Falconeyes RFL-3 Instruction Manual

E) 技术参数 Specifications:
型号Model no.：
RFL-3
灯管数量 No. of Tubes 3
1X22W 1X28 W 1X40W
灯管功率 Power
尺寸 Dimensions (LxWxH) 59x14x49cm
色温 Color Temperature
电压 Voltage
中心孔径 Central Aperture
重量 Weight 1.6kg
包含配件 Accessories Included
柔光面罩、相机支架 Diffusor, Camera Bracket(RFL-L)
布袋、相机支架
选购配件 Optional Accessories
Carrying Bag, Camera Bracket,(TMB-176L)
F) 使用注意事项 Attention
1.请按照本产品所标注电压选择电源。
2.不要在通电状况下装置或拆卸灯管，如需要拆卸灯管，请在关掉电源15分钟之后进行，以免被高温
烫伤。
3. 非专业人士，请勿随便拆卸，否则后果自负。
4. 使用环境应保持干燥、通风注意防潮防水。
5.产品表面有轻微的油渍及污渍请使用清洁布擦拭表面即可清除。
6.请避免硬物将其划伤以至影响使用效果。
7.使用产品时，请详细阅读说明书。
1.Please use the appropriate voltage labeled on the product.
2.Do not remove the fluorescent tube when the power is on.
3.Do not remove the fluorescent tube until the light is switched off for at least 15 minutes in order to avoid scald.
4.Since there can be high voltage inside the unit, Do NOT open or repair the unit yourself. If there is any defect, please
contact an experienced technician.
5.Keep the environment dry and ventilated when using the product. Do not leave or use the flash in humid or dusty
environment.
6.For best performance of tubes, maintain cleanliness of tubes by wiping the surface softly with clean cloth.
7.Do NOT apply pressure to the product.
8.Read this manual carefully before using the product.
3
RFL-2 RFL-1
2 1
1X22W 1X28 W 1X22W
45x14x38cm 28x12.5x28cm
5300K-5500K
AC220-240V 50Hzor AC110-120V/60Hz
Ф102mm
1.45kg 1.3kg
布袋 Carrying Bag
FM1304_RFL-3/2/1_Chinese_eng
RFL-3 RFL-2 RFL-1
环形荧光灯说明书
Ring Fluorescent Light Instruction Manual
RFL-3
感谢您选购锐鹰公司的产品！
如欲了解更多相关产品的信息，请联系您当地的经销商或访问我们的
网页。使用产品之前，请先仔细阅读说明书。
Thank you for purchasing FalconEyes' products.
For further details of our related products, please contact your
local distributor or visit our webpage at www.falconeyes.com.hk
Thank you.
Please read this manual carefully before using this product.
使用说明书
E-mail: info@falconeyes.com.hk
Websit: www.falconeyes.com.hk
RFL-2 RFL-1
