Jefferson JEFTBX05A User Manual

INTRODUCTION
•
5 Drawer mobile tool chest
•
Modular storage compatibility: bottom section
•
Ideal for garage tool storage
•
Locking mechanism for added security
•
Ball bearing drawer sliders for smooth operation
•
Maximum storage load: 250kg
•
Drawer liners and top mat included for tool & drawer
protection
•
Supplied with smooth running castors
OPERATION & MAINTENANCE
•
Do not open more than one loaded drawer at a time
•
Open and close the drawers smoothly - do not slam or
force them
•
Close the lid and lock the drawers before moving the
chest
•
Do not stand on the chest or use it to support heavy
weights
•
Do not mount the chest on a vehicle
•
Do not exceed the rated drawer storage load capacity
or the overall load capacity for the chest
•
Ensure the chest is kept clean and dry, free from dirt,
grease and debris
•
Clean and wax / polish regularly to avoid rust and
corrosion
•
Keep tools clean and organised
•
Store in a dry environment
•
Lubricate the top and bottom channels of the drawer
slides at least twice a year
•
Contact Jefferson Tools for further advice on repair,
maintenance and spare parts for this equipment
SPECIFICATIONS
Model Number:
Drawer 1 (Top):
Drawer 2
Drawer 3
Drawer 4
Drawer 5 (Bottom)
Maximum Overall Storage Load:
Overall Dimensions:
NW:
JEFTBX05A
Dimensions:
570 x 406 x 74.5mm
Dimensions: 570 x 406 x 74.5mm
Dimensions: 570 x 406 x 74.5mm
Dimensions: 570 x 406 x 153.5mm
Dimensions: 570 x 406 x 153.5mm
250kg
680 x 458 x 698mm (without casters)
46kg
www.jeffersontools.com
5 DRAWER MOBILE TOOL CHEST
Modular Storage: Bottom Section
Max Load
20kg
Max Load 20kg
Max Load 20kg
Max Load 30kg
Max Load 30kg
680 x 458 x 812mm (with casters)
JEFTBX05A
USER GUIDE
v.1.1
