Build Manual for "Clockerel" Electromechanical Wooden Geared Clock
Thank you for purchasing the "Clockerel" electromechanical clock kit from Wooden Gear Clocks UK. We called it
the "Clockerel" as it resembles a flightless bird of some kind, probably, but not exclusively, a Clockerel.
The aim of this manual is to make the construction of this kit enjoyable, safe and rewarding. The clock is
powered by 4 x D cell Alkaline batteries.
SAFETY
Always read and digest any safety instructions that came with your tools. Wooden Gear Clocks do not accept
any responsibility for any injuries incurred during the construction of this clock.
TOOLS
The tools required to carry out this build are as follows:
A bench vice (fitted with jaw protectors) is desirable but not essential.
An electric drill, preferably battery operated.
A square file, approximately ¼" and a flat file approximately 15mm wide.
A sharp chisel approximately 12mm wide.
Soldering iron, solder etc.
Rapid setting epoxy resin e.g. Araldite
PVA wood glue
Sanding Block
Shellac, color up to the customer.
Plastic "Scotchbrite" washingup pad. 1-2 required.
Aluminium oxide abrasive paper. Grade 80, 120 and 180.
