Jefferson JEFTBX06A User Manual

INTRODUCTION
•
6 Drawer tool chest
•
Modular storage compatibility: top section
•
Ideal for garage tool storage
•
Locking mechanism for added security
•
Ball bearing drawer sliders for smooth operation
•
Maximum storage load: 90kg
•
Drawer liners included for tool & drawer protection
OPERATION & MAINTENANCE
•
Do not open more than one loaded drawer at a time
•
Open and close the drawers smoothly - do not slam or
force them
•
Close the lid and lock the drawers before moving the
chest
•
Do not stand on the chest or use it to support heavy
weights
•
Do not mount the chest on a vehicle
•
Do not exceed the rated drawer storage load capacity
or the overall load capacity for the chest
•
Ensure the chest is kept clean and dry, free from dirt,
grease and debris
•
Clean and wax / polish regularly to avoid rust and
corrosion
•
Keep tools clean and organised
•
Store in a dry environment
•
Lubricate the top and bottom channels of the drawer
slides at least twice a year
•
Contact Jefferson Tools for further advice on repair,
maintenance and spare parts for this equipment
SPECIFICATIONS
Model Number:
Drawer 1 (Top):
Drawer 2
Drawer 3
Drawer 4
Drawer 5
Drawer 6 (Bottom)
Maximum Overall Storage Load:
Overall Dimensions:
NW:
JEFTBX06A
Dimensions: 171 x 267 x 48mm
Dimensions: 570 x 267 x 48mm
Dimensions: 570 x 267 x 48mm
Dimensions: 570 x 267 x 48mm
Dimensions:
570 x 267 x 48mm
Dimensions:
570 x 267 x 74.5mm
90kg
660 x 307 x 377mm
23.5kg
www.jeffersontools.com
6 DRAWER TOOL CHEST
Modular Storage: Top Section
Max Load 8kg
Max Load 8kg
Max Load 8kg
Max Load 10kg
Max Load
10kg
Max Load
15kg
JEFTBX06A
USER GUIDE
v.1.1
