruption 5 buttons design for multimedia purpose to immediately play Ergonomic design for comfortable grip Electromagnetic Characteristics (EMC) FCC ID:...
- Page 6 Distance: 3 feet typical Power: 3.7V DC (Lithium ion battery) Carrier Frequency: 27 MHz Dimensions: 98*59*38 mm Weight: 106 grams Receiver Interface: USB Power: 5V DC, 100mA MAX connected to host computer Dimensions: 63*22*17 mm (without counting the extended USB connector) Weight: 16 grams Recharger l Charging Current: 70 mA typical...
- Page 7 1. Mouse does not function If mouse is not functional, please turn off the computer first. Check the receiver and make sure it is firmly attached to the USB port of the computer. Check the placement of the battery and see if it is properly connecting. "+"...
- Page 8 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
