KISS REBREATHERS
SPORT KISS MANUAL
MSL 72.124 Jetsam/Sport KISS Manual R.6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sport Kiss and is the answer not in the manual?

Questions and answers

Related Manuals for KISS REBREATHERS Sport Kiss

Summary of Contents for KISS REBREATHERS Sport Kiss

  • Page 1 KISS REBREATHERS SPORT KISS MANUAL MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 2 READ THE MANUAL!!!!    IN ORDER TO FULLY UNDERSTAND YOUR NEW REBREATHER, THE COMPONENTS, HOW  THEY WORK, HOW TO HANDLE AND TREAT THEM, YOU MUST READ THE MANUAL IN  FULL, FOR YOUR REBREATHER.      SPORT KISS OWNERS SHOULD READ THE SPORT KISS MANUAL.  CLASSIC KISS OWN- ERS SHOULD READ THE CLASSIC KISS MANUAL.  EXPLORER OWNERS SHOULD READ  BOTH THE EXPLORER AND CLASSIC MANUALS.  CLASSIC OWNERS WHO HAVE UP- GRADED TO SOME OF THE EXPLORER COMPONENTS SHOULD READ BOTH THE CLAS- SIC AND EXPLORER MANUALS.      THIS SHOULD BE DONE PRIOR TO DIVING OR SERVICING THIS UNIT!!!  SPECIAL AT- TENTION SHOULD BE PAID TO ALL NOTES &/OR WARNINGS; THEY MUST BE READ  AND UNDERSTOOD!!!! FAILURE TO DO SO, MAY CAUSE SERIOUS INJURY OR DEATH!!!!      YOU MUST BE A LEGAL ADULT IN THE AREA IN WHICH YOU LIVE  IN ORDER TO PURCHASE AND DIVE A KISS REBREATHER.        As with all scuba diving equipment, your KISS rebreather components should be ser- viced annually by a trained technician.  For those diving frequently, servicing may be  required more often.    ALL INFORMATION IN THIS MANUAL IS SUBJECT TO CHANGE.      PLEASE VISIT OUR WEBSITE, www.kissrebreathers.com/manuals.html,   FOR UPDATED MANUALS  MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 3   The  diver  must  complete  a  proper  training  course  covering  the  mainte- nance, testing and operation of the rebreather before diving this equipment.  The re- breather  can  malfunction  while  diving  even  when  properly  assembled  and  having  passed all pre-dive tests. Only carrying adequate bailout gas and having the training  and  skills  necessary  to  utilize  the  bailout  system  can  reduce,  but  never  eliminate,  the risk of equipment failure.  MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 4 MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 5: Table Of Contents

    KISS Minimum Training Standards Page 83 Scrubber Duration Page 86 Warranty Page 87 O-ring List Page 88 The photographs in this manual were taken by Doug Ebersole, Curt Bowen, Alan Studley and Kim Mikusch MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 6: Information

    And when you take a piece of equipment into water, especially salt water, that could happen sooner rather than later. Due to this, we have built the KISS rebreathers to have the least amount of components possible and to make the components that we use durable and easily repairable if required.
  • Page 7 With the KISS rebreathers, you know that you should have both a good positive and negative test. If you don’t, there is a leak. If you aren’t sure if the test is good, then you probably have a small leak. Testing is easy to do, as both the lungs and loop hoses are accessible and are the key components which need to be watched while testing.
  • Page 8 Please see the back of the manual for more information on absorbent and run times. Absorbent can easily be obtained at most dive resorts and is easy to pack for travel, should the need arise. The Sport KISS has a bi-axial flow design.
  • Page 9 The Sport KISS is very small and light weight and will also take divers past regular recreational limits.

  • Page 10: Specifications

    • The Sport KISS is a closed circuit rebreather designed for recreational sport diving. It is not recommended for diving deeper than 165 feet (50 meters), cave diving or wreck penetrations. For those diving to the 50 meter limit, proper training, outside the basic KISS rebreather course is required.

