DK Custom DK-2-48-RSRS-BLK Instructions

INSTRUCTIONS
(Please read the entire sheet before beginning install)

Parts included:

2 Risers (powder coat black or raw aluminum finish)
4 Grade 8 Bolts
(these instructions are for both the 1" & 2" 48 Stealth Riser Extension Kits)

Installation Steps:

1. Place a towel or some other protection over gas tank and front fender
2. Remove the 4 bolts securing the handlebar Top clamp to the integral top tree (you may find it
helpful to have someone hold the handlebars in place for you while doing this)
3. Place riser extensions between the top tree bracket (the extensions are labeled L (left) and R
(Right)), and then set the handlebars into the curve of the risers extension. (the right side is the
side with your air cleaner)
4. Bolt the top clamp into place with the four bolts provided with the kit Make sure to use
thread-locker and to tighten to factory torque specifications. This is generally 30-40 ft pounds,
check your manual to verify the values for your bike.
The FUN PART! Now that your handlebars are higher, you may want to adjust them forward or
back. Have fun experimenting with the new look & improved comfort! Ride Safe!
Here is a link to "The Comfort Triangle" -
http://www.dkcustomproducts.com/how-to-set-your-bike-up-for-youthe-comfort-triangle-dk-tri-su.
htm
48 RISER EXTENSIONS KIT
Made in the USA!
