Fujitsu Plasmavision P42HCA11WH Specifications

42” high resolution.
Hide thumbs


Advertisement

Advanced Video Movement
and Increased Image Clarity
P42HCA11WH
Display Type
Screen Size
Dimensions
Weight
Brightness
Pixel Count
Aspect Ratio
Displayable Colors
Contrast Ratio
Video Standards Supported
Video Inputs
Audio Inputs
Computer Inputs
Viewing Angle
Horizontal kHz
Vertical Hz
Power Source
External Control
Operating Temperature
Relative Humidity
EMC Regulations:
Safety Regulations:
Specifications and design subject to change without notice for further improvement.
AC type plasma display panel
36.3" W x 20.5" H (42" diagonal)
40.8" W x 25.2" H x 3.8" D
62.8 lbs
2
1000 cd/m
1024 x 1024
16:9
16.77 million colors
1000:1
NTSC, PAL, SECAM,
4.43NTSC, PAL-60
Optional video board sold separately
3 inputs L, R
15-pin, 5 x BNC
160 degrees
15.62 - 80.00
50.0 - 120.0
110 - 240 AC, 50/60 Hz
RS-232C
32F to 104F degrees
20 to 90 percent (not condensing)
FCC part-15 Class A, ICES-003 Class A,
AS/NZS3548 Class A
UL 6500, CSA22.2 No. 950 (C-UL)
Fujitsu General America, Inc. 353 Route 46 W. Fairfield, NJ 07004
Tel: (888) 888-3424 Fax: (973) 575-2194
www.plasmavision.com
Fujitsu's AVM Digital
Video Processor
Fujitsu General has
developed the AVM
(Advanced Video
Movement) digital
video processor
which virtually elim-
inates motion artifacts and flicker,
improves vertical resolution and
reproduces natural movement with
ease.
The processor's built-in line dou-
bler converts NTSC signals and
uses different types of processing
for moving and still pictures, yield-
ing smoother images with more
natural movement and without visi-
ble scan lines.
High Resolution Digital Multi-
conversion System
Achieves high picture quality with
the HRDMC (High Resolution
Digital Multi- conversion) system.
Developed by Fujitsu General,
HRDMC is the original system of
converting a variety of input signals
and still PC images and optimizing
them for the Plasmavision
SlimScreen display monitor.
Adjust-To-Movement Mode
Enhances natural movement,
improves vertical resolution and vir-
tually eliminates flickering by pro-
cessing and retaining fields within
still and moving pictures.
Automatic Phase Adjustment
Automatically detects and adjusts
horizontal signals using the newly
developed digital PLL (Phase Lock
Loop). This high precision automat-
ic phase adjustment function
achieves optimum display of PC
signals.

Advertisement

   Related Manuals for Fujitsu Plasmavision P42HCA11WH

   Summary of Contents for Fujitsu Plasmavision P42HCA11WH

  • Page 1

    EMC Regulations: Safety Regulations: Specifications and design subject to change without notice for further improvement. Fujitsu General America, Inc. 353 Route 46 W. Fairfield, NJ 07004 AC type plasma display panel 36.3” W x 20.5” H (42” diagonal) 40.8” W x 25.2” H x 3.8” D 62.8 lbs...

  • Page 2: Advanced Features

    Lighting of Surfaces) technology, which discharges the electrodes in the plasma panel in a more efficient manner than conventional plasma monitors to achieve significantly higher brightness and definition. Fujitsu's newly developed APLC (Advanced Peak Luminance Control) system provides improved contrast and brightness through advanced rib materials and phosphors for enhanced panel brightness to a remarkable 1000 cd/m 2 without affecting product life.