  • Page 11: Parts List

    Most divers have pressure gauges which can be used. This is also true for the wing and back plate assembly. Additional LP and HP swivels. EXTRAS:  We are happy to supply you with more LP swivel elbows, HP swivel elbows, off-board gas accessory. MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 12: Schematic

    Schematic  Illustration By Curt Bowen, Advanced Diver Magazine www.advanceddivermagazine.com MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 13: Components

    L. Diluent Tank and First Stage C. Ballast D. Breathing Hoses E. Rings and Hose Clamps F. Hose Attachment, ADV & Exhaust G. Hose Attachment, Sensor Housing H. Scrubber Canister I. Counterlungs J. Manual Add Valve MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 14 MOTHER AND DAUGHTER MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 15: Assembly

    Assembly      After verifying that you have all the necessary parts to assemble your new Sport KISS CCR, you are ready to put the pieces together. Start with the counterlungs and scrubber canister. First, ensure that the o-ring surface on the counter-...
  • Page 16 When attached correctly, the stainless steel T-connector swivel should be on the BCD side of the counterlung case, facing the divers back. Next, attach the other hose attachment in the same manner.   *WARNING: When attaching the hose attachments, ensure  that they are inserted straight and that the base of the at- tachment is flush with the mating piece on the scrubber can- ister.  The photo on the right shows the incorrect way!!    *NOTE: Any damage to the exhaust valve, or any debris  caught in this valve may cause a malfunction &/or leak.  Care  should be taken when servicing the valve.     *NOTE: Care should be taken so the bottom screens of the display & exhaust pods are not  damaged.  If the screens come off, the absorbent will be loose and can travel up the loop hose  to the mouthpiece!    MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 17: Ballast And Loop Hoses

    There is one tether on each side of the case. (This is the most current tether system for the Sport KISS rebreather). The benefit of this current tether system is that the parts are readily available worldwide. Should you lose a component, replace- ment should be fairly easy.
  • Page 18 Finally to attach the breathing hoses to the DSV, push the hose stubs onto the DSV adapters, push down and turn right. Repeat to attach the other hose ends to the hose attachment pods.   MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 19: Automatic Diluent Valve (Adv)

    Another way to add gas to the loop via the mouthpiece is to close the loop only a 1/4 inch, for a second. You may need to lightly push the purge button on the front of the 2nd stage. A small amount of gas will blow directly into the breathing loop. MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 20 ADV housing. The LP hose should run under the display cables. Ensure that there are no entan- glements. The DSV regu- lator hose should be at- tached to the outside of the T-connector. MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 21 To attach the BCD lay the unit down, front side up. The BCD should be positioned so that it sits as low as possible. The higher the Sport KISS sits on the divers back, the better the work of breathing will be.

  • Page 22: Changing The Scrubber

    Changing the scrubber on the Sport KISS is quick and easy and takes just minutes. To start, unclip the two quick link tethers and remove the rubber LP hose which is connected to the inside of the T-connector swivel. The quick link/split ring tethers keep the pods from spinning and also hold the scrubber canister in place.
  • Page 23 Attach the scrubber canister caps onto the top of the scrubber. Lift the scrubber canister out of the counterlung case and remove the counterlungs. The lungs are removed by rotating them 1/4 turn counter-clockwise. MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 24: Counterlungs

    Remember to push them on straight and ensure that the o-ring is not pinched. COUNTERLUNGS:  The Sport KISS uses two back mounted counterlungs that are available in two sizes; small and medium. A combi- nation of these will normally provide a good match between the counterlung volume and the divers tidal volume.
  • Page 25 BCD. Once the canister has been replaced in the counterlung case and is secure, it is ready to be filled. Start by pouring scrubber into both sides of the canister. MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 26 When the canister has been properly filled, the scrubber material should be level with the bot- tom of the black retainers. *WARNING: It is important that the can- ister is filled to the correct level, follow- ing the above procedures.  Over filling  the canister will increase the work of  breathing and can actually cause CO2  symptoms by restricting the off gassing  of CO2 within the divers lungs.   Care  should also be taken to ensure that the  canister does not incur any damage.   Damage to a sealing area could cause  water to enter, rendering the absorbent  useless.   MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 27 This will ensure a good seal and will make re-attachment easier. Lightly lubricate the o-ring on the hose attachments and the inside surface of the scrubber canister. MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 28 Once the hose attachments are back in place, re-attach the quick link safety tethers and the rubber LP hose.   *WARNING: CARE SHOULD BE TAKEN TO ENSURE THAT THE DISPLAY AND EXHAUST PODS ARE IN GOOD  WORKING ORDER AND NOT DAMAGED.  DAMAGED COMPONENTS MAY CAUSE THE SPORT KISS TO NOT FUNC- TION PROPERLY WHICH COULD RESULT IN INJURY OR DEATH!!!    *WARNING: IT SHOULD BE NOTED THAT ALL COMPONTENTS OF THE SPORT KISS SHOULD BE HANDLED WITH  CARE.  ABUSE OR DAMAGE TO ANY COMPONETS COULD CAUSE THEM TO NOT WORK PROPERLY. THIS COULD  LEAD TO INJURY OR DEATH!!!    MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 29: Positive/Negative Testing

