Instructions for Assembly & Installation
Thank you for choosing this KRUMMA-Gull 131 product from Krumma ehf.
KRUMMA-Gull 131
Package details: 130kg & 0,3m
Equipment delivery part list:
1 x
Instructions for Assembly & Installation (this document)
4 x
Posts
4 x
Sockets
1 x
Swing beam
2 x
Swings
2 x
Side plates
8 x
10x120mm Bolts
8 x
10,5x20mm Washers
8 x
10,5x25,5mm Washers
8 x
10mm Self locking nuts
8 x
Black Covers: Bottoms and tops
8 x
Red Covers: Bottoms and tops
8 x
8,4x16mm Washers
8 x
8x80mm Wood screws
4 x
8x30mm Bolts
4 x
8mm Selflocking nuts
16 x
10mm Flange nuts
Installers and Installation tools:
2 x
Installers are required to successfully install the equipment
1 x
Ratchet with 13mm, 15mm and 17mm sockets
1 x
13mm wrench
1 x
17mm wrench
1 x
Measuring tape
1 x
Soft head hammer
2 x
Shovel
3
Concrete
0,2m
3
Gravel
0,4m
3
Advertisement
Related Manuals for Krumma KRUMMA-Gull 131
Summary of Contents for Krumma KRUMMA-Gull 131
- Page 1 Instructions for Assembly & Installation Thank you for choosing this KRUMMA-Gull 131 product from Krumma ehf. KRUMMA-Gull 131 Package details: 130kg & 0,3m Equipment delivery part list: Instructions for Assembly & Installation (this document) Posts Sockets Swing beam Swings Side plates...
-
Page 2: Installation Instructions
Installation Instructions: Figure 1 displays assembly parts. 10x120mm Bolts 10,5x20mm Washers Swing beam Black covers 10,5x25,5mm Washers 10mm Self locking nuts 8x30mm Bolts 8mm Self locking nuts Post Red covers 8x80mm Wood Side plates 8,4x16mm Washers Swings 10mm Flange nuts Socket Assembly sequence: Attach sockets to posts with 10mm flange nuts using 15mm wrench. - Page 3 Placing of the equipment and foundation: Figure 2 displays the holes for the ground fasteners. All measurements are in mm. Dig holes as displayed in figure 2. Place 80mm of compressed gravel into all four holes. Place the equipment into the holes as figure 2 displays. The surface signage on the posts should be at surface level.
- Page 4 Safety: Figure 3 displays minimum space requirements, safety clearance and maximum fall height. Measurements are in mm. KRUMMA-Gull 131 is certified by Dansk Technologisk Institut according to EN1176. • The maximum fall height determines the fall protection surface. The surface must have •...
- Page 5 Maintenance: Impact protection surface: Maintain the impact attenuating adequately on a regular basis. • Keep the safety zone free from external obstacles. • Product: Use sal ammoniac soap to clean painting. Next option is to use white sprit but make sure to •...
