  • Page 3 IMPORTANT SAFETY INSTRUCTIONS In these safety instructions the word “product” refers to the Canon Digital Video Camcorder OPTURA600 A and all its accessories. 1. Read Instructions — All the safety and operating instructions should be read before the product is operated.
  • Page 4 When replacement of power supply is required, please return it to the responsible nearest Canon Service Center and please replace it with the same type number CA-570. The Adapter can be used with a power supply between 100 and 240 V AC. For areas where 120 V AC power is not used, you will need a special plug adapter.

  • Page 5: Using This Manual

    Using this Manual Thank you for purchasing the Canon OPTURA600. Please read this manual carefully before you use the camcorder and retain it for future reference. Symbols and References Used in This Manual : Precautions related to the camcorder operation.
  • Page 6 Trademark Acknowledgements • is a trademark. • is a trademark. ® • Windows is a registered trademark of Microsoft Corporation in the United States and/ or other countries. • Macintosh and Mac OS are trademarks of Apple Computer, Inc., registered in the United States and other countries.

  • Page 7: Table Of Contents

    Table of contents Introduction Using this Manual ...5 Checking Supplied Accessories ...10 Components Guide...11 Screen Displays...15 Preparation Step 1: Preparing the Power Supply...17 Step 2: Loading a Cassette ...20 Step 3: Inserting a Memory Card...21 Step 4: Preparing the Camcorder ...22 Step 5: Using the Wireless Controller...23 Step 6: Adjusting the LCD Screen ...24 Step 7: Changing the Display Language ...25...
  • Page 8 Magnifying the Image ...76 Displaying the Data Code...77 End Search...78 Returning to a Pre-marked Position ...79 Date Search...80 Digital Camera Functions Selecting the Image Quality/Size...81 Simultaneous Recording on Tape and Memory Card...83 Using the Flash...84 Selecting the Light Metering Mode ...86 Changing the Focusing Mode...87...
  • Page 9 Specifications...143 Product Codes...145 Index...146...

  • Page 10: Checking Supplied Accessories

    Checking Supplied Accessories CA-570 Compact Power Adapter (incl. power cord) Lens Cap and Lens Cap Cord DIGITAL VIDEO SOLUTION DISK The serial number of this product can be found at the battery attachment unit of the camcorder. Write down the number and other information here and retain this book as a permanent record of your purchase to aid identification in case of theft.

  • Page 11: Components Guide

    Components Guide Left side view Right side view Speaker ( MIC terminal ( Terminal cover Serial number Battery attachment unit ( RESET button ( 126) (flash) button ( 84) / (play/pause) button ( LCD BACKLIGHT button ( (self-timer) button ( 50) / REC PAUSE button ( 98, 100)

  • Page 12: Front View

    Front view Back view Remote sensor ( Terminal cover Flash ( Mini video light ( AV terminal ( DC IN terminal ( Charge indicator ( Card access indicator ( LCD screen ( Memory card slot ( USB terminal ( 108, 121) DV terminal ( 97, 100) Viewfinder (...

  • Page 13: Top View

    Top view Bottom view Stereo microphone (print/share) button ( Tripod socket ( Cassette compartment ( 109, 121) OPEN/EJECT Cassette compartment cover ( switch (...
  • Page 14 Wireless Controller WL-D85 Transmitter START/STOP button ( CARD –/+ buttons ( DATE SEARCH button ( –/ button ( PAUSE button ( SLOW button ( AUDIO DUB. button ( START/ STOP PHOTO ZOOM CARD DATE SEARCH PLAY STOP PAUSE SLOW ZERO SET AUDIO DUB.

  • Page 15: Screen Displays

    Screen Displays When recording movies on a tape (CAMERA• When recording on a memory card (CAMERA• Remaining battery charge The battery symbol indicates the charge status of the battery pack. • “ ” starts flashing in red when the battery pack is empty. •...
  • Page 16 When playing back a tape (PLAY(VCR)• Tape operation : Record : Pause rewind playback ( : Stop : Eject : Play : Fast forward frame reverse playback ( : Rewind When playing back a memory card (PLAY(VCR)• 12 bit audio ( End search ( Audio dubbing ( Digital effects (...

  • Page 17: Step 1: Preparing The Power Supply

    Step 1: Preparing the Power Supply Preparation The camcorder can be powered by a battery pack or connected to a household power source. Charge the battery pack before use. Attaching the Battery Pack 1. Turn the POWER switch to OFF. 2.

  • Page 18: Using A Household Power Source

    Using a Household Power Source Connect to a household power source to use the camcorder without worrying about the battery power. You can keep the battery pack attached; the battery power will not be consumed. 1. Turn the POWER switch to OFF. 2.
  • Page 19 Charging, Recording and Playback Times Below times are approximate and vary according to the charging, recording or playback conditions. Battery Pack Charging Time Max. Recording Time Viewfinder normal bright Typical Recording Time* Viewfinder normal bright Playback Time * Approximate times for recording with repeated operations such as start/stop, zooming, power on/off.

  • Page 20: Step 2: Loading A Cassette

    Step 2: Loading a Cassette Use only videocassettes marked with the 1. Slide the OPEN/EJECT switch and open the cassette compartment cover. The cassette compartment opens automatically. 2. Load the cassette. Unload the cassette by pulling it straight out. 3. Press the mark on the cassette compartment until it clicks.

  • Page 21: Step 3: Inserting A Memory Card

    Step 3: Inserting a Memory Card This camcorder is for use with SD Memory Cards only. Inserting the Card 1. Set the POWER switch to OFF. 2. Open the cover. 3. Insert the memory card straight all the way into the memory card slot. 4.