    If you have any uncertain feeling, then you may have a small leak. The exhaust valve should be fully closed while doing these tests. *WARNING - It is important to not leave the vacuum in the loop for more than a minute as this will cause the  ADV diaphragm to stretch and get baggy.  If this happens, the ADV will not work properly.  It will either stop  working altogether or will continuously feed you diluent.      *NOTE: When doing your test, it is VERY important to not suck so hard that you are damaging the dia- phragms.  When you do the negative  test, suck until you get a good seal, and then immediately close off the  BOV. if you suck so hard that you feel the pressure building in the back of your throat/neck area, your ears  pop, or you feel your face turning red for exertion, this is way too hard.  There is no need for this and it will  damage the valves and diaphragms.  Suck just until you feel that pressure, then close the valve.      Our new BOV has a larger bore and much better work of breathing, then the older DSV.  In order to get that  good work of breathing, the valves are more flexible. This means that with this new product, we need to en- sure that we have good testing habits.  Those divers who learned the testing procedures years ago, have to  understand that the equipment has now changed, and that our habits must also change.      Also ensure that the area where the valve seals is clean.  build up in this area will cause the diaphragm to  leak.   MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 30: Counterlung Adjustment Plate Positioning

    To correct this, exhale some of the gas out of your nose. *NOTE: The closer you can match the counterlung volume with your own, the better the work  of breathing will be.  If you have the sizing flap set to far out and the lungs are too large, the  work of breathing will be very difficult.  This could cause injury or death!        MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 31: Sensor Pod-Assembly & Calibration

      In the past, the Sport KISS was shipped using the Teledyne K1D sensors. For those still using these sensors or equivalent, please see below for use and installation. It is best to open the bags and let them sit for at least 24 hours prior to calibration as they need to go through a “wake up”...
  • Page 32 To turn the displays on, rotate the dial on the back, clockwise. Push the sensor pod and the end cap with the molex plugs together. Note that the rib on the sensor pod, A, con- nects with the slot on the end cap, B. MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 33 Ensure that the wires are not pinched. While holding the two together, screw the tiny nut back into place and hand tighten. (the tiny nut is not used on the larger sensor assembly) MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 34: Larger Sensors

    LARGER SENSORS: The Sport KISS now ships only with the larger sensor housing. The AI PSR-11-39-MD sensors are recommended. The unit is not shipped with sensors; you will need to order them from your local sensor supplier. Prior to install- ing them, it is best to open the bags and let them sit for at least 24 hours prior to calibration as they need to go through a “wake up”...
  • Page 35 Follow this procedure until the screws are snug. THE SCREWS SHOULD BE SECURED PROPERLY, BUT NOT OVER TIGHT- ENED!!! *NOTE: Ensure that the O-rings are in good condition, that the  area is clean and the components are not damaged.    *WARNING: If the wires are pinched, the pod will not be water  tight.  Water damage in this area will ruin the sensors and/or  the electronics.  If the wires do get pinched, inspect them for  damage!!  MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 36 The flat edge of the sensor assembly needs to be positioned at the bottom side of the pod. Once pushed together, attach the sensor knob to the opposite side and secure. Ensure that the knob is tight! The O-ring should be lubricated. MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 37: Fischer Plate

    VRx “C57A” CABLE, PENDENT USE The Sport KISS rebreather has a Single Fischer plate. If the VRx is used with this plate, the C57A cable must be used. Please note that VR makes several cables. Be certain that you are using the correct one! *WARNING:  OTHER CABLES MAY GIVE YOU AN INCORRECT READING WHICH COULD CAUSE SE-...

