Quick Reference for SEABOB F5 S
Left Controlgrip
Display
Information display
Power
(in % of maximum power)
Water temperature
Diving depth
Set maximum diving depth
Charge display
Water temperature
Charge symbol
Warning symbol
• Motor temperature warning ("motor overheated")
➞ Power is limited to Power Level 2
• Accumulator temperature warning ("accumulator overheated")
➞ Power is limited to Power Level 2
• Warning: Accumulator error ("accumulator error")
➞ Emergency operation! Power is limited to Power Level 2 or motor stops
• Warning: Impeller locked ("impeller locked") ➞ Motor stops
Workshop symbol
• Motor, accumulator or system defect ➞ Contact manufacturer or specialist dealer!
Right Controlgrip
Red button
Blue button
Trigger
Green button
Silver button
Display
Connection Port
Speed range +
set maximum power (red dot)
Accumulator charge state
Accumulator temperature
(in°C)
Power Level
Accumulator charge state
Accumulator temperature
(in°C)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SEABOB F5 S
Summary of Contents for SEABOB F5 S
- Page 1 Quick Reference for SEABOB F5 S Trigger Right Controlgrip Green button Silver button Left Controlgrip Red button Blue button Display Connection Port Display Information display Speed range + Power set maximum power (red dot) (in % of maximum power) Accumulator charge state...
- Page 2 To complete the charging process, first pull the mains plug from the mains socket. Only then should you disconnect the connector from the connection port. Danger of short circuit! Note: The SEABOB can only be switched on from Off mode or switched off into Off mode using a connected and active charger.
- Page 3 Power decreases by one Power Level ➞ the power (also during operation) with every tap of the button 4. Push Trigger against Controlgrip SEABOB starts (minimum power of Power Level 1) ➞ 5. Release Trigger SEABOB stops ➞ Note: Always observe accumulator charge state. When the accumulator is discharged to approx. one third of...
- Page 4 Select / change: (On mode) Move cursor: Trigger Trigger Power: - Motor: Power: + On / Stop * Menu item "exit" selected Action: = User = SEABOB Buttons: = red = blue = green = silver Technical changes reserved. As of 07/2014...
