IT-Reference 7 - Owner's Manual
you about upgrades or other vital information.
Registering the product also upgrades your
warranty from one year to five years.
s I
a F e t y
W
a n d a r n I n g s
Please read and observe all of the safety and
operating instructions before the IT-Reference 7
is operated. Retain these instructions for future
reference.
◊ Do not disassemble or modify in any way.
No user-serviceable parts inside
◊ Keep away from moisture and avoid
excessive humidity
◊ Do not allow liquids or foreign objects to
enter the unit Household lighting equipment
may not be connected to the IT-Reference
7 because their sockets are not designed
for use with symmetrical power and may
present a shock hazard. We recommend
that only audio, video and computer
processing equipment be connected to the
IT-Reference 7.
The IT-Reference 7 should be serviced by
qualified service personnel when:
◊ The power supply cord or plug has been
frayed or cut.
◊ Objects have fallen or liquid has spilled into
the unit.
◊ The IT-Reference 7 has been exposed to
rain or other moisture.
◊ The IT-Reference 7 does not appear to
operate normally, or exhibits a marked
change in performance.
◊ The IT-Reference 7 has been dropped, or
the enclosure damaged.
-  -
n F o r m a t I o n
The IT-Reference 7 requires that a safety ground
be present for proper operation. Any attempt
to operate the IT-Reference 7 without a safety
ground is considered improper operation and
will invalidate the warranty.
P s
oWer ource
The power source to which the IT-Reference
7 is connected should be adequate for use at
7 Amps. Typical household outlets will have a
current capacity of at least 10 - 15 amps.
P
lacement
The IT-Reference 7 is manufactured with
four rubber feet for placement on any table,
cabinet, shelf, or floor. These rubber feet may
be easily removed with a standard Philips screw
driver when rack mounting adjacent to other
components. Because of the IT-Reference 7's
internal shielding, placement or proximity to
other components is not critical, and the IT-
Reference 7 does not produce any appreciable
heat under standard use. The IT- Reference 7
may also be rack mounted in a standard 19"
rack by attaching the rack ears. These rack ears
(contained within the plastic rack kit package)
mount flush with the back portion of the IT-
Reference 7's front panel. They are attached
to the chassis by removing the () countersunk
screws on each forward-side of the chassis top
cover. Each rack ear is installed with (3) pan-
head Philips screws contained within the IT-
Reference 7 rack mounting kit. The third screw
used for each rack ear is for the center hole,
located towards the rear and aids in stabilizing
the unit when rack mounted.
c
o n n e c t I o n
ac c r
able outIng
Once the IT-Reference 7 is placed, its AC cord's
female end must be plugged into the male IEC
