Summary of Contents for Trust PRECISION VIEWER EXCELLENCE SERIES
- Page 1 Precision Viewer 17” -Excellence Series- PRECISION VIEWER 17” – EXCELLENCE SERIES – User’s manual Version 1.0...
-
Page 2: Thank You
Precision Viewer 17” -Excellence Series- Thank you Thank you very much for purchasing this product from the Trust range. We wish you hours of fun with it. Please read this manual carefully before using the product. Registration Register your purchase now at the Trust Internet site (www.trust.com) and you could win one of the fabulous prizes. -
Page 3: Table Of Contents
Precision Viewer 17” -Excellence Series- Contents Introduction....................2 Safety......................2 Installing the monitor ................... 3 Unpacking ....................3 Fastening the swivel-and-tilt base ............3 Positioning the monitor ................4 Connecting the monitor ................4 Installing the driver..................5 Windows 95 / 98 ..................5 Other operating systems ................ -
Page 4: Introduction
Precision Viewer 17” -Excellence Series- 1. Introduction This manual contains instructions for installing and operating the Precision Viewer 17” -Excellence Series. No prior knowledge is required for the installation and operation. This monitor is suitable for professional use in an office environment. The Precision Viewer 17”... -
Page 5: Installing The Monitor
Precision Viewer 17” -Excellence Series- 3. Installing the monitor 3.1 Unpacking The following items should be found in the packaging: • Monitor • Swivel-and-tilt base • Mains cord • This manual Please contact your dealer if anything is missing or damaged. Tip: Save the box for future transportation. -
Page 6: Positioning The Monitor
Precision Viewer 17” -Excellence Series- 3.3 Positioning the monitor Place the monitor in a convenient location near your computer. Position the monitor so that the top of the screen is no higher than eye level. Position the monitor directly in front of you at a comfortable reading distance (around 45 to 60 cm). -
Page 7: Installing The Driver
Precision Viewer 17” -Excellence Series- Plug the mains cord connection (B) to connection (A) on the monitor. Plug the other end of the mains cord (C) to your computer's mains supply connection (D). Switch on the computer. Note: If your computer does not have a mains connection for a monitor, plug the monitor directly into the wall socket. -
Page 8: Other Operating Systems
Precision Viewer 17” -Excellence Series- 4.2 Other operating systems No drivers are required for other operating systems, such as DOS, Windows 3.1x or Windows NT. The recommended setting is a resolution of 1024x768 and a refresh rate of 85Hz. 4.3 Setting the refresh rate Follow the instructions below to set your refresh rate in Windows 98: Go to the configuration window (Start - Settings - Configuration window). -
Page 9: Operation
Precision Viewer 17” -Excellence Series- 5. Operation 5.1 Control buttons on the monitor Figure 4: Frontal view of the monitor ‘ZOOM’ button. Press this button and rotate the button (D) to enlarge or reduce the image. ‘RECALL’ button. This button has 2 functions, namely: Switching off the OSD menu. - Page 10 Precision Viewer 17” -Excellence Series- Press the ‘ONE TOUCH OSD’ button (C) to obtain the OSD main menu. A menu like the one shown in Figure 5 will pop up. Figure 5: OSD main menu The OSD main menu is divided into 2 windows. The upper window displays the current resolution and refresh rate.
-
Page 11: Power Saving
Precision Viewer 17” -Excellence Series- Icon Function Description Corner Pin / For correcting angle deflection and a rotated display image. Rotation H-moire / For readjusting the horizontal and vertical moire. V-moire Degauss For demagnetising the display image. Color Control For adjusting the RGB value (manually) or colour temperature (6550K, 9300K). - Page 12 Precision Viewer 17” -Excellence Series- Status Signal Power Refresh LED colour Consumption time H-Sync. V-Sync. Video No pulse No pulse Black <5 Watt <15 sec. Yellow screen...
-
Page 13: Troubleshooting
Precision Viewer 17” -Excellence Series- 6. Troubleshooting If your monitor is not functioning properly, you may be able to solve the problem by locating the problem and possible solution in the following table. Problem Cause Possible solution No display image, Monitor is not switched on. - Page 14 Precision Viewer 17” -Excellence Series- Problem Cause Possible solution The picture is There is a device with a Remove or move the source of bouncing or a transformer or adapter disturbance. Try the monitor at a wave pattern is nearby (such as a TV, different workplace if necessary.
- Page 15 The wrong frequency will flash. Check your system or switch to a different resolution. If these suggestions are not of any help, consult the Trust Internet site at www.trust.com. Please contact your dealer if you still have problems after you have tried these solutions.
-
Page 16: Specifications
Precision Viewer 17” -Excellence Series- 7. Specifications Screen size 17 inch Viewable size 16 inch (40.5 cm) Dot pitch 0.27 mm Display area 330 x 245 mm Number of colours Infinite Maximum resolution 1280x1024 non interlaced Horizontal synchronisation 30 to 70 KHz Vertical synchronisation 50 to 150 Hz Bandwidth... -
Page 17: Warranty
90% of cases (24 hour service). The reaction time may be longer due to local accessibility, journey distance, transport over water and holidays. • Trust® Computer Products warrants to the original purchaser of this product, purchased from the authorised resellers or distributors, that it will be free from... -
Page 18: Service Centres
CRT, cables, connectors or controls), mistreatment of the product and/or opened/repaired by an unauthorised service person. • You can also read the general conditions of the warranty on our website: www.trust.com. Contact your nearest service centre for the service conditions that apply for you. 8.3 Service Centres Country:... - Page 19 Precision Viewer 17” -Excellence Series- Country: Contact: Benelux E-mail paul@ngp.nl Mail Dwarsdijk 4 5705 DM HELMOND The Netherlands +31-4925-23781 Phone +31-4925-22466 Germany Internet www.repair-center.de E-mail fleckenb@mus.de Mail Nordring 55-57 63843 NIEDERNBERG Germany +49-60-28944211 Phone +49-60-28944212 Spain Seltron S.L E-mail jose_luis@jet.es Mail C/Industria,44-46 08830 Sant Boi De Llobregat...