  • Page 22: Step 4: Preparing The Camcorder

    Step 4: Preparing the Camcorder Adjusting the Viewfinder (Dioptric Adjustment) 1. Turn on the camcorder and keep the LCD panel closed. 2. Adjust the dioptric adjustment lever. Attaching the Lens Cap 1. Attach the cord to the lens cap. 2. Pass the grip belt through the loop on the cord.

  • Page 23: Step 5: Using The Wireless Controller

    Step 5: Using the Wireless Controller Inserting the Battery The wireless controller operates with a lithium button battery CR2025. 1. Press the tab in the direction of the arrow and pull out the battery holder. 2. Place the lithium button battery with the + side facing up.

  • Page 24: Step 6: Adjusting The Lcd Screen

    Step 6: Adjusting the LCD Screen Rotating the LCD Panel Open the LCD panel 90 degrees. • You can rotate the panel downward by 90 degrees. • You can rotate the panel by 180 degrees toward the lens (allowing the subject to monitor the LCD screen).

  • Page 25: Step 7: Changing The Display Language

    Step 7: Changing the Display Language The language used in the camcorder displays and menu items can be changed to German, Spanish, French, Italian, Russian, Simplified Chinese, Traditional Chinese, Korean or Japanese. MENU DISPLAY SETUP/ 1. Turn the POWER switch to CAMERA or PLAY (VCR). 2.

  • Page 26: Step 8: Setting The Time Zone, Date And Time

    Step 8: Setting the Time Zone, Date and Time Setting the Time Zone/Daylight Saving Time MENU D/TIME SET 1. Turn the POWER switch to CAMERA or PLAY (VCR). 2. Press the MENU button to open the menu. 3. Turn the SET dial to select [D/TIME SET] and press the SET dial.
  • Page 27 Time Zones Once you have set your time zone, date and time, you do not need to reset the clock each time you travel to another time zone. Just set the time zone to the one of your destination, and the camcorder automatically adjusts the clock. Time Zones and Difference from GMT/UTC London Paris...

  • Page 28: Recording

    Basic Functions Recording Movies on a Tape Recording Before You Begin Recording Make a test recording first to check if the camcorder operates correctly. If necessary, clean the video heads ( 1. Press the small button and set the POWER switch to CAMERA. The POWER indicator lights up.
  • Page 29 Screen Displays during Recording Time Code Indicates the recording time in hours, minutes and seconds. Reviewing and Searching when Recording You can review the last few seconds of your recording (record review). You can also play back the tape to locate the point where you wish to begin recording (record search). Record Review In record pause mode: Press and release the...

  • Page 30: Recording On A Memory Card

    Recording on a Memory Card Recording Still Images on a Memory Card 1. Press the small button and set the POWER switch to CAMERA. The POWER indicator lights up. 2. Set the TAPE/CARD switch to 3. Select the still image size and quality ( 82).
  • Page 31 Sound for movies recorded on the memory card will be monaural. When you use a SD Memory Card, we recommend using a Canon SD Memory Card, or a SD Memory Card with a transfer rate of more than 2 MB/sec., right after you have formatted it with this camcorder.
  • Page 32 Screen Displays during Still Image Recording Still Image Quality/Size Indicates the image quality and the image size of the still image. Screen Displays during Movie Recording Movie size Indicates the movie size. Card Access Display “ ” appears to indicate that the camcorder is writing on the memory card.

  • Page 33: Zooming

    Zooming CAMERA• mode: In addition to the 10x optical zoom you can also use the 200x digital zoom ( 65). 10x Optical Zoom Move the zoom lever toward W to zoom out (wide- angle). Move it toward T to zoom in (telephoto). Press the zoom lever slightly for a slow zoom.

  • Page 34: Tips For Better Recording

    Tips for Better Recording Holding the Camcorder For maximum stability, grip the camcorder in your right hand and keep your right elbow pressed against your body. If necessary, support the camcorder with your left hand. Be careful that your fingers do not touch the microphone or lens.

  • Page 35: Playback

    Playing Back a Tape Playback If the playback picture is distorted, clean the video heads using a Canon Head Cleaning Cassette or a commercially available digital video head-cleaning cassette ( 1. Press the small button and set the POWER switch to PLAY (VCR).
  • Page 36 Special Playback Modes (Playback Pause) To pause playback, press the (Fast Forward Playback) / Plays back the tape at 9.5 times normal speed (forward or reverse). Press and hold the button during normal playback or fast forward. –/ (Reverse Playback) Press the button on the wireless controller during normal playback.

  • Page 37: Playing Back A Memory Card

    Playing Back a Memory Card 1. Press the small button and set the POWER switch to PLAY (VCR). 2. Set the TAPE/CARD switch to 3. Press the CARD +/– button to move between images. Press the button to play back a movie.

  • Page 38: Adjusting The Volume

    Adjusting the Volume When you use the LCD screen for playback, the camcorder plays back the sound via built-in speaker. The speaker does not sound when you close the LCD panel. Use headphones when using the viewfinder. Speaker 1. Set the camcorder to PLAY(VCR)• 2.

  • Page 39: Playing Back On A Tv Screen

    Playing Back on a TV Screen Refer also to the TV or VCR instruction manual. Signal flow MTC-100 Multi Cable (Supplied) 1. Turn off all devices before starting the connections. 2. Open the terminal cover and connect the camcorder to the TV/VCR using the MTC-100 Multi Cable.

