Eurocode (Analogue) 26/04/05
EUROCODE SERIES
(ANALOGUE CONTROLLER)
OPERATOR INSTRUCTIONS
INSTALLATION DETAILS
These instructions cover the following models;
EUROCODE 150
EUROCODE 180
EUROCODE 300
Designed and manufactured by:
OPEN DATE EQUIPMENT LIMITED
UNITS 8 & 9, PUMA TRADE PARK,
Tel:
Fax: +44 (0)20 8655-4990
Email: sales@opendate.co.uk
Web site: www.opendate.co.uk
PARTS LISTING
CIRCUIT DIAGRAMS
145, MORDEN ROAD,
MITCHAM,
SURREY, CR4 4DG.
UNITED KINGDOM.
+44 (0)20 8655-4999
Advertisement
Related Manuals for Open Date Equipment EUROCODE Series
Summary of Contents for Open Date Equipment EUROCODE Series
- Page 1 CIRCUIT DIAGRAMS INSTALLATION DETAILS These instructions cover the following models; EUROCODE 150 EUROCODE 180 EUROCODE 300 Designed and manufactured by: OPEN DATE EQUIPMENT LIMITED UNITS 8 & 9, PUMA TRADE PARK, 145, MORDEN ROAD, MITCHAM, SURREY, CR4 4DG. UNITED KINGDOM. Tel:...
-
Page 2: Table Of Contents
Eurocode (Analogue) 26/04/05 Page 1 EUROCODE SERIES INDEX. Page Declaration of Conformity Safety Instructions. Operating Instructions. Electronic Control - Description. Electronic Control - Front Panel Layout. Electronic Control - Rear Panel Layout. Printhead - Magazine Removal and Fitting. Foil Threading. -
Page 3: Declaration Of Conformity
A technical construction file for this machinery is retained at the above address. Signed..........… Date……………………………. Name K.F. Wingfield. Position General Manager Being the responsible person appointed by Open Date Equipment Limited. This Declaration of Conformity complies with Regulation 22 of The Supply of Machinery (Safety) Regulations 1992. -
Page 4: Safety Instructions
Eurocode (Analogue) 26/04/05 Page 3 IMPORTANT SAFETY INSTRUCTIONS Read these instructions carefully. Follow all warnings and instructions marked on the product. Always disconnect the printhead and controller from the mains electricity and air supply before attempting to clean or service it. Never operate the printhead unless it is installed within the mounting frame supplied. -
Page 5: Operating Instructions
Eurocode (Analogue) 26/04/05 Page 4 OPERATING INSTRUCTIONS ELECTRONIC CONTROL UNIT (refer to page 6) PRINT switch Switches on the print cycle. Switch off to silence the audible alarm. POWER/HEAT Doubles as the main power switch (does not isolate the internal switch circuitry). -
Page 6: Electronic Control - Front Panel Layout
Eurocode (Analogue) 26/04/05 Page 5 ELECTRONIC CONTROL UNIT FRONT PANEL... -
Page 7: Electronic Control - Rear Panel Layout
Eurocode (Analogue) 26/04/05 Page 6 ELECTRONIC CONTROL UNIT REAR PANEL (Cables omitted for clarity) PRINT HEAD PRINT SIGNAL SUPPLY VOLTAGE SOLENOID VALVE MODEL 200000 SERIAL No L1883 VOLTS AMPS 50/60 SUPPLY VOLTAGE DETAIL EARTH TEST POINT... -
Page 8: Printhead - Magazine Removal And Fitting
Eurocode (Analogue) 26/04/05 Page 7 OPERATING INSTRUCTIONS MAGAZINE REMOVAL To remove the foil magazine, slide the catch away from the type holder access door, hold in place and withdraw the magazine using the two handles. Turn off the PRINT switch to silence the audible alarm. FOIL THREADING (refer to page 9) Fit an empty foil core onto the rewind mandrel. -
Page 9: Type Holder Removal And Replacement
