Model Number
686B61
Performance
Alarm Threshold(± 10 %)
Frequency Range(± 3 dB)
Hysteresis(% < Alarm Threshold)
Residual Vibration Level(Reference)
Residual Vibration Level(% Alarm Threshold)
MAVT(Sets Alarm Threshold to 2X actual vibration)
Transverse Sensitivity
Power On Delay(± 1 sec)
Startup Delay(± 1 sec or 1 min)(Time)
Startup Delay(x Alarm Threshold)
Startup Delay(Active)
Operational Delay(± 1 sec)
Relay(Type)
Relay(Capacity)
Relay(Latching)
Relay(Contacts)
Environmental
Temperature Range(Operating)
Temperature Range(Storage)
Overload Limit(Shock)
Humidity Range(Condensing)
Electrical
Power Required
Current Rating(Relay Closed)
Leak Current(Relay Open)
Electrical Isolation(Case)
Physical
Size (Hex x Height)
Weight
Mounting Torque
Mounting Thread
Sensing Element(Internal)
Housing Material
Sealing
Electrical Connector
Cable Length
Cable Termination
Electrical Connection Position
Cable Type
[2]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without
notice.
®
ICP is a registered trademark of PCB Group, Inc.
VIBRATION SWITCH
ENGLISH SI
0.25 to 5 in/sec pk 4.5 to 90 mm/s rms
420 to 60 kcpm 7 to 1000 Hz
3; 6; or 10 % 3; 6; or 10 %
Dependent or Independent [1]
Dependent or Independent
1 to 40 % 1 to 40 %
Enabled or Disabled Enabled or Disabled
<3 % <3 %
3 or 20 sec 3 or 20 sec
1 to 60 sec or 1 to 30 min 1 to 60 sec or 1 to 30 min
x2; x4; x8; Blocked x2; x4; x8; Blocked
Enabled or Disabled Enabled or Disabled
1 to 60 sec 1 to 60 sec
SPST, Form A or B SPST, Form A or B
MOSFET MOSFET
24 to 240 V AC/DC, 500 mA 24 to 240 V AC/DC, 500 mA
Latching / Non-Latching Latching / Non-Latching
Normally Open / Closed Normally Open / Closed
-40 to 185 °F -40 to 85 °C
-40 to 257 °F -40 to 125 °C
5000 g pk 49,050 m/s² pk
0 to 100 % 0 to 100 %
24 to 240 V DC/AC 50/60 Hz 24 to 240 V DC/AC 50/60 Hz
500 mA 500 mA
1 mA 1 mA
8 8
>10 Ohm >10 Ohm
1.25 in x 2.6 in 1.25 in x 66 mm
5.2 oz 148 gm
3 to 5 ft-lb 4 to 7 Nm
1/4-28 Female 1/4-28 Female
Piezoelectric Accelerometer Piezoelectric Accelerometer
Stainless Steel Stainless Steel
Molded Molded
Molded Integral Armored Molded Integral Armored
Cable Cable
10 ft 3 m
Blunt cut Blunt cut
Top Top
Polyurethane Polyurethane
OPTIONAL VERSIONS
[1]
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
[1]
EX
- Hazardous Area Approval- contact factory for specific approvals
[1]
Current Rating(Relay Closed)
[1] Cl I, Div 2, Groups A, B, C, D;
Hazardous Area Approval
Ex nL IICT3, AEx nA IICT3
[1] Power Required 10 to 30 VDC
Relay(Capacity) 10 to 30 VDC, 100 mA
[1]
[1]
M
[1] - Metric Mount
Supplied Accessory : Model M081A61 Mounting Stud 1/4-28 to M6 X 1 (1)
[1]
[1]
[1]
NOTES:
[1] USB Programmable - See configuration sheet supplied with switch for exact setting.
[2] See PCB Declaration of Conformance PS096 for details.
SUPPLIED ACCESSORIES:
Model 081A41 Mounting stud 1/4-28 socket head set screw brass tip stainless steel 5/8" long
(1)
Entered: AP Engineer: do Sales: EGY
Date: 9/4/2012 Date: 9/4/2012 Date: 9/4/2012
3425 Walden Avenue, Depew, NY 14043
Revision: A
ECN #: 39883
100 mA 100 mA
Cl I, Div 2, Groups A, B, C, D;
Ex nL IICT3, AEx nA IICT3
10 to 30 VDC
10 to 30 VDC, 100 mA
Approved: BAM Spec Number:
44915
Date: 9/4/2012