  • Page 40: Using The Recording Programs

    Advanced Functions Using the Recording Programs Recording Programs Auto The camcorder adjusts focus, exposure and other settings automatically, allowing you to just point and shoot. Portrait The camcorder uses a large aperture, achieving a focus on the subject while blurring other distracting details.
  • Page 41 Selecting the Recording Program 1. Set the camcorder to CAMERA• 2. Turn the mode dial to switch between the recording programs. The symbol of the selected recording program appears. Do not change the mode during recording as the brightness of the image may change abruptly.

  • Page 42: Using The Super Night Mode

    Using the Super Night Mode Allows you to record in dimly lit places without sacrificing color. The assist lamp lights up automatically responding to the surrounding brightness. SET dial 1. Set the camcorder to CAMERA• 2. Set the mode dial to 3.

  • Page 43: Using The Special Scene Modes

    Using the Special Scene Modes FOLIAGE Use this mode to record images with flowers, leaves or trees. BEACH Use this mode to record on a sunny beach. It prevents the subject from being underexposed. SPOTLIGHT Use this mode to record spotlit scenes. 1.

  • Page 44: Using The Program Ae Mode

    Using the Program AE Mode The camcorder automatically adjusts shutter speed and exposure according to the brightness of the subject. In Program AE mode, you can point and shoot as in Auto mode, however, you have the option of changing some settings. 1.

  • Page 45: Using The Shutter-Priority Ae Mode

    Using the Shutter-Priority AE Mode You can select a shutter speed, and the camcorder automatically sets a matching aperture setting. Select a high shutter speed for recording fast moving subjects, and a slow shutter speed to create a trailing after image. Guidelines for selecting the shutter speed CAMERA•...

  • Page 46: Using The Aperture-Priority Ae Mode

    Using the Aperture-Priority AE Mode You can select an aperture value, and the camcorder automatically chooses the appropriate shutter speed. Aperture values: 1.8, 2.0, 2.4, 2.8, 3.4, 4.0, 4.8, 5.6, 6.7, 8.0 Use low aperture values (large aperture) to blur the background for a portrait, or high aperture values (small aperture) to achieve a broad depth of field for recording landscapes.

  • Page 47: Adjusting Exposure Manually

    Adjusting Exposure Manually Recording Adjust the exposure when a backlit subject becomes underexposed, or overexposed due to bright light. EXP button Exposure Lock 1. Set the camcorder to CAMERA• 2. Set the mode dial to a mode other than Exposure cannot be adjusted in the Fireworks mode (SCN). 3.

  • Page 48: Adjusting The Focus Manually

    Adjusting the Focus Manually Autofocus may not work well on the following subjects. In such case, focus manually. Subjects with low Reflective contrast or without surfaces FOCUS button 1. Set the camcorder to CAMERA• 2. Set the mode dial to a mode other than 3.

  • Page 49: Using The Mini Video Light

    Using the Mini Video Light You can turn on the mini video light (assist lamp) at any time regardless of the recording program. LIGHT button 1. Set the camcorder to CAMERA• 2. Press the LIGHT button. • “ ” appears on the screen. •...

  • Page 50: Using The Self-Timer

    Using the Self-Timer The self-timer can be used for recording movies and still images. 1. Set the camcorder to CAMERA• 2. Press the (self-timer) button. • “ ” appears. • In the CAMERA• When recording a still image: 3. Press the PHOTO button halfway. 4.

  • Page 51: Recording With An External Microphone

    Recording with an External Microphone You can use the optional SA-1 Adapter Bracket to attach a microphone to the camcorder. Refer also to the instruction manual of the microphone. 1. Attach the microphone to the adapter bracket. 2. Attach the adapter bracket to the camcorder. 3.

  • Page 52: Changing The Settings With The Func. Button

    Changing the Settings with the FUNC. Changing the Settings (1) Button Many of the camcorder’s functions are selected from the FUNC. menu that appears when pressing the FUNC. button. For menu items, see List of Menu Items (FUNC.) ( FUNC. button 1.

  • Page 53: List Of Menu Items (Func.)

    List of Menu Items (FUNC.) Available menu items vary depending on the operation mode. Default settings are in boldface text. For details on each function, see the reference page. Menu Items Light metering EVALUATIVE, SPOT mode White balance AUTO, TUNGSTEN, FLUORESCENT H, Image effect IMAGE EFFECT OFF,...

  • Page 54: Setting The White Balance

    Setting the White Balance You can use the preset modes to reproduce colors more accurately, or set a custom white balance to obtain the optimal setting. AUTO DAYLIGHT SHADE CLOUDY TUNGSTEN FLUORESECENT FLUORESCENT H FUNC. button AUTO 1. Set the camcorder to CAMERA• 2.
  • Page 55 Use the auto setting for normal outdoor scenes. Depending on the type of fluorescent light, optimal color balance cannot be accomplished with [FLUORESCENT] or [FLUORESCENT H]. If the color looks unnatural on the screen, adjust using [AUTO] or [SET]. The camcorder retains the custom white balance setting even if you turn it off. When you want to use a previously made [SET] setting, after selecting [SET] in step 4, press the FUNC.

  • Page 56: Selecting An Image Effect

    Selecting an Image Effect You can record with different saturation and contrast color effects. IMAGE EFFECT OFF VIVID NEUTRAL LOW SHARPENING SOFT SKIN DETAIL CUSTOM IMAGE EFFECT OFF 1. Set the camcorder to CAMERA• 2. Set the mode dial to a mode other than 3.

