CAR MULTIMEDIA SYSTEM
USER'S MANUAL
FCC ID : TQ8-ADB10F6GG

Advertisement

Table of Contents
loading

Related Manuals for Kia ADB10F6GG

Summary of Contents for Kia ADB10F6GG

  • Page 1 CAR MULTIMEDIA SYSTEM USER'S MANUAL FCC ID : TQ8-ADB10F6GG...
  • Page 2 Read the following safety precautions Notations used within this User's Manual for your safety WARNING Before using the product, read the contents of this user's manual • Failure to observe the instructions within this category could result in death carefully and use this product safely. or serious injury or damage to the vehicle.
  • Page 3 ® The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Kia is under license. Other trademarks and trade names are those of their respective owners. ® A Bluetooth Wireless Technology enabled cell phone is required to use ®...
  • Page 4 Basic part.1 Warnings and Cautions Key Product Features Component Names and Functions Starting the System for the First Time...

  • Page 5: Safety Warnings

    Basic Safety Warnings • Please refrain from use if the screen • Some functions other than the one is blank or no sound can be heard as mentioned above cannot be used while • Do not stare at the screen while driving. these signs may indicate product mal- driving.

  • Page 6: Safety Cautions

    Safety Cautions • Pay attention to the volume setting when • Do not subject the device to severe turning the device on. A sudden output shock or impact. Direct pressure onto Pay attention to traffic conditions while of extreme volume upon turning the the front side of the monitor may cause driving.

  • Page 7: Key Product Features

    Key Product Features ® Bluetooth Wireless Technology ® • Convenient use of Bluetooth Handsfree by using buttons within the steering wheel control This device is a Multimedia system equipped with a multifunc- Digital Screen Control Features • Easy control of features through touch screen tional player that supports Radio (FM, AM), USB, iPod, AUX and Miscellaneous options...

  • Page 8: Component Names And Functions

    Component Names and Functions Name Description HOME Displays the HOME screen. Head Unit PHONE Displays the Bluetooth phone mode. Name Description Displays the function set by the user. Converts to FM/AM mode SETUP Moves to the Setup screen. • Each time the key is pressed, the mode is RADIO changed in the following order: FM1 →...

  • Page 9: Steering Wheel Control

    Steering Wheel Control Name Description When pressed quickly. (less than 0.8 seconds) Name Description • When pressed in the dial screen, makes a call For more details, refer to Phone Projection guide. • When pressed in the incoming call screen, answers the call •...

  • Page 10: Starting The System For The First Time

    Starting the System for NOTICE System Reset • Cannot operate the system while it is the First Time booting up. It may take some time for all of The System Reset function restores the features of the system. system when it is not operating correctly. Turning the System On/Off Press and hold the RESET key for a sec- Press the engine start button or set the...

  • Page 11: Battery Warning Message

    Battery Warning Message Restrictions on Features for Safety Measures Always use the system while the car engine is running. If you turn on the sys- Several features are limited while driving. tem while the engine is off, a battery warn- The restriction screen will disappear when ing message will appear.

  • Page 12: Home Screen

    Home Screen Information Display on the Status Bar Controls Menu Confi guration for the Home Screen Displays the date and time, along with the system status shown by Tap the icon on any screen to display the Home Screen below. the various icons to the right of the clock.

  • Page 13: On-Screen Touch Controls

    On-Screen Touch Controls Adding a Feature to My Menu Drag & Drop Select on the Home Screen to Learn how to touch the screen to operate Select a menu or item you want, then drag My Menu add the most frequently used menus, the system.
  • Page 14 Flick (Quick Scrolling) Press and Hold Pressing the buttons in the music player will fast forward/rewind the music. Quickly moves up and down in the list. NOTICE • Moving the list when there are many items will display a handler on the right of the display.
  • Page 15 MEMO...
  • Page 16 Radio/Media part.2 FM/AM iPod ® Bluetooth Audio...

  • Page 17: Fm/Am Mode Display Controls

    Radio/Media FM/AM Features Description Mode Display Displays the current operating mode. • The stored preset frequencies are displayed You can access the radio player either by pressing the RADIO for user selection. key or by selecting the Radio menu from All Menus on the Home •...
  • Page 18 Features Description • Pressing this button briefly (less than 0.8 sec- onds): Seeks the previous/next frequency. • Pressing and holding this button (for more SEEK/TRACK than 0.8 seconds): Moves quickly through all of the frequencies. The moment that you release the button, the system seeks the next available frequency.

