Cub CB-1034
Quick Installation Guide
Printer Overview
Front View
1. LED Indicators
2. LCD Display
3. Front Panel Command
Keys
4. Label Exit Point
5. Lower Front Cover
6. Media Cover Door
Rear View
1. FanFold Paper Slot
2. Centronics Interface
3. USB Interface
4. RS-232C Interface
5. A/C Power
6. GPIO Interface
7. SD Card Slot
8. Ethernet Interface
9. PS/2 Interface
10. AC Power Switch
Interior View
1. Ribbon take up spindle
2. Ribbon release button
3. Ribbon guide plate
4. Print head
5. Platen roller
6. Print head release lever
7. Media guide bar
8. Label roll guard
9. Label supply spindle
10. Ribbon supply spindle
11. Damper
12. Label guide
13. Z axis mechanism
adjustment knob
14. Print head pressure
adjustment knob
15. Print head mounting set
screw
16. Ribbon sensor
17. Media sensor
Advertisement
Related Manuals for Cub CB-1034
Summary of Contents for Cub CB-1034
- Page 1 Cub CB-1034 Interior View Quick Installation Guide 1. Ribbon take up spindle 2. Ribbon release button Printer Overview 3. Ribbon guide plate 4. Print head Front View 5. Platen roller 6. Print head release lever 1. LED Indicators 7. Media guide bar 2.
- Page 2 Front Panel Display Ribbon Installation 1. Lift open the 2. Install the ribbon 3. Thread the ribbon printer's Media Door. onto the ribbon supply through the ribbon Push the print head spindle. sensor slot and then release lever to open through the open space LED Indicators the print head...
- Page 3 Media Installation Label guide 1. Lift open the 2. Move the label roll 3. Place the roll of media printer's Media Door. guard horizontally to on the label supply Push the print head the end of label spindle spindle. Push the label roll release lever to open then flip down the until it is flush with the...
- Page 4 You can now enter the printer’s IP Address, Subnet Mask & Gateway. To enter the Your Cub CB-1024 is now ready to be installed on your host PC. Please see the value press the printer’s button. To advance to the next number press the Installing Windows Print Driver guide to complete printer installation on your host PC.
