Optical Time Domain Reflectometer
1. Unpacking Inspection
Before you receive this instrument, please carefully check the product appearance and quality according to
the packing list to find the possible damage caused in the transport process. If the package is found
damage, please keep the original packing materials, give an immediate notice to the freight company and
contact the supplier to solve this problem.
The product package should be provided with the power cord, adapter, analysis software installation CD,
user manual, etc together with the instrument, for detail, see the packing list. If the materials in the packing
box are discovered incomplete, please contact your supplier agent to solve them in a timely manner.
Table 1-1 Basic components of 5302 series Optical Time Domain Reflectometer
ITEM
Host machine 5302 Optical Time Domain Reflectometer
Standard
accessories
2. Overview of Instrument
5302 series handheld optical time domain reflectometer (OTDR) is a new generation of intelligent optical
measuring instrument designed for the optical fiber communication system testing by zhe Electronics
Technology Co., Ltd.. This product is mainly used to measure the parameters of optical fibers and cables,
such as length, loss, and connection quality, etc.; it can realize the accurate positioning of event points and
fault points, and can be widely used in the construction, maintenance testing and emergency repair of the
optical fiber communication systems as well as the research, production and production measurement of
optical fibers and cables and so on. This product can provide you with the highest performance of solutions
for installation and construction of fiber optic network construction and the subsequent fast and efficient
maintenance and troubleshooting testing.
SHENZHEN TRANSCOM TECHNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China.
Tel: +86 755 88278677 / Fax: +86 755 26029402 / Web: www.sz-transcom.com
NAME
Power cord
Power adapter
User manual
CD (containing 5302 simulation analysis
software)
Engineering plastics packing box
QUANTITY
1
1
1
1
1
1
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 5302 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Transcom 5302 Series

Summary of Contents for Transcom 5302 Series

  • Page 1 Engineering plastics packing box 2. Overview of Instrument 5302 series handheld optical time domain reflectometer (OTDR) is a new generation of intelligent optical measuring instrument designed for the optical fiber communication system testing by zhe Electronics Technology Co., Ltd.. This product is mainly used to measure the parameters of optical fibers and cables, such as length, loss, and connection quality, etc.;...