  • Page 19: Before Playing A Usb Mp3

    • Some USB devices may not be supported due to compatibility issues. Before Playing a USB MP3 • Take caution so that the USB connector does not come in con- tact with body parts or objects. Connect the USB device after turning on the engine. The USB •...
  • Page 20 • The device may not operate normally if MP3 Players, cellu- lar phones, digital cameras, or other electronic devices (USB devices not recognized as portable disk drives) are connected Plug Type Connector with the device. • Charging through the USB may not work for some mobile Product Name Manufacturer devices.
  • Page 21 Supported USB MP3 music specifi cations Name Description MP3 File Specification: MPEG1 AUDIO LAYER 3 Specification Acceptable sampling frequency: 32, 44.1, 48 (kHz) Recommended Bit Rates and Acceptable bit rate: 32, 40, 48, 56, 64, 80, 96, 112, Sampling 128, 160, 192, 224, 256, 320 (Kbps) Frequency 96, 128, 192 Kbps fixed bit rate/44.1kHz Supports ID3v1.0 and ID3v1.1, ID3v2.2, ID3v2.3,...

  • Page 22: Usb Music Mode Display Controls

    USB Music Mode Display Controls Features Description If button is pressed (less than 0.8 seconds): Moves to the previous file or play the current file from the beginning (Depends on the play time) • If play time is less than 3 seconds, moves to Previous File previous file •...
  • Page 23 Features Description • Delete Current File: A selected file can be deleted. Deleted file can be found in the to_ Delete folder. This function is only suppored when USB for- Menu mat is compatable with FAT16 or FAT32. • Sound Settings: Moves to the Sound Settings screen.
  • Page 24 Features Description Folder/ Category Displays folder/category name in the list Name Current Song Displays current playing file name Back Button Converts to basic mode screen Upper Folder/ Moves to Upper Folder Category Now Playing: When moving to a different list screen, moves to the list page where the cur- Menu rent file is located (Becomes disabled when the...

  • Page 25: Using Ipod Devices

    iPod • If repeatedly connect and disconnect • To listen to the iPod sound, reconnect iPod/iPhone to the Multimedia system the USB cable or change the audio out- Using iPod Devices with USB cable in short time, it may put settings in iPod/iPhone to Dock. •...
  • Page 26 • When connecting to iPod Nano/Classic, • The screen of multimedia system can the Kia Motor logo appears on the Apple be different when you run other music device. For the iPod Nano 6 genera- players (e.g.
  • Page 27 Caution • If you control pause, repeat, shuffle, or • We recommend that your Apple device seek songs when the play time is when uses the latest firmware since some • While using a connected iPhone/iPod the play time is less than 3s before fin- problems may occur due to an outdated Touch device, it may not operate nor- ished playing, it may occur difference of...
  • Page 28 Caution • If connect to the Multimedia system while podcast or iTunes music down- • If the iPhone/iPod Touch supports loading to iPod/iPhone, it may occur Bluetooth, it is unable to use Bluetooth some problems when you select song Audio if the Apple device that is con- in the list.

  • Page 29: Ipod Mode Display Controls

    iPod Mode Display Controls Features Description If button is pressed (less than 0.8 seconds): Moves to the previous file or play the current file from the beginning (Depends on the play time) • If play time is less than 3 seconds, moves to Previous File previous file •...
  • Page 30 Features Description TUNE knob to search a desired Turn the track. If the desired track is displayed, press the TUNE knob to play the track. TUNE TUNE knob If you do not anything with the for 5 seconds of searching tracks, the track info for the current track is restored.
  • Page 31 Features Description Category Name Displays the category name Displays the contents of selected category If there are many items in the list, items are Category List added in order and the scroll bar on the right is adjusted accordingly. Back Button Converts to basic mode screen Upper Category Moves to Upper Category...

  • Page 32: Connecting An External Device

    NOTICE • If only a cable is connected to the AUX without an external device, the mode will be Connecting an External Device changed to AUX, but noise may occur. When If an external device connector is con- an external device is not being used, remove nected with the AUX terminal, then AUX the connector jack.

  • Page 33: Bluetooth Audio Mode Display Controls

    ® Bluetooth Audio Features Description Artist Info Name of current artist Bluetooth Audio Mode Display Controls Title Name of current song • If play time is less than 3 seconds, moves to the previous file • If play time is over than 3 seconds, plays the Previous File current file from the beginning This function may differ depending on the...