  • Page 57: Using Digital Effects

    Using Digital Effects The Digital Effects functions include a fader and effects, multi-image screen and Card Mix. Faders ( Begin or end scenes with a fade to or from black. Fade Trigger (FADE-T) Corner Wipe (CORNER) Flip (FLIP) Zigzag (ZIGZAG) Tide (TIDE) Wipe (WIPE) Jump (JUMP)
  • Page 58 Effects ( Add flavor to your recordings. Black and White (BLK & WHT) Mosaic (MOSAIC) Wave (WAVE) Multi-Image Screen ( Captures moving subjects in 4, 9 or 16 sequences of still images and displays them at one time. Sound will be recorded normally. 4 Sequences Card Mix ( Combines a still image recorded on a memory card with your recording.
  • Page 59 Availability of Digital Effects by Operating Modes: CAMERA• Still Movies Images Faders Effects Multi-image screen Card mix : Available : Not available *: Black and White only. Selecting a Fader D.EFFECT OFF 1. Set the camcorder to CAMERA• CAMERA• mode: Set the mode dial to a mode other than 2.

  • Page 60: Selecting An Effect

    PLAY(VCR)• mode: 7. Fade in: Press the mode. Fade out: Press the Selecting an Effect D.EFFECT OFF 1. Set the camcorder to CAMERA• CAMERA• and CAMERA• than 2. Press the FUNC. button. 3. Select the digital effect symbol followed by EFFECT].
  • Page 61 Using the Multi-Image Screen You can operate the multi-image screen only in the following playback modes: • When [S.SPEED] is set to [MANUAL]: Playback pause, slow forward/reverse playback • When [S.SPEED] is set to [FAST], [MOD.] or [SLOW]: Playback pause D.EFFECT OFF 1.
  • Page 62 Combining Images (Card Mix) You can produce effects not possible with just a tape with the Card Mix function. Choose one of the sample images provided on the supplied DIGITAL VIDEO SOLUTION DISK (such as picture frames, backgrounds and animations) and combine it with the live video recording.
  • Page 63 CARD + / – button FUNC. button D.EFFECT OFF 1. Set the camcorder to CAMERA• 2. Upload a sample image from the DIGITAL VIDEO SOLUTION DISK to the memory card. Refer to Adding Still Images from Your Computer to the Memory Card in the Digital Video Software Instruction Manual.

  • Page 64: Changing The Settings With The Menu Button

    Changing the Settings with the MENU Changing the Settings (2) Button Many of the camcorder’s functions are selected from a menu that appears when pressing the MENU button. For menu items, see List of Menu Items (MENU) ( Selecting Menus and Settings 1.

  • Page 65: List Of Menu Items (Menu)

    List of Menu Items (MENU) Available menu items vary depending on the operation mode. Default settings are in boldface text. For details on each function, see the reference page. Functions without reference page are explained below the tables. CAMERA SETUP Menu Items A.SL SHUTTER D.ZOOM...
  • Page 66 FOCUS PRI.: The camcorder records the still image once focus is adjusted. Set it to [OFF] when you wish to record a still image as soon as you press the PHOTO button. When set to [OFF], no focusing frame appears. The setting cannot be turned off when the mode dial is set to In Fireworks mode (SCN) the setting is automatically turned off.
  • Page 67 REC MODE: Switches the recording mode. The long play mode extends the tape usage by 1.5 times. Tapes recorded in LP mode cannot be used for audio dubbing. Depending on the nature and usage condition of the tape, picture and sound recorded in LP mode may be distorted.
  • Page 68 DISPLAY SETUP Menu Items BRIGHTNESS LCD MIRROR TV SCREEN DISPLAYS 6SEC.DATE DATA CODE DATE, CAMERA DATA, DATE, LANGUAGE DEUTSCH, ENGLISH, ESPAÑOL, FRANÇAIS, ITALIANO, DEMO MODE BRIGHTNESS: Adjusts the brightness of the LCD screen. Turn the SET dial up or down to adjust the brightness. Changing the brightness of the LCD screen does not affect that of the viewfinder or the recordings.
  • Page 69 SYSTEM Menu Items WL. REMOTE BEEP HIGH VOLUME, POWER SAVE FILE NOS. RESET, WL. REMOTE: Sets the camcorder to be operated with the wireless controller. BEEP: A beep sounds upon operations such as turning on the camcorder, during self- timer countdown or warnings such as condensation. POWER SAVE: When powered by a battery pack, the camcorder shuts off after 5 minutes when the camcorder is left without any operation to save power.
  • Page 70 When selecting the settings, you can check the sound and image. To check the sound, make sure to set beep to a setting other than [OFF] in the menu. Setting Options CANON LOGO, MY IMAGE DEFAULT, MY SOUND...

  • Page 71: Adjusting The Audio Recording Level

    Adjusting the Audio Recording Level You can manually adjust the audio recording level of the built-in microphone or an external microphone. MENU AUDIO SETUP 1. Set the camcorder to CAMERA• 2. Set the mode dial to a mode other than 3.
  • Page 72 About the audio level indicator: [MIC LEVEL] is set to [MANUAL] When [MIC LEVEL] is set to [AUTO] or in the PLAY(VCR)• AUDIO LEVEL button will alternately turn audio level indicator on and off. The audio level can be changed when the green bar is displayed. We recommend hiding the bar when you have finished adjusting to prevent accidental changes.

  • Page 73: Using The Wind Screen

    Using the Wind Screen The camcorder reduces wind noise automatically. However, you can turn off the wind screen when recording indoors, or when you want the microphone to be as sensitive as possible. MENU AUDIO SETUP 1. When setting the camcorder to CAMERA the mode dial to a mode other than When setting the camcorder to PLAY(VCR) [AUDIO DUB.] is set to [MIC.