Eurocode (Analogue) 26/04/05 Page 8 FOIL THREADING DIAGRAM... -
Page 10: Initial Setting
Eurocode (Analogue) 26/04/05 Page 9 INITIAL SETTING PROCEDURE Ensure that printing foil and substrate are compatible. If in doubt, contact foil supplier for assistance. Remove type holder from printhead. Ensure that rubber print base is clean, undamaged and securely retained in position under printer. -
Page 11: Print Dwell (Timer) Adjustment
Eurocode (Analogue) 26/04/05 Page 10 INITIAL SETTING PROCEDURE PRINT TIMER ADJUSTMENT (refer to page 6) • Normal setting is about 4. • Generally, the larger the print, the higher the setting. • Should the print not adhere fully to the substrate, a higher setting may be used. •... -
Page 12: Solenoid Valve Details
Eurocode (Analogue) 26/04/05 Page 11 SOLENOID VALVE ASSEMBLY BLACK PIPE RED PIPE TO PRINTER TO PRINTER SOLENOID VALVE FIXING HOLES MOUNTING LOCK NUT PLATE AIR FLOW RESTRICTOR AIR FLOW RESTRICTOR (for forward stroke) (for return stroke) SILENCERS... -
Page 13: Interconnection Details - Electrical And Pneumatic
Eurocode (Analogue) 26/04/05 Page 12 EUROCODE CONNECTION DETAILS... -
Page 14: Connection Details - Electronic Control Unit
Eurocode (Analogue) 26/04/05 Page 13 WIRING DIAGRAM – ELECTRONIC CONTROL UNIT. DRAWING NO. 9-842... -
Page 15: Block Diagram For Electronic Control Unit
Eurocode (Analogue) 26/04/05 Page 14 BLOCK DIAGRAM FOR EUROCODE & SPRINT SERIES CONTROLLER Drawing No. 9-841... -
Page 16: Trigger Signal Selection
Eurocode (Analogue) 26/04/05 Page 15 TRIGGER SIGNAL SELECTION The trigger signal which initiates the print cycle can be either a DC voltage or taken from a pair of normally open contacts. The option is selected by moving the blue jumpers at the rear of the main printer control card. When supplied, the board is configured to accept a DC print signal. -
Page 17: Temperature Chart
Eurocode (Analogue) 26/04/05 Page 16 Printhead Temperature Relative to Settings (nominal). Degrees C Temperature Control Setting... -
Page 18: Electronic
Eurocode (Analogue) 26/04/05 Page 17 ELECTRONIC FAULT FINDING FAULT POSSIBLE CAUSE No lights when control unit is switched on. No power to control unit. Fuse blown on PCB. Control panel lights, including green, are No air. illuminated but printer will not operate Fault on PCB. -
Page 19: Mechanical
Eurocode (Analogue) 26/04/05 Page 18 MECHANICAL FAULT FINDING FAULT POSSIBLE CAUSE Insufficient foil pull. Foil adjusting screw wound in too far. Pinch roller not engaged. Torsion spring on body broken. Grub screw loose in cam or lever. Drive roller damaged or dirty. Insufficient clearance between printer and print base. -
Page 20: Print Quality
Eurocode (Analogue) 26/04/05 Page 19 PRINT QUALITY DETERIORATION. Print quality deterioration can be attributed to any of the following causes; POSSIBLE CAUSE CURE Insufficient foil pull See page 19. Insufficient air pressure. Check pressure regulator setting. See that pipes are not damaged. Printer not level with print base. -
Page 21: Machine Serial No. Identification