  • Page 38: Calibration Jetsam Display

    Once in this position, a small port will open to allow access to the meter. Insert the jewellers screwdriver into the port and gently turn the screw to adjust the reading.     *WARNING: When inserting the screwdriver into the port to adjust the meter, DO NOT PUSH  THE SCREW DRIVER INTO THE METER WITH FORCE.  GENTLY PLACE THE TIP OF THE SCREW- DRIVER INTO THE ADJUSTMENT SCREW ON THE METER.    MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 39 *WARNING: The PPO2 display cases have internal magnets.  Divers should not wear a compass  on the same wrist or near the displays as the magnets will cause the compass to read incor- rectly.      *SERVICE: Note that the display backs are disposable and are  not meant to be serviced.   The KISS rebreather should be flushed with oxygen on every dive to ensure that the displays are reading correctly, and re-calibrated every time the ab- sorbent is changed. MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 40 To change the batteries, remove the four outer screws on the back of the display case and carefully remove the cover. After changing the battery and logging the date, ensure that the o-ring is LIGHTLY lubricated and clean prior to replacing the cover. MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 41: Replacing Batteries, Meters, Circuit Boards

    It will be snug. If you like, you can use a tool such as a dental pick to assist you or one of the small jewellers screw drivers from your tool kit. HOWEVER, be very careful that you do not damage the circuit board!! Replace the battery, meter or circuit board, as required. MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 42 Then tighten the screws until the back is secure and seated properly. While it is important that the screws are tight enough, it is also important that they are not over tightened. Remember, the O-ring creates the seal. MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 43: Replacing A Single Display Case

    If you tap on any other part of the case, use too much force or twist it, you can dam- age the case which could cause breakage at a later date. MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 44     WRONG!!                      WRONG!!    *NOTE: Only tap the cases by the puzzle pieces, as per above instructions.  If you tap the cases  on the outer edges, as shown in the two above photos, you will stress the plastic.  This will  cause breakage.    Following the directions on page 42, insert the circuit board assembly into the case, reattach the wire to the board, insert the O-ring and seal the case. MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 45: Replacing The Wire

    To remove the wire from either the Classic KISS sensor plate or the Sport KISS three hose connector, you will need to remove the white molex connector.

  • Page 46: Display Troubleshooting

    When sea water comes in contact with electronics, even if it is just a small amount it is difficult to determine where and how bad the damage is. It could even be in the wire. When in doubt, change the wire, cir- cuit board and meter. MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 47: Sensors

    Electrolyte, which is a gel like substance is inside the sensors. If you notice this substance leaking out of the sen- sors, do not touch it as it is caustic. Do not dive with a leaking sensor. The readings will be high!!!! MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 48: Information Vr Triple Pendent Display

    4 minutes to conserve the battery. Note that the red LED light will turn on for a moment, just as the display is about to turn off. This is normal. WARNING:  WHEN THE LOW BATTERY INDICATOR LIGHT COMES ON, THE BATTERY MUST BE  CHANGED!!!! DIVING WITH A LOW BATTERY WILL AFFECT THE PPO2 READINGS!  THIS CAN  CAUSE INJURY OR DEATH!! MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 49: Calibration Vr Triple Pendent Display

    The KISS rebreather should be flushed with oxygen on every dive to ensure that the displays are reading correctly, and re-calibrated every time the absorbent is changed. MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 50: Vrx Programming & Calibration

    JETSAM DUAL DISPLAY AND VR CABLE: this cable will read one sensor only. It will work on a VR2, VR3, and the C53 version of the VRx. ONE SENSOR ONLY. VRx, C54 COMPUTER WITH THE “SINGLE FISCHER” PLATE: With the single fischer plate, the “C57A” cable must be used. ONE OR THREE SENSOR USE. MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 51 4. Then do a long press on both buttons. 5. Do another long press on both buttons and you will see the screen change to “Flush” 6. Completely flush the loop with oxygen. The steps for this are as follows: MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 52 These instructions are here to provide you with some quick notes on how the VRx computer works. This is not a complete list of the VRx instructions. Prior to diving this computer, the VRx manufac- turer’s instruction manual must be read in full. THESE INSTRUCTIONS ARE SUBJECT TO CHANGE!! MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 53: Vr3 Programming