  • Page 74: Widescreen Tv Recording (16:9)

    Widescreen TV Recording (16:9) The camcorder uses the full width of the CCD providing high-resolution 16:9 recording. MENU CAMERA SETUP 1. Set the camcorder to CAMERA• 2. Press the MENU button and select [CAMERA SETUP]. Select [WIDESCREEN], set it to [ON] and press the MENU button. •...

  • Page 75: Creating A Start-Up Image

    Creating a Start-up Image You can create a start-up image using a still image on the memory card. MENU MY CAMERA 1. Set the camcorder to PLAY(VCR)• 2. Select a still image with the CARD +/– buttons. 3. Press the MENU button and select [MY CAMERA]. 4.

  • Page 76: Magnifying The Image

    Magnifying the Image Playback The playback image can be magnified up to 5 times. 1. Set the camcorder to PLAY(VCR)• 2. Move the zoom lever toward T. • The image is magnified by 2 times. • A frame appears indicating the position of the magnified area. •...

  • Page 77: Displaying The Data Code

    Displaying the Data Code The camcorder maintains a data code containing recording date and time and other camera data such as shutter speed and exposure (f-stop). DATA CODE button Selecting the Date/Time Display Combination MENU DISPLAY SETUP/ 1. Set the camcorder to PLAY(VCR)• 2.

  • Page 78: End Search

    End Search When you have played back a tape, you can use this function to locate the end of the last recorded scene. END SEARCH button 1. Set the camcorder to PLAY(VCR)• 2. Play back the tape. 3. In stop mode, press the END SEARCH button. •...

  • Page 79: Returning To A Pre-Marked Position

    Returning to a Pre-marked Position If you wish to return to a particular scene later, mark the point with the zero set memory and the tape will stop at that point when you rewind/fast forward the tape. This function is operated with the wireless controller.

  • Page 80: Date Search

    Date Search You can locate the change of the date/time zone with the date search function. This function is operated with the wireless controller. 1. Set the camcorder to PLAY(VCR)• 2. In stop mode, press the • Press more than once to search for further date changes (up to 10 times). •...

  • Page 81: Selecting The Image Quality/Size

    Selecting the Image Quality/Size Digital Camera Functions You can select the image quality of still images, and the image size of still images and movies. Still images are compressed and recorded in JPEG (Joint Photographic Experts Group). Movies are recorded in Motion JPEG.
  • Page 82 Selecting the Still Image Size and Quality 2304x1736/FINE 1. Set the camcorder to CAMERA 2. Press the FUNC. button. 3. Select the still image size/quality symbol. 4. Select the still image size. The number at the lower right corner indicates the number of still images available on the memory card (the same as the number displayed at the upper right corner).

  • Page 83: Simultaneous Recording On Tape And Memory Card

    Simultaneous Recording on Tape and Memory Card When you are recording a movie on a tape, you can record the same picture as a still image on the memory card. The size of the still image will be 640 x 480. The image quality can be selected.

  • Page 84: Using The Flash

    Using the Flash You can use the built-in flash for recording still images in dark places. The flash is equipped with the red-eye reduction mode. (auto) (red-eye reduction, auto) (flash on) (flash off) PHOTO button 1. Set the camcorder to CAMERA• 2.
  • Page 85 The flash will not fire in the following cases: - When you press the EXP button in mode. - When (auto) or (red-eye reduction, auto) is selected and a shutter speed of 1/2000 is set in the CAMERA• - During auto exposure bracketing. When (flash on) is selected and a shutter speed of 1/2000 is set in the CAMERA•...

  • Page 86: Selecting The Light Metering Mode

    Selecting the Light Metering Mode You can select the method the camera uses to evaluate the brightness of your subject. EVALUATIVE CENT.WEIGHT.AVERAGE SPOT EVALUATIVE 1. Set the camcorder to CAMERA• 2. Set the mode dial to 3. Press the FUNC. button. 4.

  • Page 87: Changing The Focusing Mode

    Changing the Focusing Mode You can change the AF (autofocus) frame selection mode. 9 Point AiAF Depending on the shooting conditions, an AF frame is (Auto selection) automatically selected from the 9 frames and focused. Center point Of 9 AF frames, the center one is selected to focus. This is convenient for making sure the focus is exactly where you want it.

  • Page 88: Selecting The Drive Mode

    Selecting the Drive Mode (Single) (Continuous Shooting) (High-Speed Continuous Shooting) (AEB (Auto Exposure Bracketing)) DRIVE MODE button 1. Set the camcorder to CAMERA• 2. Set the mode dial to a mode other than 3. Press the DRIVE MODE button to switch between the drive modes. The setting changes with each press of the button.
  • Page 89 The drive mode can also be selected from the FUNC. menu ( When the FUNC. menu is being displayed, the DRIVE MODE button cannot be used. Maximum number of continuous shots at one time: Still Image Size Normal speed 2304 x 1736 2.1 frames 1632 x 1224 2.5 frames...

  • Page 90: Recording Panoramic Images (Stitch Assist Mode)

    Recording Panoramic Images (Stitch Assist Mode) You can shoot a series of overlapping images and merge them into one large panoramic scene using the supplied software (PhotoStitch) on a computer. CARD +/– button When Recording in Stitch Assist Mode: PhotoStitch detects the overlapping portion of adjoining images and merges them. Try to include a distinctive item (landmark, etc.) in the overlapping portion.
  • Page 91 9. Press the FUNC. button after the last image. • The Stitch Assist screen will disappear. The DRIVE MODE button can also be used to close the Stitch Assist screen. • For details on how to merge these images, refer to the Digital Video Software Instruction Manual.