Always quote the model and serial number when ordering spare parts. Company Logo CE mark Type of machine MODEL ROCODE 300 SERIAL NO. 123456 Serial number Open Date Equipment Ltd. Puma Trade Park, MANUFACTURED Mitcham, Surrey CR4 4DG. UK 2005 TEL: (020) 8655 4999 FAX: (020) 8655 4990 Manufacturer... -
Page 22: Recommended Spares Kit
Eurocode (Analogue) 26/04/05 Page 21 RECOMMENDED SPARES LIST Covering: EUROCODE 150 / 180 / 300 MECHANICAL STOCK REF Spring Set (Eurocode 150) SPR620216 Spring Set (Eurocode 180) SPR620215 Spring Set (Eurocode 300) SPR620217 Drive Belt (Eurocode 150) DRI110022 Drive Belt (Eurocode 180) DRI620048 Drive Belt (Eurocode 300) DRI620049... -
Page 23: Parts Lists
Eurocode (Analogue) 26/04/05 Page 22 EUROCODE PARTS LIST MECHANICAL Item numbers refer to those on the assembly drawings. When ordering spare parts please use the Stock Reference. ITEM DESCRIPTION STOCK REF NOTES Magazine plate Take-off hub assy HUB620201 Includes items 26,44,50,56,57. Rewind hub assy HUB620202 Includes items 26,42,44,50,54,55... - Page 24 Eurocode (Analogue) 26/04/05 Page 23 EUROCODE MECHANICAL PARTS LIST cont'd. ITEM DESCRIPTION STOCK REF NOTES Roller ROL620018 Grub screw M4x5 Main body Piston PIS620020 Piston/Seal assy ref. PIS620200 Bottom cap Databox packing PAC190028 Guide pin PIN620022 Washer WAS620065 Needle Bearing BEA521008 Spindle SPI620059...
- Page 25 Eurocode (Analogue) 26/04/05 Page 24 EUROCODE MECHANICAL PARTS LIST cont'd. ITEM DESCRIPTION STOCK REF NOTES Top Cylinder Bearing BEA620064 Bush BUS620035 Keep plate CAT620125 CSK screw M4x10 Thumb plate THU620127 Locking plate LOC620129 Cap screw M4x20 Spring SPR530032 Part of Spring Set. Grub screw M3x8 Plug...
-
Page 26: Eurocode 150/180 Magazine Details
Eurocode (Analogue) 26/04/05 Page 25 EUROCODE 150/180 MAGAZINE DETAILS... -
Page 27: Eurocode Body Details
Eurocode (Analogue) 26/04/05 Page 26 EUROCODE BODY DETAILS Page 7.4... -
Page 28: Eurocode 300 Magazine Details
Eurocode (Analogue) 26/04/05 Page 27 EUROCODE 300 MAGAZINE DETAILS (Iss. 5) -
Page 29: Eurocode Dimensions Datasheet
Eurocode (Analogue) 26/04/05 Page 28 EUROCODE DIMENSIONS... -
Page 30: Frame Installation Datasheet
Eurocode (Analogue) 26/04/05 Page 29 EUROCODE FRAME INSTALLATION... -
Page 31: Airborne Noise Emissions
Eurocode (Analogue) 26/04/05 Page 30 EUROCODE SERIES AIRBORNE NOISE EMISSIONS. Comprehensive tests have been carried out with the Eurocode fitted in a standard printer frame and mounted onto a typical label applicator. Measurements were taken at 1.6 metres above floor level and approximately 1 metre away from the printer in all directions. -
Page 32: Warranty
Eurocode (Analogue) 26/04/05 Page 31 OPEN DATE EQUIPMENT LTD. UNITS 8 & 9, PUMA TRADE PARK, 145 MORDEN ROAD, MITCHAM, SURREY, CR4 4DG. UNITED KINGDOM. STANDARD WARRANTY TERMS AND CONDITIONS – HOT FOIL PRINTERS Open Date printers should be installed and operated according to the instructions given in the operating manual. -
Page 33: Open Date Group Companies & Agents
Eurocode (Analogue) 26/04/05 Page 32 OPEN DATE GROUP COMPANIES FRANCE OPEN DATE FRANCE Z.I. D’Attichy No.8, Voie Industrielle 60350 Attichy. Local Tel:- 03 44 42 94 43 Local Fax:- 03 44 42 17 17 International Tel:- +33 3 44.42.94.43 International Fax:- +33 3 44.42.17.17 GERMANY OPEN DATE GmbH Mittlere Stammig 4...