    VR3 PROGRAMING  The VR3 dive computers from VR Technology Ltd. are compatible with the KISS rebreathers. They can be dove either independently or with a live link. These computers offer recreational and technical KISS divers an alterna- tive way to monitor PPO2 and decompression.
  • Page 54 This procedure will switch your VR3 from running independently to live. To do this, a special PIN will need to be purchased from the manufacturer in order to open this feature on your dive computer. You will also need to change your Jetsam triple display for a Jetsam dual display with a VR cable. MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 55 PPO2 in BAR (adjusted automatically for ambient atmospheric pressure), and a PPO2 bar graph. 13. One long push on both buttons. This will take you into “CAL” or calibration mode. You will see the instruction, “FLUSH CAL GAS” on your screen. MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 56 Operation: While diving, the “Xo2” can be turned on and off. To do this, do a quick push on the right button. This will take you to the “DVo” screen where you can select “Xo2” on or off. With the “Xo2” turned off, your decom- pression will be calculated using the internal set point. MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 57: Tank Mounting Brackets

    Push against the side of the push tab, where the arrow indicates. If you try and snap the lever into position any other way, the channel edges may break! MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 58: Manual Add Valve/Metering Orifice

    Do not scratch the O-ring grooves. The orifice does not need to be removed unless it is damaged or plugged. The parts in the valve are: A. snap ring; B. nut; C. spring; D. spool & orifice; E. valve body MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 59   The KISS rebreathers are mechanically controlled. The oxygen manual add valve houses a orifice which allows oxy- gen to flow into the loop at all times. In the event that more oxygen is required, the button on this valve will need to be pushed.

  • Page 60: Adjusting The Oxygen Flow Rate

    TINGS FROM THE MANUAL ADD VALVE!!! ONE MUST BE USED TO ENSURE THAT THE FITTING ON THE VALVE DOES NOT SPIN!! SEE THE PHOTOS AT THE TOP OF PAGE 59 (THE PREVIOUS PAGE) WHICH SHOW HOW TO DO THIS PROPERLY. MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 61 The metering orifice flow rate will decrease as the depth (ambient pressure) increases. The amount it decreases depends on the upstream pressure (regulator pressure setting) versus the downstream pressure (depth). This is not a fault, it is physics. MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 62: Manual Add Valve Trouble Shooting

    If the pressure is inconsistent the high pressure seat or diaphragm may be damaged. The regulator should be serviced regularly and maintained in an oxygen clean condition.     *WARNING:  It is very important that this valve is in good working order, with proper flow rates  and good O-rings.  Ensure that you rinse your gear after diving in salt water, and if you flood  your rebreather, and you think water has gotten into the valve, service it!!  If you pay attention  to how often you usually add oxygen to your rebreather during a typical dive, it will be easier  for you to notice a problem.   MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 63: Exhaust Valve, Adv, Work Of Breathing

    Then as you lift the tab, push on the top of the valve while continuing to turn it counter clock wise. Be very careful to not break the tab!! If you do, the entire valve is garbage. MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 64 Then, unscrew the valve; ensure that   it stops turning when it reaches the tab. Your valve is now ready to be replaced on your Sport KISS. ADV problem.   If your counterlung volume is correct and the exhaust valve is in good working order, and you still have a leaking exhaust with the feeling of too much gas in the loop, you could have a problem with your ADV adding too much gas into the system.
  • Page 65 Again, this is a case where over tightening can cause a leak. On the other hand, if the button assembly is loose, air can leak through this area. *NOTE: Severely over tightening the ADV diaphragm screws can damage the threads on the ADV  housing!!  MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 66 The unit should sit as high on your back as possible with the diver still able to reach the tank valves. Also, the unit must be tight to the divers back. It should not move up/down or side ways at all. It needs to be completely tight. This is especially true with the Sport KISS. What is your position in the water?  ...