  • Page 92: Playing Back/Searching Images

    Playing Back/Searching Images You can display images one after another (slide show) or 6 at one time (index screen). With the Card Jump function, you can quickly locate an image without displaying them one by one. CARD – button Slide Show SLIDE SHOW 1.
  • Page 93 Card Jump Function You can locate images without displaying them one by one. The number in the upper right of the screen indicates the image number of the current image by the total number of images. 1. Set the camcorder to PLAY(VCR)• mode.

  • Page 94: Protecting Images

    Protecting Images You can protect important images from accidental erasure when displaying a single image or index screen. If a memory card is formatted, all still images and movies, even protected ones, will be erased permanently. Movies can only be protected when the first scene is displayed as a still image. Protecting during Single Image Playback PROTECT 1.

  • Page 95: Erasing Images

    Erasing Images You can erase images singly or all at once. Be careful when erasing images. Erased images cannot be recovered. Protected images cannot be erased. Movies can only be erased when the first scene is displayed as a still image. Erasing a Single Image IMAGE ERASE 1.

  • Page 96: Formatting A Memory Card

    Formatting a Memory Card Format new memory cards, or when you get the message “CARD ERROR”. You can also format a memory card to erase all data recorded on it. Formatting a memory card erases all data, including protected images. Images erased by formatting cannot be recovered.

  • Page 97: Recording To A Vcr Or Digital Video Device

    Recording to a VCR or Digital Video Editing Device You can copy your recordings by connecting the camcorder to a VCR or a digital video device. If you use the DV terminal to connect to a recording digital device (camcorder, DVD recorder, etc.) you can create perfect digital copies with virtually no generation loss in image or sound quality.

  • Page 98: Analog Line-In Recording

    Analog Line-in Recording You can input video from other analog devices (VCR, TV or camcorder) via the S-video terminal or AV terminal, and record the input video on the tape in the camcorder. You can also record the input video as a movie or still image on a memory card. Connecting Refer also to the instruction manual of the connected device.
  • Page 99 Recording the Input Video on a Memory Card The size of the still image recorded on the memory card will be 640 x 480. The still image quality and the movie size can be selected. 1. Set the camcorder to PLAY(VCR)• If a cassette is loaded, make sure that the tape is stopped.

  • Page 100: Dv Dubbing

    DV Dubbing You can input video from other digital video devices via the DV terminal, and record the input video on the tape in the camcorder. You can also record the input video as a movie or still image on a memory card. Connecting Check the direction before connecting the DV cable.
  • Page 101 Press the FUNC. button. Select the movie size symbol followed by a setting option and press the FUNC. menu. 3. Connected device: Load a recorded cassette and play back the tape. When recording a still image: 4. Press the PHOTO button halfway when the scene you wish to record appears.

  • Page 102: Converting Analog Signals Into Digital Signals (Analog-Digital Converter)

    Converting Analog Signals into Digital Signals (Analog-Digital Converter) By connecting the camcorder to a VCR or 8mm video camcorder, you can convert analog video/audio signals to digital signals and output the digital signals via the DV terminal. The DV terminal serves as output terminal only. Connecting the Devices Turn off all devices before starting the connections.
  • Page 103 Turning On the Analog-Digital Converter MENU VCR SETUP 1. Set the camcorder to PLAY(VCR)• Check the video input setting ( 2. Press the MENU button and select [VCR SETUP]. Select [AV set it to [ON] and press the MENU button. Depending on the signal sent from the connected device, the conversion from analog to digital signals might not work properly (e.g., signals that include copyright protective signals or anomalous signals such as ghost signals).

  • Page 104: Audio Dubbing

    Audio Dubbing You can add sound from audio devices (AUDIO IN) or with the built-in or an external microphone (MIC. IN). This function is operated with the wireless controller. Connecting Connecting an Audio Device Refer also to the instruction manual of the connected device. Audio device (e.g.
  • Page 105 Audio dubbing will stop if the tape has a blank section or a section recorded in LP mode or 16-bit mode. When using the built-in microphone, do not connect any devices to the MIC terminal. You cannot use the DV terminal for audio dubbing. If you add sound to a tape not recorded with this camcorder, sound quality may decrease.

  • Page 106: Recording From The Tape On A Memory Card

    Recording from the Tape on a Memory Card You can record movies or still images from a tape in the camcorder. Recording a Movie from the Tape The movie size can be selected. 320x240 1. Set the camcorder to PLAY(VCR)• 2.
  • Page 107 An image recorded from an image in widescreen mode will be vertically compressed. The data code of the image will reflect the date and time it has been recorded on the memory card.

  • Page 108: Printing Still Images

    Refer to the instruction manual of each printer for information on which interface cable to use with the camcorder. The Canon CP-Printers CP-10 and CP-100 are supplied with two direct interface cables. Use the cable with the USB logo on the connector (DIF-100).
  • Page 109 Printing with the You can print an image without changing the settings by simply pressing the share) button. 1. Select the still image you wish to print with the CARD +/– button. 2. Press the (print/share) button. • Printing starts. The when printing is complete.
  • Page 110 - Canon PIXMA/SELPHY DS printers and CP600: Printing stops even if it is incomplete and the paper is fed through. - Canon CP printers (except for CP600): A print in progress cannot be stopped. Printing stops when the current print is finished, and the remaining prints are canceled.

  • Page 111: Selecting The Print Settings

    The image’s top, bottom and sides may be cropped slightly. [VIVID], [VIVID+NR] and [NR] can be selected with Canon PIXMA/SELPHY DS printers. When selecting [2-UP], [4-UP], [9-UP] or [16-UP] for [PAGE LAYOUT], set the [PAPER SIZE] to [10 x 14.8 cm].
  • Page 112 Paper Settings 1. In the print setting menu, turn the SET dial to select [PAPER] and press the SET dial. 2. Turn the SET dial to select the paper size and press the SET dial. Select the paper size of the paper set in your printer. 3.

