Summary of Contents for E-Z UP Deco
-
Page 2: Table Of Contents
® experience. To ensure your complete satisfaction, take the time to learn how to operate your Deco™ Instant Outdoor Pavilion by E-Z UP by carefully reviewing these set-up and care instructions. TABLE OF CONTENTS Intro..................Set-up Instructions..............Care and Maintenance............. -
Page 3: Set-Up Instructions
STEP 1 Place your Deco™ Instant Outdoor Pavilion by E-Z UP frame in the center of area to be shaded. With partner on opposite side, grasp outer legs, slightly lift off the ground and step backwards, stopping at full arms’... - Page 4 STEP 4 Unscrew top attachment nut from bolt. Place grommeted fabric top over the bolt, install top attachment nut and tighten until snug. Top should rotate easily - Do not over tighten. Repeat on remaining grommets. STEP 5 With partner, grasp the bottom of the diamond shaped area of trusses, on opposite sides of the shelter.
- Page 5 STEP 7 Use peak extension pole to push up center hub, extending top frame structure. Continue push up motion until all four sides snap in place. WARNING: Do not let go of center hub until at least two sides are locked. Complete top structure must be locked before using shelter.
- Page 6 STEP 10 Lift up two adjacent outer legs and slide out the inner legs until snap button locks. Repeat on opposite legs. Be sure to adjust two legs at one time to avoid frame damage. STEP 11 Outer Leg Once the shelter is fully raised to the desired height setting, secure all legs with quick release pins.
-
Page 7: Care And Maintenance
Deco™ Instant Outdoor Pavilion shelter, follow these care and maintenance instructions: The Deco™ Instant Outdoor Pavilion top clean-up is a breeze. Spot wash by sponging briskly with a soapy solution of natural soap in lukewarm water. Rinse thoroughly with clean water to remove soap and air dry. -
Page 8: Take Down Instructions
TAKE DOWN INSTRUCTION STEP 1 With partner, disengage quick release pins. Depress snap button on legs and telescope inner legs into outer legs. Repeat on other legs, making sure to do two legs at a time. STEP 2 Stand under shelter and locate center hub. - Page 9 STEP 3 Release Auto Slider ® at each corner by first lifting hem of top. With one hand, push up on truss near slider, release quick pin by pulling ring. Pull STEP 4 With one or two partners at opposite sides of shelter make sure peak beam assembly snap buttons are disengaged.
- Page 10 ACCESSORIES DELUXE STAKE KITS DELUXE WEIGHT BAGS...
- Page 11 INTERNATIONAL E-Z UP, INC., manufacturer of the Deco™ Instant Outdoor Pavilion, warrants to the original purchaser who provides a dated sales receipt from an Authorized Dealer, each part of the Deco™ Instant Outdoor Pavilion frame and top to be free from defects in material or workmanship for a period of five years after the date of original purchase.
- Page 12 INTERNATIONAL E-Z UP, INC. Worldwide Corporate Headquarters 1900 Second Street Norco, California 92860 888.474.3583 bungalowbyezup.com...