  • Page 67: Mouthpiece Disassembly (Old)

    First, remove the monofilament by lifting it with a sharp dental pick and then pulling it out of the groove with a pair of pointed pliers or forceps. This will release the hose sleeve retainers. Once the monofilament is removed, pull the hose retainers out of the body and shake the valve plates loose. MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 68 The second stage can now be re- moved. Once the regulator has been removed, remove the two screws on the spool guide and the four screws on the se- lector knob. MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 69 Pull the knob out of the body. Once the knob has been removed, pull the spool guide and spool out of the body as well. MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 70: Mouthpiece Parts List (Old)

    Mouthpiece Parts List  A: Monofilament B: Body C: Exhaust Valve Plate D: Inlet Valve Plate E: Hose Sleeve F: Regulator Attachment Plate G: Regulator H: Spool I: Spool Guide J: Selector Knob and Selector Knob Plate MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 71: Mouthpiece Reassembly (Old)

    Place the nub end of the plate in first, and then using your thumbs, push the plate into place. It will snap in. Insert the pin which holds the plastic plate in place. * WARNING: Those using the Mares Prestige second stage, must use the bottom screw to as- sist in securing it to the DSV!!!  MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 72: Mouthpiece Disassembly (New)

    Next, the switch will need to be removed. Remove the screw which holds the switch in place; pull the switch off. Unscrew the front cover. MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 73 BE REPLACED!!! When attaching (or removing) the mushroom valves BE CAREFUL!!! PULL ON THE STEM GENTLY & ONLY HOLD THE STEM WHEN REMOVING THE VALVE. To remove the second stage regulator, remove the metal U-clip and pull the adapter loose. MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 74: Mouthpiece Parts List (New)

    IN YOUR MOUTH THE GAS FLOW IS FROM LEFT TO RIGHT. SUCK IN AND THE LEFT SIDE VALVE OPENS AND EX- HALE AND THE RIGHT SIDE VALVE OPENS. DO NOT POSITION THE MUSHROOM VALVES IN ANY OTHER DIRECTION!!!! MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 75: Mouthpiece Reassembly (New)

    Push the adapter into position and secure with the metal U-clip. Be gentle while pushing in the U-clip and push it in straight. It must be inserted fully to secure the adapter. If the clip is bent, it will be difficult to insert it properly. MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 76: Mouthpiece Test

    These tests will determine if the rubber mouthpiece has a leak or if the 2nd stage regulator a fault. The 2nd stage adapter O-ring could also be causing a leak. CLEAN AND INSPECT THE MOUTHPIECE AND SECOND STAGE AS REQUIRED. SERVICING OF THE SECOND STAGE SHOULD BE DONE BY A QUALIFIED SERVICE TECH. MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 77: Mouthpiece Servicing & Troubleshooting

    If after all that you still have a bubbling 2nd second stage the problem could be with the seat, inhale diaphragm, exhale diaphragm or it could be debris. Your local dive shop should be able to service the 2nd stage for you. *NOTE: When doing your negative pressure test, it is possible to damage the exhaust dia- phragm in the second stage.  If your inhalation is extremely hard, for an extended period of  time, this can happen.   Also, on the new BOV, the 2nd stage exhaust diaphragm can be dis- torted if the negative is too hard causing the test to fail.    MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 78 Also check for a tear underneath the zip tie which holds the rubber mouth bit in place. Damage here will also cause water to leak into the system. Many cases of water into the loop come from torn or damaged rubber mouth pieces. Loose lips. IT SHOULD BE NOTED THAT A LEAK ON THE MOUTHPIECE, INCLUDING THE RUBBER MOUTH BIT,  WILL NOT BE DETECTED ON THE POSTIVE AND NEGATIVE TESTS!!  THIS IS WHY IT IS VERY IM- PORTANT TO KEEP YOUR MOUTHPIECE PROPERLY SERVICED AND CLEANED.  ALSO, ALWAYS  CARRY A SPARE RUBBER MOUTHBIT.  MOST MOUTHPIECE LEAKS ARE FROM THIS!! MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 79: Pre-Dive Checklist's