  • Page 113: Setting The Print Style

    Setting the Print Effect (Image Optimize) This function uses the camcorder’s recording information to optimize the image data, yielding high quality prints. 1. In the print setting menu, turn the SET dial to select (print effect) and press the SET dial. 2.
  • Page 114 3. Turn the SET dial to select the paper size and press the SET dial. • Select the paper size of the paper set in your printer. • Pressing the MENU button brings you back to the print settings menu. 4.
  • Page 115 Selecting the Image Style 2. Make sure that (IMAGE) is selected and press the SET dial. 3. Turn the SET dial to select the image style and press the SET dial. Pressing the MENU button brings you back to the print settings menu.

  • Page 116: Trimming Settings

    • Pressing the MENU button brings you back to the print settings menu. About the color of the trimming frame (Canon CP printers only): - White: No trimming settings. - Green: Recommended trimming size. (The trimming frame may not appear in green depending on the image size, paper size or borders settings.)

  • Page 117: Printing With Print Order Settings

    Printing with Print Order Settings You can select still images for printing and set the number of copies. These print order settings are compatible with the Digital Print Order Format (DPOF) standards and can be used for printing on DPOF compatible printers ( can be selected.
  • Page 118 Erasing All Print Orders MENU CARD OPERATIONS 1. Set the camcorder to PLAY(VCR)• 2. Press the MENU button and select [CARD OPERATIONS]. 3. Select [PRINT ORD. ALL ERASE]. “ERASE ALL PRINT ORDERS?”, [NO] and [YES] appears. 4. Select [YES]. All “ ”...

  • Page 119: Transferring Video Recordings To A Computer

    A computer running Windows XP (Service Pack 1 or Service Pack 2) equipped with a USB2.0 (Hi-Speed) Terminal A USB cable (supplied) Canon USB Video Driver (the driver is included with the supplied DIGITAL VIDEO SOLUTION DISK) Windows Movie Maker 2 (Version 2.0.3312.0 with SP1, 2.1.4026.0 with SP2)

  • Page 120: Connection Diagram

    Connection Diagram Check the type and orientation of the DV or USB terminal and make sure you connect the DV cable or USB cable properly. Using a USB cable IFC-300PCU USB Cable (supplied) Using an IEEE1394 (DV) cable Operation may not work correctly depending on the software and the specifications/settings of your computer.

  • Page 121: Transferring Memory Card Images To A Computer (Direct Transfer)

    Transferring Memory Card Images to a Computer (Direct Transfer) With the supplied USB cable and Digital Video Software, you can transfer images to the computer by simply pressing the Preparations The first time you connect the camcorder to the computer, you need to install the software and set the auto-launch setting.

  • Page 122: Transferring Images

    Transferring Images To transfer images with transfer order, you need to set the transfer orders ( ALL IMAGES... NEW IMAGES... TRANSFER ORDERS... SELECT & TRANSFER... Allows you to select an image and transfers the selected WALLPAPER... CARD + / – button 1.
  • Page 123 When the camcorder is connected to the computer and screen to select images displays, press the MENU button. The transfer menu will display. When the protect switch of the SD Memory Card is activated during image transfer, the images will not be marked as “already transferred”, and will be transferred again when you select [ NEW IMAGES] later.

  • Page 124: Selecting Images For Transfer (Transfer Order)

    Selecting Images for Transfer (Transfer Order) You can select images for transfer to the computer. These transfer settings are compatible with the Digital Print Order Format (DPOF) standards. A maximum of 998 images can be selected. Do not connect a USB or DV cable to the camcorder while setting the transfer orders. TRANSFER ORDER 1.

  • Page 125: Using The Network Mode (Dv Messenger Version 2)

    1. Start the computer and install DV Messenger. If you wish to connect the camcorder using a USB cable, you also need to install the Canon USB Video Driver (The required USB Video Driver will be downloaded together with the DV Messenger).

  • Page 126: Troubleshooting

    “ ” flashes on the screen. “ ” flashes on the screen. “ ” flashes red on the screen. The camcorder malfunctions. Consult a Canon Service Solution Battery pack is exhausted. Replace or charge the battery pack. Attach the battery pack correctly.
  • Page 127 Problem “REMOVE THE CASSETTE” Unload and reload the cassette. appears on the screen. “SET THE TIME ZONE, Set the time zone, date and time. DATE AND TIME” appears on Recharge the built-in lithium battery and set the time zone, the screen. date and time.
  • Page 128 Memory Card Operation Problem Memory card cannot be inserted. Memory card cannot be recorded. Memory card cannot be played back. Image cannot be erased. “ ” flashes red. Printing Problem The printer is not operating even though camcorder and printer are correctly connected.
  • Page 129 Condensation Moving the camcorder rapidly between hot and cold temperature may cause condensation (water droplets) to form on its internal surfaces. Stop using the camcorder if condensation is detected. Continued use may damage the camcorder. Condensation may form in the following cases: When the camcorder is moved from an air-conditioned room to warm, humid place...