  • Page 2: Internal Battery

     Internal battery Inside the instrument is the 5302 Series OTDR dedicated lithium battery. To give full play to the performance of the battery, please charge the instrument with the internal battery and use up the electric quantity before using this instrument, and then charge the battery.
  • Page 3 The size of reflection depends on the refractive index difference and boundary surface flatness. SHENZHEN TRANSCOM TECHNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China. Tel: +86 755 88278677 / Fax: +86 755 26029402 / Web: www.sz-transcom.com...
  • Page 4 Fig. 2-2. Fig. 2-2 Chart of non-reflective event SHENZHEN TRANSCOM TECHNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China. Tel: +86 755 88278677 / Fax: +86 755 26029402 / Web: www.sz-transcom.com...
  • Page 5 3.2 5302 OTDR Power Supply Interface 5302 Series OTDR power port is on the right side of the instrument. Input requirement: 19V±1V，≥2 A, Polarity: positive in the center. Fig. 2-4 Schematic diagram of 5302 power port Please use the adapter provided by the manufacturer to charging this instrument, otherwise, it may cause damage to the instrument.
  • Page 6 4.1 Menu structure and functional description 5302 Series OTDR has the simplest and quick operation way in the industry. The whole main user interface contains only 6 menu options. Through the optimized operating mode, it can conform to the user’s daily habits;...
  • Page 7 Fig. 2-7 Schematic diagram of main window menu bar Fig. 2-7 shows the schematic diagram of the six main menu of 5302 Series OTDR， which respectively “waveform operation”, “parameter setting”, “curve save”, “file operation”, “system information”, “help” from left to the right.
  • Page 8  Modify the value of the item where the cursor is under the system information sub-interface;  Use to page up under the help information interface. SHENZHEN TRANSCOM TECHNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China. Tel: +86 755 88278677 / Fax: +86 755 26029402 / Web: www.sz-transcom.com...
  • Page 9 SHENZHEN TRANSCOM TECHNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China. Tel: +86 755 88278677 / Fax: +86 755 26029402 / Web: www.sz-transcom.com...
  • Page 10 OTDR operating interface and display the main operation window. When the instrument is switched on, press and hold this button for about 1 second to switch off the instrument. 4.3 Description of 5302 Series OTDR test parameters and setting method Correct setting the measurement parameters of the instrument is necessary for the accurate measurement of the optical fibers.
  • Page 11 Setting method: Under the parameter setting interface, move the cursor to the option Test Item via the navigation key , and press the key to select SHENZHEN TRANSCOM TECHNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China. Tel: +86 755 88278677 / Fax: +86 755 26029402 / Web: www.sz-transcom.com...
  • Page 12 SHENZHEN TRANSCOM TECHNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China. Tel: +86 755 88278677 / Fax: +86 755 26029402 / Web: www.sz-transcom.com...
  • Page 13 SHENZHEN TRANSCOM TECHNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China. Tel: +86 755 88278677 / Fax: +86 755 26029402 / Web: www.sz-transcom.com...
  • Page 14 A and B can be switched and the positions of them can be modified, so that customers can observe the detailed characteristics of each fiber link distance. SHENZHEN TRANSCOM TECHNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China. Tel: +86 755 88278677 / Fax: +86 755 26029402 / Web: www.sz-transcom.com...
  • Page 15 B to the top of the reflection event. Read the reflection loss value of the reflection event through the Ref position. SHENZHEN TRANSCOM TECHNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China. Tel: +86 755 88278677 / Fax: +86 755 26029402 / Web: www.sz-transcom.com...
  • Page 16 ：indicate that this event point is the end of optical fiber. SHENZHEN TRANSCOM TECHNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China. Tel: +86 755 88278677 / Fax: +86 755 26029402 / Web: www.sz-transcom.com...
  • Page 17 5.3 Zooming and shift of waveform curve To facilitate users to carry out manual analysis on the tested curve, when the test of 5302 Series OTDR is over, the menu key is placed on horizontal zoom-in and zoom-out...
  • Page 18 OTDR test function. 7. File management operation The 5302 Series OTDR file management operations are described as follows, mainly including file save, reading, copy, deletion, etc.. 7.1 Save the waveform files When the automatic measurement or manual measurement is over, save the measurement curve.
  • Page 19 , press the and the system information setting window will pop up. SHENZHEN TRANSCOM TECHNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China. Tel: +86 755 88278677 / Fax: +86 755 26029402 / Web: www.sz-transcom.com...
  • Page 20 Figure 2-19 5302 Help Information Navigation key : used to page down, page up. SHENZHEN TRANSCOM TECHNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China. Tel: +86 755 88278677 / Fax: +86 755 26029402 / Web: www.sz-transcom.com...

  • Page 21: Chapter 3 Maintenance And Troubleshooting

    3.1.3 Cleaning of instrument screen and calibration The display of 5302 series OTDR is a 3.5-inch color LCD with touch screen. Do not click on the LCD with a sharp object when in use, otherwise, it may cause damage to the LCD screen.
  • Page 22 2. The channel is not set channel. correctly. SHENZHEN TRANSCOM TECHNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China. Tel: +86 755 88278677 / Fax: +86 755 26029402 / Web: www.sz-transcom.com...
  • Page 23 The instrument is forbidden to remove without permission in the application process; otherwise, it  may lose the qualification for warranty permanently. SHENZHEN TRANSCOM TECHNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China. Tel: +86 755 88278677 / Fax: +86 755 26029402 / Web: www.sz-transcom.com...
  • Page 24 Test and display the loss of any two points in the optical fiber link and fiber attenuation constant;  SHENZHEN TRANSCOM TECHNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China. Tel: +86 755 88278677 / Fax: +86 755 26029402 / Web: www.sz-transcom.com...
  • Page 25 @1300nm Range accuracy ± (1m + sampling interval +0.005% × distance) Attenuation measurement ±0.05 dB/dB accuracy SHENZHEN TRANSCOM TECHNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China. Tel: +86 755 88278677 / Fax: +86 755 26029402 / Web: www.sz-transcom.com...
  • Page 26 4.2 5302 Series OTDR Purchase Information Standard  Table 4-2 Standard list of 5302 Series OTDR SHENZHEN TRANSCOM TECHNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China. Tel: +86 755 88278677 / Fax: +86 755 26029402 / Web: www.sz-transcom.com...
  • Page 27 Note: OTDR Standard Interface Type can be chosen from FC / UPC and FC / APC. SHENZHEN TRANSCOM TECHNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China. Tel: +86 755 88278677 / Fax: +86 755 26029402 / Web: www.sz-transcom.com...