    The bottom line is that this 5 minute pre-breath confirms your system check has been done and that all is working. DIVERS SHOULD FOLLOW THE PREDIVE CHECKLISTS BEFORE EVERY DIVE AND KEEP A COPY OF THE CHECKLIST WITH THE KISS REBREATHER AT ALL TIMES. MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 80 ____ My PPO2 display uses ________ batteries and they have ________ hours left on them.    ____ I have analyzed my O2 cylinder and it has ________% O2    ____ I am diving with _______________ diluent in my on-board diluent cylinder.  I have analyzed it    and have confirmed what percentage of O2/Helium/Nitrogen it contains.    ____ I am diving with _______________ mix in my first off-board cylinder.  I have analyzed it and    have confirmed what percentage of O2/Helium/Nitrogen it contains.     ____ I am diving with _______________ mix in my second off-board cylinder.  I have analyzed it    and have confirmed what percentage of O2/Helium/Nitrogen it contains.      ____ If I am using more off-board cylinders I will also write down the mixture and ensure that I have              analyzed them and have confirmed what percentage of O2/Helium/Nitrogen they contain.    ____ My absorbent has been used for ________ hours, which means that I have ________ hours    left on it.    ____ My dive computer is in perfect working order.    ____ The battery voltage on my computer is ________.    ____ My buddy and I have practiced bailout procedures and understand what to do in an emergency.    ____ My surface interval before this dive is ________.    ____ My CNS before this dive is ________.    ____ I am using ________ lb/kg of weight.  MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 81 I enter the water. ____ Once in the water, I will do a bubble check with my buddy to double check that there are no leaks in my system. The diluent tank  is NOT an adequate gas supply for emergency situations.   MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 82: Training & Basic Skills

    • DILUENT FLUSH - Required when the diver needs to verify that the displays are reading correctly or to bring the PPO2 to a safe level • HYPERCAPNIA - High CO2 • DILUENT LOSS MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 83: Kiss Minimum Training Standards

    Students must write a written exam and achieve a passing grade of 80% or higher. • Only approved training agencies may teach a KISS rebreathers course. CCR CROSS OVER INFORMATION  A diver who is certified by a KISS approved training agency on an approved closed circuit rebreather must meet all of the KISS training standards.
  • Page 84 Diver must use the Jetsam manuals and checklist to assemble their unit and carry out assembly checks. CORRECT SCRUBBER PACKING PROCEDURES    LOOP VOLUME  • Diver must know how to determine the correct counterlung sizes required and know how to attain minimum loop volume. ASSEMBLY & PRE-DIVE CHECKLISTS MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 85 Hypercapnia ◊ Diluent gas loss ◊ Oxygen gas loss ◊ Sensor(s) failure ◊ Dive computer failure ◊ PPO2 display failure ◊ Water in loop • SCR mode • Post-dive cleaning of unit and briefing. MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 86: Scrubber Duration

    Sport Scrubber Duration  The duration of the Sport KISS scrubber canister is based on independent testing done at the ANSTI test facilities in the United Kingdom. Multiple tests were conducted, including testing to the CE standard of EN14143. The first test was done in accordance with EN14143. The parameters for this standard are depth of 40 m (131 ft), water temperature of 4°...

  • Page 87: Warranty

    USA. Note that if you ship via a courier such as UPS or Federal Express, there will be a brokerage fee, even if there are no duties. While there may be no charges for the warranty work, this brokerage fee must be paid for by the shipper. MSL 72.124 Jetsam/Sport KISS Manual R.6...

  • Page 88: O-Ring List

    30 x 3 mm INNER BARREL SIDE PORT X 2 46 x 2.5 mm INNER BARREL END PORT X 2 45 x 3 mm HOSE ATTACHMENT X 4 28 x 2.5 mm 2ND STAGE ADAPTER X 1 MSL 72.124 Jetsam/Sport KISS Manual R.6...
  • Page 90 KISS REBREATHER, LLC. www.kissrebreathers.com info@kissrebreathers.com 1 (479) 739-7726 Skype: kissccr MSL 72.124 Jetsam/Sport KISS Manual R.6...
