Summary of Contents for NST Audio ID48X
- Page 1 ID48X Matrix Signal Processor User Manual Revision 1.0 www.nstaudio.com © NST Audio Ltd 2021...
-
Page 2: Table Of Contents
Contents EU Declaration of Conformity ............................3 Declaration of Conformity ............................4 Important Safety Instructions ............................5 Instructions De Securite Importantes ........................... 6 WEEE ................................7 ROHS ..................................... 7 Thank You ..................................8 Installation ..................................8 Overview ..................................9 Key Features ................................. 9 Unit Overview ................................10 D-Net Remote Control Application ..........................12 Technical Specifications ..............................13... -
Page 3: Eu Declaration Of Conformity
EU Declaration of Conformity This declaration is issued under the sole responsibility of the manufacturer. NST Audio Ltd Units 1& 2 Long Row Espersykes Farm Malton North Yorkshire England United Kingdom Declare that this declaration of conformity is issued under our sole responsibility and belongs to the following product:... -
Page 4: Declaration Of Conformity
Declaration of Conformity This declaration is issued under the sole responsibility of the manufacturer. NST Audio Ltd Units 1& 2 Long Row Espersykes Farm Malton North Yorkshire England United Kingdom Declare that this declaration of conformity is issued under our sole responsibility and belongs to the following product:... -
Page 5: Important Safety Instructions
Important Safety Instructions CAUTION: RISK OF ELECTRIC SHOCK. DO NOT OPEN. The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. -
Page 6: Instructions De Securite Importantes
Instructions De Securite Importantes ATTENTION: RISQUE DE CHOC ELECTRIQUE. NE PAS OUVRIR. Le symbole représentant un éclair fléché dans un triangle équilatéral a pour but d’alerter l’utilisateur de la présence d’une “tension dangeruese” non isolée à l’intérieur du boitier, pouvant ê t re d’une force suffisante pour constituer un risqué d’électrocution. Le point d’exclamation dans un triangle équilatéral a pour but d’alerter l’untilisateur de la présence d’instructions importantes concernant le fonctionnement et la maintenance, dans la documentation qui accompagne l’appariel. -
Page 7: Weee
WEEE Once your NST Audio product has reached the end of its useful life, please ensure that is recycled in a proper manner. "The WEEE Regulations 2013 are the UK interpretation of the EU WEEE Directive and aim to reduce the quantity of waste electrical and electronic equipment (WEEE) disposed of in the UK". -
Page 8: Thank You
Thank You Thank you for choosing an NST Audio product for your application. Please spend a little time reading through this manual, so that you can obtain the best possible performance from the unit. All NST products are carefully designed and engineered for cutting-edge performance and world-class reliability. If you would like further information about this, or any other NST product, please do not hesitate to contact us. -
Page 9: Overview
The ID48X runs at a fixed sampling rate of 96kHz. Front panel meters show levels of all inputs and outputs (plus mute states) and indication of remote control status is also provided. -
Page 10: Unit Overview
Unit Overview Front Panel Overview: 1. Input Meters: Real time LED input meters show level from maximum input level (clip) in 4-segments... Signal present, 6dB below clipping, 0dB/maximum input level and clip. If analogue input level is within 1dB of clipping, the red input Clip LED will illuminate to show this. 2. - Page 11 Rear Panel Overview: 1. Mains Power Inlet, Fuse and Power Switch: 3-pin IEC input, fused [5mm x 20mm, 3.15A, 250V, Anti-Surge (T)], 90-250VAC, 50-60Hz <40W. A spare fuse is located within the fuse holder – only replace with the correctly rated fuse! 2.
-
Page 12: D-Net Remote Control Application
Compatibility with Microsoft Windows, Apple Mac and Apple iPad too, you can control your system the way that suits you. USB connection (Microsoft Windows only) is also available on some devices, allowing quick connection to a single device. D-Net is available to download, free of charge, from the NST Audio website: nstaudio.com/software-downloads... -
Page 13: Technical Specifications
Technical Specifications Analogue Inputs – 4 Electronically balanced, pin 2 hot CMRR: >60dB @ 1kHz Maximum Level: >20dBu Input Impedance: 10kΩ balanced AES Inputs – 2 x 2 channel Transformer balanced, pin 2 hot AES Input Sample Rates : 8kHz to 192kHz AES Input s/n Ratio : 139dB Input Impedance : 110Ω... -
Page 14: Maintenance
This product comes with a warranty against defects in components and workmanship only, for a period of five years from the date of shipment to the customer. During the warranty period, NST Audio will, at its discretion, either repair or replace products that prove to be defective, provided that the product is returned, shipping prepaid, to an authorised NST Audio service facility.
