Summary of Contents for Tesla TI5200 GPU-24
- Page 1 Power Anytime, Anywhere Tesla TI5200 GPU-24 ™ User Manual Built Smart...Proven Tough Tesla Industries, Inc. 101 Centerpoint Blvd. New Castle, DE 19720 (302) 324-8910 Phone (302) 324-8912 Fax www.teslaind.com www.tesla1.com...
- Page 2 Conditioners, manufactured by Tesla™ Industries, Inc., are able to safely and effectively charge any AGM, Lead Acid battery. The Tesla™ GPU’s and chargers are voltage and current regulated to 0.01% (dual loop). The charging voltage is calibrated, by Tesla™, to 28.6 volts and is pure dc (no power line ripple).
- Page 3 Chemical Family/Classification: Tesla™ Industries, Inc. Sealed Lead Battery Synonyms: Sealed Lead Acid Battery, VRLA Battery Telephone: For information, contact Tesla™ Industries, Inc. Customer Service Department at 302-324-8910 Manufacturer's Name/Address: Tesla™ Industries, Inc 101 Centerpoint Blvd. 24-Hour Emergency Response Contact: New Castle, DE 19720-4180...
- Page 4 Supersedes: AF ECO #: 1002195 Inorganic lead and sulfuric acid electrolyte are the primary components of every battery manufactured by Tesla™ Products. There are no mercury or cadmium containing products present in batteries manufactured by Tesla™ Products. IV. FIRST AID MEASURES Inhalation: Sulfuric Acid: Remove to fresh air immediately.
-
Page 5: Table Of Contents
3.10 – Transporting Unit 3.11 – Regulated 28.5 Vdc Ground Power 15-16 3.12 – Operating with a Digital Volt/Amp Meter 3.13 – Regulated AC Power 3.14 – Charging Unit 3.15 – Circuit Breaker Switch 3.16 – Changing Circuit Breaker Switch TI5200 GPU-24... - Page 6 7.8 – Maximum Output Current Section 8 – Optional Accessories 8.1 – Shipping Case 8.2 – GPU Protective Covers 8.3 – Digital Volt/Amp Meter(TI3100A) 8.4 – GPU Tires 8.5 – Cobra™ DC Replacement Contacts and Tools Repair Request Form TI5200 GPU-24...
- Page 7 Maximum MΩ megaohm Minimum Micro Power Unit NEMA National Electrical Manufacturers Association Ω power factor power factor correction root-mean-square Total Harmonic Distortion TMDE Test, Measurement, & Diagnostic Equipment Unmanned aerial vehicle Volts, Alternating Current Volts, Direct Current watts TI5200 GPU-24...
-
Page 8: Section 1 - Safety Review
The following symbols will appear within the warning triangles to alert the user to the specifi c type of danger or hazard. General Warning Electrical Hazard Explosion Hazard Fire Hazard Battery Warning Guard from Moisture Figure 1.2.1 – Different types of hazard and caution symbols TI5200 GPU-24... -
Page 9: Hazards
150°F (65°C). This protects the unit from overheating and damage. If the unit shuts down, move the unit into a cooler environment such as shade or air conditioning when possible. Perform a full function test, after the unit has been allowed to cool, prior to use. TI5200 GPU-24... -
Page 10: Section 2 - Product Overview
This manual contains the complete operating instructions and procedures for the TI5200 GPU-24 ground power unit. The TI5200 GPU-24 provides dc electrical ground power for aircraft flight line and maintenance ground support operations. The unit is designed to provide 24 Vdc electrical power output for aircraft engine starting and 24 or 28.5 Vdc electrical support for ground maintenance, avionics/electrical trouble shooting... -
Page 11: Front Panel Overview
Air Intake Fan – Provides active transport of unit. cooling for internal components. DVAM Interface Receptacle – Allows direct connection of Tesla™ DVAM LED Charge Status Meter – Displays (Digital Volt/Amp Meter). current battery charge status when pressed. TI5200 GPU-24... -
Page 12: General Specifications
• Three Phase 200-260 Vac 50/60 Hz • 20 amps @ 208 Vac - 4160 Watts • Requires 30 amp service (contact Tesla™ Industries for receptacle information) Power Cell: • Dry, High Rate Discharge, Rechargeable , Maintenance-free DC Output: •... -
Page 13: Physical Dimensions
Ensure that ports are clear at all times. When the TI5200 GPU-24 is plugged into 208 Vac 60 Hz ac power, the internal cooling system will efficiently regulate unit temperature regardless of load. At room temperature (+77°F) the exhaust air will not exceed the ambient temperature by more than 5°F. -
Page 14: Operating Positions
