Matco Tools S3030 Instruction Manual

15W COB
Underhood Light
Soft padded Light bulbs pivot
aluminium hooks for independently
scratch proof grip to direct light as
needed
The new super bright Underhood Light for
powerful illumination of the entire engine bay.
Shines brighter, grips stronger & outlasts most
other lights!
15W COB Underhood Light
3 powerful COB lamps of 5W each
Light Output
Single button, user controlled light output for
maximized operating time. Choose between three
light sittings-high, medium & low
NR. OF LAMPS USED
LUMEN
RUN TIME 3 hours
Sturdy Construction
a. Aluminium extruded body with ABS coating.
Built to withstand the toughest of job site
conditions
b. Soft padded aluminium hooks resist wear and
provide scratch proof grip. Large gripping
surface provides larger contact for better
positioning when mounting the light
underhood, undercarriage or elsewhere
c. 3 light bulbs with sturdy polycarbonate lens to
withstand the toughest of job site conditions
d. Fully adjustable light head: bulbs can be
rotated 40° to provide the optimum light
angle depending upon job need
Expandable Length
(1200 mm - 1750 mm)
USB charging port
with LED charging
indicators
INTENSITY
HIGH MEDIUM LOW
3 2
1000 700 350
5 hours 7 hours
47 - 69 inch
Expandable Length
47 - 69 inch (1200 mm - 1750 mm)
This covers wide cars & trucks, making it a perfect
choice for mechanics working in automotive
shops or fleet maintenance
Power Source
LITHIUM-ION
RECHARGEABLE
Charging of Battery
Battery can be recharged using in-built USB
charging port protected by rubber bezel
Complete with USB cable and AC Power Adaptor
1
Charging Time
4 hours
FEATURES
BEAM
ANGLE
60°
(INCH)
47-21/32 × 3 × 2-3/8
INSTRUCTION MANUAL
S3030, REV B
Rechargeable
Battery
3.7V 5200 mAh
OPERATING TEMPERATURE
−5°C TO 40°C
(−23°F TO 104°F)
SIZE (L×H×D)
1210 × 75 × 60
RoHs
(MM)
