Summary of Contents for Trust Precision Viewer
- Page 1 Trust Precision Viewer Monitor TRUST PRECISION VIEWER MONITOR Instruction Manual Version 1.0...
- Page 2 Trust Precision Viewer Monitor Thank you Thank you very much for purchasing this product from the Trust range. We wish you hours of fun with it. Please read this manual carefully before using the product. Registration Register your purchase now at the Trust Internet site, www.trust.com, so that you are able to receive optimal guarantee and service support.
-
Page 3: Table Of Contents
Adjusting the contrast ...................... 7 6.2.3 Other settings ........................7 Energy saving ........................... 8 Troubleshooting..........................9 On-Site guarantee ........................12 7.1.1 Before you call the On-site Service Center..............12 Specifications ..........................13 Trust Customer Care Centers ...................... 14 10. On-Site Service Centers ....................... 15... -
Page 4: Introduction
This instruction manual is intended for users of the Trust Precision Viewer Monitor. Prior knowledge of computers is not necessary to install this product. If you have any questions, please consult one of the Trust Customer Care Centers. You can find more information about these Customer Care Centers on the last page of this electronic manual, as well as at the back of the quick installation manual. -
Page 5: Safety
Trust Precision Viewer Monitor 2. Safety General information Do not use the device in a damp environment, such as a bathroom, a damp basement, a swimming pool, etc. Do not try to repair the device yourself. If any of the following circumstances occur, remove the plug from the power socket and have the device repaired by qualified personnel: a) The cable or plug is damaged or worn. -
Page 6: Connecting The Monitor
Insert the 15 pin signal cable connector (B) to the 15 pin connection (A) at the back of the monitor and screw it firmly into place (not applicable for the Precision Viewer 17”). Insert the other 15 pin connector (C) into your computer's 15 pin VGA connection and screw it firmly into place. -
Page 7: Installing The Driver
Insert the CD-ROM into your CD-ROM drive. Select 'CD-ROM' to give the correct location of the driver. Select ‘Precision Viewer Excellence Series’ and click on 'Next' to continue. Follow the on-screen instructions to complete the installation. You will not have to restart your computer after completing the installation. -
Page 8: Operation And Making Adjustments
Trust Precision Viewer Monitor Windows 95 / 98 / ME: Click on the 'Adapter' tab. Select the desired frequency from the 'Refresh rate' list. Windows 2000: Click on the 'Monitor' tab. Select the desired frequency from the 'Refresh Frequency' list. -
Page 9: Adjusting The Brightness
Trust Precision Viewer Monitor 6.2.1 Adjusting the brightness Push button 3 to change the brightness. The value can be decreased using button 3 (M) and increased using button 4 (L). 6.2.2 Adjusting the contrast Press button 4 to change the contrast. The value can be decreased using button 3 (M) and increased using button 4 (L). -
Page 10: Energy Saving
Trust Precision Viewer Monitor Function 17” 19” Description Corrects the parallel distortion. Corrects the pin balance distortion. Removes vertical moiré (concentric circles or arches on the screen). Removes horizontal moiré. Corrects the top corner deflection. Corrects the bottom corner deflection. -
Page 11: Troubleshooting
Trust Precision Viewer Monitor Status Signal Power Refresh LED colour consumption time H-Sync. V-Sync. Video Pulse Pulse Active 17”: 80 Watt Green 19”: 130 Watt Stand-by No pulse Pulse Black <15 Watt <3 sec. Flashes green / screen yellow Suspend... - Page 12 Trust Precision Viewer Monitor Problem Cause Possible solution Image is wavy or moves. There is a device with a Remove or move the source of transformer or adapter nearby disturbance. Try the monitor at a (e.g. a radio, TV or different workplace.
- Page 13 You will be automatically informed of developments to your product and of other Trust products. You will also have the chance to win some spectacular prizes. If you still have any problems after trying these solutions, please contact one of the Trust Customer Care Centers.
-
Page 14: On-Site Guarantee
Trust Precision Viewer Monitor On-Site guarantee If you still have problems with your Trust monitor, then you can contact one of our On-site Service Centers. These are given at the back of the instruction manual. Conditions: • The guarantee is granted to the original purchaser of the product and last for a period of three years from the moment of purchase from an authorized supplier or distributor. -
Page 15: Specifications
Trust Precision Viewer Monitor 8. Specifications Precision Viewer 17” Precision Viewer 19” Screen size 17 inch 19 inch Viewable area 45.5 cm 45.4 cm Dot pitch 0.27 mm 0.26 mm Screen area 305 X 229 mm 352 x 264 mm... -
Page 16: Trust Customer Care Centers
Trust Precision Viewer Monitor 9. Trust Customer Care Centers Inhabitants of Great Britain and Ireland should contact: GB Office Internet www.trust.com From: E-mail support-uk@trust.com 9:30 - 17:00 +44-(0)1376-514633 Tel. +44-(0)1376-500000 Inhabitants of Italy should contact: Italian Office From: Internet www.trust.com... -
Page 17: On-Site Service Centers
Trust Precision Viewer Monitor 10. On-Site Service Centers England ServLab Ltd. E-mail servlabuk@btinternet.com Tel.: +44-208-9000 733 Fax: +44-208-9000 744 Italy ServLab SRL E-mail i@servlab.com Tel.: +39-041-509 3011 Fax: +39-041-509 3073 France ServLab E-mail f@servlab.com Tel.: +33-1-4591 9329 Fax: +33-1-4591 1710...