  • Page 130: List Of Messages

    List of Messages Message SET THE TIME ZONE, DATE AND TIME CHANGE THE BATTERY PACK THE TAPE IS SET FOR ERASURE PREVENTION REMOVE THE CASSETTE CHECK THE INPUT CONDENSATION HAS BEEN DETECTED CONDENSATION HAS BEEN DETECTED REMOVE THE CASSETTE TAPE END CHECK THE CASSETTE [WRONG FORMAT] WRONG FORMAT...
  • Page 131 TV: When an error number or error message is displayed on the panel or TV monitor. If the error persists, consult your dealer or a Canon Service Center listed in the Contact List provided with the printer or the printer’s manual.
  • Page 132 The ink cannot be used with the selected paper type. Waste tank is full. Select [CONTINUE] to restart printing. Consult your dealer or a Canon Service Center listed in the Contact List provided with the printer or the printer manual to replace the waste tank (waste ink absorber).

  • Page 133: Handling Precautions

    Handling Precautions Do’s & Don’ts Camcorder Do not carry the camcorder by the LCD panel or viewfinder. Do not leave the camcorder in places subject to high temperatures, such as a sun- heated car, and high humidity. Do not use the camcorder near strong electric or magnetic fields such as above TVs, near plasma TVs or mobile phones.
  • Page 134 Although the battery pack’s operating temperature range is from 32 °F to 104 °F (0 °C to 40 °C), the optimal range is from 50 °F to 86 °F (10 °C to 30 °C). At cold temperatures, performance will temporarily decline. Warm it in your pocket before use. Replace the battery pack if the usable time after full charge diminishes substantially at normal temperatures.

  • Page 135: Memory Card

    We recommend saving backups of memory card images on your computer’s hard drive or other external memory device. Image data may be corrupted or lost due to memory card defects or exposure to static electricity. Canon Inc. makes no warranties for corrupted or lost data.
  • Page 136 Recycling the Built-in Rechargeable Lithium Battery If you should dispose of your camcorder, first remove the built-in rechargeable lithium battery for recycling according to the recycling system of your country. 1. Loosen the screw using a screwdriver and remove the cover. 2.

  • Page 137: Cleaning The Video Heads

    To maintain the best picture quality, we recommend cleaning the video heads frequently with the Canon DVM-CL Digital Video Head Cleaning Cassette or a commercially available dry cleaning cassette.

  • Page 138: Maintenance/Others

    You can use the compact power adapter to operate the camcorder and to charge battery packs in any country with power supply between 100 and 240 V AC, 50/60 Hz. Consult the Canon Service Center for information on plug adapters for overseas use. Playback on a TV Screen You can only play back your recordings on TVs with NTSC system.

  • Page 139: System Diagram

    Battery Charger MTC-100 Multi Cable Commercially available DV Cable IFC-300PCU USB Cable SDC-128M SD Memory Card SC-A50 Soft Canon printers with direct print function / Carrying Case PictBridge-compliant printers BP-308, BP-315 Battery Pack CA-570 Compact Power Adapter BP-308, BP-315 Battery Pack...

  • Page 140: Optional Accessories

    Optional Accessories Call or visit your local retailer/dealer for genuine Canon video accessories. You can also obtain genuine accessories for your Canon camcorder by calling: 1-800-828-4040, Canon U.S.A. Information Center. Use of genuine Canon accessories is recommended. This product is designed to achieve excellent performance when used with genuine Canon accessories.
  • Page 141 WD-H34 Wide-converter This lens decreases focal length by a factor of 0.7, giving you a wide perspective for indoor shots or panoramic views. • When the Wide-converter is attached, a shadow may appear in the picture when you record with flash or assist lamp. FS-34U Filter Set Neutral density and MC protector filters help you to control difficult lighting conditions.
  • Page 142 This lightweight bag keeps the camcorder within easy reach without weighing you down or getting in the way. This mark identifies genuine Canon video accessories. When you use Canon video equipment, we recommend Canon-brand accessories or products bearing the same mark.

  • Page 143: Specifications

    Specifications OPTURA600 System Video Recording System Audio Recording System Television System Image Sensor Tape Format Tape Speed Maximum Recording Time (80 min. cassette) Fast Forward/Rewind Time LCD Screen Viewfinder Microphone Lens Lens Configuration Filter Diameter AF system Minimum Focusing Distance White Balance Minimum Illumination Recommended Illumination...
  • Page 144 Input/Output Terminals AV Terminal DV Terminal MIC Terminal Headphone Terminal USB Terminal Power/Others Power supply (rated) Power consumption (AF on) Operating temperature Dimensions (W x H x D) Weight (camcorder body only) CA-570 Compact Power Adapter Power supply Power consumption Rated output Operating temperature Dimensions...

  • Page 145: Product Codes

    Product Codes Provided Accessories Lens Cap CA-570 Compact Power Adapter BP-308 Battery Pack WL-D85 Wireless Controller MTC-100 Multi Cable IFC-300PCU USB Cable Optional Accessories BP-315 Battery Pack CG-300 Battery Charger TL-H34 Tele-converter WD-H34 Wide-converter FS-34U Filter Set WS-20 Wrist Strap SC-2000 Soft Carrying Case SC-1000 Soft Carrying Case SC-A50 Soft Carrying Case...

  • Page 146: Index

    Index 12bit audio ..... 105 9 Point AiAF ..... 87 Abroad, using the camcorder .
  • Page 147 Microphone level ....71 Mini video light ....49 Movies (memory card) .
  • Page 148 FOR THE UNITED STATES The warranty set forward below is given by Canon U.S.A., Inc. with respect to equipment purchased in the United States. The limited warranty is only effective upon presentation of your Bill of Sale or other proof of purchase.
  • Page 149 Video Heads which will be exchanged for a period of 3 months from the date of purchase. Labour: For a period of one year from the date of original purchase, labour will be provided free of charge by our Canon Service Facilities in Canada.

Table of Contents