Product Overview 2.7 – Operating Positions The TI5200 GPU-24 can be operated in both the horizontal (Figure 2.7.1) and vertical (Figure 2.7.2) positions as shown. Make sure that the airflow is not obstructed from air intake (figure 2.7.3) and outlet (Figure 2.7.4). -
Page 15: Push To Test" Button And Led Status Indicator
The voltage will drop from NOTE 28.60 to 28.10 volts (±0.10). When a load greater than 2 amps is applied, the unit will return to normal operation. Figure 2.8.1 - Pushing to Test STATUS STATUS STATUS Full Charge Half Charge No Charge TI5200 GPU-24... -
Page 16: Section 3 - Operating Procedures
1200 - 1500 peak starting amps 40-50% charged 1500 - 1800 peak starting amps 50-60% charged 1800 - 2100 peak starting amps 60-70% charged 2100 - 2400 peak starting amps 70-80% charged 2400 - 3000 peak starting amps 80-100% charged MINIMUM CHARGE TI5200 GPU-24... -
Page 17: Temperature Specifications
If the unit shuts down, move the unit into a cooler climate, such as shade or air conditioning when possible. Perform a full function test prior to use after the unit has been allowed to cool. TI5200 GPU-24... -
Page 18: Environmental
If the unit is exposed to signifi cant moisture, preventive measures and precautions shall be taken to: B. Minimize moisture entering forward inlet and outlet cooling fan vent ports Figure 3.7.1 – TI5200 GPU-24 with TI7000-104 Protective Rain Cover TI5200 GPU-24... -
Page 19: Normal Functional Test Procedures
Check Unit for Evidence of Damage Check for dents, punctures, case distortion or misalignment, and cracked or loose connec tors. If no damage is evident, proceed to the next step. If damage is evident, contact Tesla™ Industries, Inc. Figure 3.8.2 – Damaged Unit... - Page 20 If unit is left charging after the batteries are fully charged, the unit will enter a standby mode. The voltage will drop from 28.60 to 28.10 volts (±0.10). NOTE When a load greater than 2 amps is applied, the unit will return to normal operation. TI5200 GPU-24...
-
Page 21: Pre-Operation
3.10 – Transporting Unit The TI5200 GPU-24 has a telescoping handle that makes rolling the unit easy. For transporting on uneven ground, axle extensions should be added to the unit. For use on sand, balloon tires should be installed on the unit (see Optional Accessories). -
Page 22: Regulated 28.5 Vdc Ground Power
Line up the plug with the receptacle. Push forward while rotating the T-handle one full turn clockwise. The unit is now ready to safely transfer power. Figure 3.11.1 Attaching DC Power Cable to TI5200 GPU-24 Connecting DC Power Cable To Vehicle or Aircraft Line up the NATO plug or aviation dc plug pins and push it in. -
Page 23: Operating With A Digital Volt/Amp Meter
2,000. The DVAM 3100A indicates the aircraft or vehicle’s current demand. Integrated with the Tesla™ GPU power supply, the DVAM is a valuable tool for troubleshooting Figure 3.12.1 DVAM 3100A and system checks. -
Page 24: Regulated Ac Power
Plugging in with AC Power When the TI5200 GPU-24 is plugged into ac power, the output is 28.5 volts. This voltage allows the system to recondition and recharge the vehicle’s battery(ies). It is also an optimum voltage for powering avionics and lighting on most aircraft. -
Page 25: Charging Unit
3.15 – Circuit Breaker Switch The TI5200 GPU-24 comes equipped with a circuit breaker switch on the front faceplate. This switch controls ac power input only, It does not control the dc output power to the aircraft or vehicle. Whenever the unit is plugged into an aircraft or vehicle, it is supplying dc power. -
Page 26: Changing Circuit Breaker Switch
Figure 3.16.6 Switching Figure 3.16.7 Circuit Breaker ON Figure 3.16.5 Circuit Breaker OFF Circuit Breaker ON 4. If the fans and LED bar graph do not operate, check ac outlet for power. TI5200 GPU-24... -
Page 27: Section 4 - Post Operation
Section 4 – Post Operation 4.1 – General Although the TI5200 GPU-24 has been ruggedized and made weather resistant within the scope of unit’s intended use, it is essential that good general care be taken to maintain unit in good operating condition and to maximize unit’s operational life. - Page 28 Power cells should only be charged by either the TI5200 GPU’s internal charger and the ac power cord furnished with the equipment, or when connected to aircraft’s external dc power receptacle. Figure 4.3.2 Proper and Improper Charging Methods TI5200 GPU-24...
