DK Custom DK-LPR-AX-CRV-22 Quick Start Manual

Curved axle mount license plate relo
Hide thumbs
1
2

Advertisement

Table of Contents

Curved Axle Mount License Plate Relo

Parts included:

1- Curved Axle Mount License Plate Bracket
1- Set of (4) Button Head fasteners with (8) flat & (4) lock washers, & (4) nuts

Instructions:

1. This License Plate Bracket that allows you to mount your license plate on the Left side.
Note:​ In the following step make sure to install the bracket flush against the swingarm with the
factory washer between the nut and the bracket.
2. Remove the retaining clip and axle nut, set aside for later use.
3. Depending on your year and model it may be necessary to remove your axle completely to
get the desired orientation of the Relocation Bracket. If this is necessary reference your service
manual for that portion of the installation.
3. Install the mounting arm in place and hand tighten the axle nut so the Mounting bracket does
not freely spin.
4. At this time make sure you have the arm at the angle you want your plate to be at. Tighten
to torque settings specified in your manual while making sure the bracket stays in place and
reinstall retaining clip.)
4. ​
I f you are using the optional Run/Brake Led reference the instructions supplied with that item
at this point.
Made in The USA
DK Custom Products
(​
P lease read all instructions before beginning install​

)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DK-LPR-AX-CRV-22 and is the answer not in the manual?

Questions and answers

Related Manuals for DK Custom DK-LPR-AX-CRV-22

Summary of Contents for DK Custom DK-LPR-AX-CRV-22

  • Page 1 Curved Axle Mount License Plate Relo  Made in The USA  DK Custom Products    (​ P lease read all instructions before beginning install​ Parts included: 1- Curved Axle Mount License Plate Bracket 1- Set of (4) Button Head fasteners with (8) flat & (4) lock washers, & (4) nuts Instructions: 1.
  • Page 2 5. Using the 4 supplied sets of bolts, nuts, and washers, attach your tag to the tag bracket. If not using the optional Led light you will want to center your license plate on the bracket. (There will be a small amount of the bracket sticking out on either side, this is normal and by design.) Torque to 15-20 ft-lbs.