  • Page 34: Bluetooth Connection Settings

    Bluetooth Connection Settings Settings for pairing, connection and dis- connection of a Bluetooth device. • In Bluetooth Audio play screen, select and then Menu Connections Information • If the music in the mobile phone is not played after changing to audio streaming mode, press the play button.
  • Page 35 MEMO...
  • Page 36 Bluetooth part.3 ® Before Using the Bluetooth Handsfree Bluetooth Connection Bluetooth Phone...

  • Page 37: Before Using The Bluetooth ® Handsfree

    Bluetooth Before Using the Precautions for Safe Driving ® • The Bluetooth Handsfree feature ® Bluetooth Handsfree ® may not be supported in some mobile • Bluetooth is a feature that enables driv- phones. ers to practice safe driving. Connecting ®...
  • Page 38 CAUTIONS upon Connecting • If you do not want automatic connection • The Handsfree call volume and quality ® Bluetooth Phone ® with your Bluetooth device, turn the may differ depending on the mobile phone. ® ® ® • Before connecting the head unit with Bluetooth feature off of the Bluetooth •...

  • Page 39: Bluetooth Connection

    Bluetooth Connection Connecting Bluetooth Devices Pairing a New Device Through the Phone Settings Connects the Bluetooth devices that you Pairing a New Device key. ▶ Select Press the add. SETUP Bluetooth ▶ Select . ▶ Select Before you can use the Bluetooth feature, Bluetooth Connection .

  • Page 40: Disconnecting Bluetooth Devices

    Disconnecting Deleting Bluetooth Devices Connecting Devices Through the Bluetooth Devices Phone Settings Deletes the Bluetooth devices that you key. ▶ Select Press the Disconnects Bluetooth devices that are added. Note that deleting a Bluetooth SETUP Bluetooth ▶ Select . ▶ Select the connected.

  • Page 41: Bluetooth Phone

    Bluetooth Phone Information Icons Description • The battery level icon and the call signal You can use Bluetooth phones strength indicator may not be supported in when a Bluetooth Hands-free Phone Status Icons some Bluetooth devices. connection is established. Shows the current phone status in the •...

  • Page 42: Accept/Reject Call

    Dial Accept/Reject Call Name Description Use the keypad to enter Dials a call after the Bluetooth devices the phone number that are connected. you want to call. Press and hold the last number Keypad of a speed dial to dial a •...

  • Page 43: Using The Menu During A Phone Call

    Information Using the Menu During Name Description • If the caller’s number is listed in Contacts, the a Phone Call Switches a voice call caller’s name will be displayed. Otherwise, Use Private from the car Hands-free only the number will be displayed. In some to the mobile phone.

  • Page 44: Call History

    Information Call History • In some mobile phones, call records may not Press the key, and then PHONE Call History be added to your Call History. • Calls from restricted ID’s are not added to your Call History Information. • Up to 50 calls can be added in each Dialed Calls/Received Calls/Missed Calls list.
  • Page 45 Information Contacts • Some devices require a device authentication • U p t o 5 0 0 0 p h o n e nu m b e r s c a n b e Press the key, and then PHONE Contacts for downloading your contacts.
  • Page 46 Favorites Press the key, and then PHONE Favorites Name Description Lists the phone num- bers saved as Favorites. Favorites Select from the list to dial the number. Adds a new number to Add New Favorites. Deletes numbers Delete that you select from Favorites.
  • Page 47 MEMO...

  • Page 48: Other Features

    Other Features part.4 Camera...

  • Page 49: Steering-Linked Camera

    Other Features Camera Steering-linked camera • This device is connected to a rear WARNING detection camera to see behind the car - Backing Up & Using Camera for safe reversing. • Never rely solely on the rear view camera • The Rear View Camera turns on auto- when backing up.
  • Page 50 Setup part.5 Setup Sound Settings Display Settings Bluetooth Settings Custom Button Settings Home Screen Settings Date/Time Settings Language Settings Keyboard Settings Screen Saver Settings Advanced Settings System Info...
  • Page 51 Setup Setup Setup is the screen to control Audio sys- tem settings. To enter the screen, press the SETUP key or the icon in All Menus. Setup Features Description Features Description Provides the sound con- Provides the function trol options for Position, Home to customize the three Screen...

  • Page 52: Sound Settings

    Sound Settings Display Settings Features Description Sets the volume priority Priority for Back-up warning and Adjusts the sound effects for the whole Adjusts the level of illumination for the resets Start-up volume. system. entire system. Select additional audio options such as “Speed Dependent Volume Advanced Control”...