-
Page 29: Section 5 - Unit Care And Maintenance
Do not cut, crush, or drag the input or output power cables when handling the unit. Always inspect cables prior to use. If no damage is evident, proceed to the next step. If damage is evident, contact Tesla™ Customer Service. Do not attempt to use any other type of power cables other than the Tesla™ cables included with the unit. -
Page 30: Unit Servicing
Ensure proper packaging when returning the unit. Transport the unit only in a sturdy shipping crate or Tesla™ Shipping Case. It is important to enclose the Repair Request Form. Seal the crate on all sides and return it to Tesla™ at the address listed below. Please contact Tesla™ Customer Service at (302) 324-8910 with any questions or concerns. -
Page 31: Section 6 - Troubleshooting And Faq
5. Will a Tesla™ Turbo Start™ spool up a turbine engine? Nothing will start a turbine engine faster or safer than the right Tesla™ Turbo Start™. Not only will it eliminate hot starts, but it will extend the life of your starter, your engine and your battery while reducing maintenance. The Turbo Start™ senses the impedance from the starter/generator. - Page 32 Unit should never be allowed to discharge fully. In-fi eld use, it receives a dc back charge directly from a running engine. When not in use, unit should be plugged into ac power (outlet) all the time. Tesla™ systems will retain 80% of their capacity after one year of storage.
-
Page 33: Basic Usage/Operation Questions
Reset breaker by pressing red button. Reconnect ac and dc connections to the unit. (Plug in ac line cord on military unit.) The unit should power up automatically. If the breaker continues to trip, return the unit to Tesla™ Industries for repair. TI5200 GPU-24... -
Page 34: Basic Troubleshooting
If LEDs still do not illuminate, Please contact Tesla™ Customer Service at (302) 324-8910. 2. Unit has no output dc or ac Units cells completely dead. Do a function check with digital meter, input or both. - Page 35 Switch breaker to ON position. Reconnect unit to cables and run. If LEDs still do not illuminate, Please contact Tesla™ Customer Service at (302) 324-8910. 8. Unit does not put out 28.5 Unit is not plugged in. Plug unit into ac power source to volts dc power.
-
Page 36: Section 7 - Performance Data
These differences, however, are considered insignifi cant and are not individually accounted for. Ground Support and Aircraft Instrument Variations: The data shown in the performance charts do not account for instrument tolerance differences or inaccuracies. TI5200 GPU-24... -
Page 37: Temperature Conversion Chart
91.4 66.0 150.8 -32.0 -25.6 33.8 34.0 93.2 67.0 152.6 -31.0 -23.8 35.6 35.0 95.0 68.0 154.4 -30.0 -22.0 37.4 36.0 96.8 69.0 156.2 -29.0 -20.2 39.2 37.0 98.6 70.0 158.0 -28.0 -18.4 41.0 38.0 100.4 71.0 159.8 TI5200 GPU-24... -
Page 38: Output Voltage
1200 * * * * * * * * * * * * * * * * * * * * (-29 C Temp) SECONDS Calculations based on actual test data at Pratt-Whitney Canada on 30 March 1992. TI5200 GPU-24... -
Page 39: Section 8 - Optional Accessories
Section 8 – Optional Accessories 8.1 – Shipping Case The optional Shipping Case is the safest way to transport the TI5200 GPU-24. This custom case weighs 95 lbs and comes equipped with side handles and locking latches. TI7000-175 Length: 54.5”... -
Page 40: Cobra™ Dc Replacement Contacts And Tools
A rugged combination of advanced composite materials and corrosion-resistant alloys make each plug maximized for durability and connectivity. To extend the life of the Cobra™ Connector included with your unit, replacement contacts, posts, noses and tools can be ordered through the Tesla™ Customer Service. TI2005-238 TI2005-078 Cobra™... -
Page 41: Repair Request Form
Email: _______________________________________________________________________________________ Purchase Order #: ______________________________________________________________________________ Model #: ____________________________________ Serial #: ________________________________________ Model #: ____________________________________ Serial #: ________________________________________ Shipping method to Tesla™: ______________________________________________________________________ Description of shipping package: ________________________________________________________________ Description of problem: _________________________________________________________________________ _________________________________________________________________________________________________ _________________________________________________________________________________________________ _________________________________________________________________________________________________ Return to Tesla™ 101 Centerpoint Boulevard, New Castle, DE 19720 Attention: Repair Department... - Page 42 Tesla™ 101 Centerpoint Blvd. New Castle, DE 19720 USA Tel: 302-324-8910 Fax: 302-324-8912 9475 Double R Blvd., Suite 2 Reno, NV 89521 Tel: 775-622-8801 Fax: 775-622-8810 www.teslaind.com ♦ www.tesla1.com...