  • Page 53: Bluetooth Settings

    Bluetooth Settings Bluetooth Connection Features Description key ▶ Select Displays the paired Press the SETUP Bluetooth Bluetooth device list. ▶ Select Changes Bluetooth phone settings. Bluetooth Connection Paired Device When selecting from List the list, the device is connected or discon- Bluetooth Settings nected.

  • Page 54: Auto Connection Priority

    Information Auto Connection Priority Bluetooth System Info • Up to 5 Bluetooth devices can be paired. key ▶ Select key ▶ Select Press the Press the SETUP Bluetooth SETUP Bluetooth • Only one Bluetooth device can be connected ▶ Select ▶...

  • Page 55: Custom Button Settings

    Custom Button Settings Home Screen Settings Date/Time Settings You can configure the feature to be You can customize the three menu items Configure the settings for time and date. accessed when the key is pressed. at the bottom right of the Home Screen Using the arrow buttons, you can change into the ones you want.

  • Page 56: Language Settings

    Language Settings Keyboard Settings Screen Saver Settings You can configure the displayed system You can configure the keyboard layout for You can select any of the following screen language. each language. formats to be displayed when the screen or power is turned off (Press and hold the Power button).

  • Page 57: Advanced Settings

    Advanced Settings System Info System Update At the System Info screen, insert the USB You can configure notifications per feature, System version information and update memory with the latest file downloaded, etc. details are available. and then select the button to begin Update updating.
  • Page 58 Appendix part.6 Product Specification Troubleshooting...

  • Page 59: Product Specification

    Appendix Product Specification Common Name Car TFT LCD Display Audio Unit TFT-LCD Operating Power Supply DC 14.4 V DC 9 V ~ DC 16 V Power Screen Size 7 inch(152.4 X 91.44 mm) Resolution 384000 pixels (Resolution: 800 x 480) Current Sleep 1 mA...
  • Page 60 ® Bluetooth Wireless Technology Supported Frequency ® 2402 ~ 2480 MHz Bluetooth Range Specification Supported Handsfree(1.6), A2DP(1.2), AVRCP(1.4), PBAP(1.0) Profile -6.5 Output dBm (Power Class2, Conducted) Number of 79 channels Channels CAUTION • The producer and installer cannot provide services related to life safety as the concerned radio equipment is liable to radio interference.

  • Page 61: Troubleshooting

    USB, iPod, or ® Bluetooth streaming mode, the most 3. If the problems persist, contact your Kia dealer. recently played mode screen prior to turn- Upon turning power on, ing off power may not properly load the most recent mode •...
  • Page 62 Display Setup The power point of purchase or Kia does not • The volume level • Adjust the volume level dealer turn on is set to the lowest •...
  • Page 63 Problem Possible Cause Countermeasure Problem Possible Cause Countermeasure • USB memory is • Please use the USB after • There are no titles • Use iTunes to download which can be and save MP3 files into the damaged formatting it. played iPod The iPod is...

  • Page 64: About Pairing Mobile Phones

    About Pairing Mobile Phones I cannot pair my mobile phone. What is the cause? What is a Passkey? ® Check to see that the mobile phone supports Bluetooth func- A passkey is the password used to authenticate the connection tion. Verify if Bluetooth on the cell phone is set to OFF. If so, set between the head unit and mobile phone.

  • Page 65: About Making/Answering Phone Calls

    ® About Making/Answering Phone Calls About Bluetooth Wireless Technology/ Head Unit Use Environment How can I answer a call? When there is an incoming call, a notification pop-up will What is the range of my wireless connection? become displayed. To answer the incoming call, select the The wireless connection can be used within 15 yards.

  • Page 66: Important Safety Information

    Important Safety Information Before using your Multimedia system, read and follow all instructions and safety information provided in this end user manual (“User’s Guide”). Not following precautions found in this User’s Guide can lead to an accident or other serious consequences. Keep User’s Guide in Vehicle When kept in the vehicle, the User’s Guide will be a ready reference for you and other users unfamiliar with the Multimedia system.
  • Page 67 Prolonged Views of Screen Do not access any function requiring a prolonged view of the screen while you are driving. Pull over in a safe and legal manner before attempting to access a function of the system requiring prolonged attention. Even occasional short scans to the screen may be hazardous if your attention has been diverted away from your driving task at a critical time.

  • Page 68: Fcc Warning

    FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
