- Page 1 Better Water LLC 4” x 40” Spiral Wound Ultra Filter System Operator Manual rev. Apr 2015...
- Page 2 Better Water LLC. All rights reserved. The content of this manual is the intellectual property of Better Water LLC. It is furnished for the express use by Better Water LLC, their customers and dealers, for informational use only for operation, service, and internal training.
- Page 3 ” ” ” ” Models and Specifications UF17000 UF25500 UF34000 UF42500 UF51000 Models Capacity GPM Number of Ultra Filters Operating 95 lbs 141 lbs 175 lbs 222 lbs 269 lbs Weight 4" x 40" sanitary sleeve design Ultra Filters 90% - 95%...
- Page 4 Visit our website to see our complete product line of water purification products! www.betterwater.com Better Water LLC; 698 Swan Dr; Smyrna, TN 37167; www.betterwater.com...
-
Page 5: Table Of Contents
4” x 40” Ultra Filter System Operator Manual TABLE OF CONTENTS Our Company ……………………………………………………………………………………... 01 - Contact Us ……………………………………………………………………………………….. 01 - Technical Phone Support ………………………………………………………………………. 01 - Technical Support Info Online …………………………………………………………………. 01 - Specific Contacts ………………………………………………………………………………... 02 Introduction ………………………………………………………………………………………… 02 Warnings ………………………………………………………………………………………….. - Page 6 4” x 40” Ultra Filter System Operator Manual Visit our website to see our complete product line of water purification products! www.betterwater.com Better Water LLC; 698 Swan Dr; Smyrna, TN 37167; www.betterwater.com rev. Apr 2015...
-
Page 7: Our Company
4” x 40” Ultra Filter System Operator Manual Better Water LLC is a leading integrated manufacturer of water treatment equipment and components for the industrial, commercial and institutional Company markets. Located in Smyrna, Tennessee, Better Water LLC continues its history... -
Page 8: Specific Contacts
- Order Form - Return Goods Authorization Request Form Introduction The Better Water LLC 4” x 40” Ultra Filter System is manufactured to the utmost quality. With proper operation, maintenance, and care, this device should give you years of reliable service. -
Page 9: Warnings
9. Do not operate this unit in an environment where temperatures may be below 50 F or above 10. This device should not be used for purposes outside the device’s stated applications, specifications or limitations. Better Water LLC; rev. Apr 2015 Page 3 of 22... -
Page 10: General Requirements And Specifications
2. Electrical requirements: None 3. Drain requirements: Must facilitate 3-5 gpm. 4. Floor space: This unit is normally assembled at Better Water LLC and mounted to the wall surface. Requirements: Approx. 12” (depth-from wall) x 50” (width-along the wall) x 72” (height- up the wall). -
Page 11: Models
The first four numbers in the serial number denote the year and month the device was manufactured. In the example above the unit, was produced in 2015, in the month of March. Better Water LLC; rev. Apr 2015 Page 5 of 22... -
Page 12: Product Description
By-Pass Valve Outlet Pressure Gauge Inlet Pressure Gauge Outlet Valve Inlet Valve Sample Sample Port Port Product Flow-Meter Reject Valve Reject Flow-Meter Ultra Filter Housings Drain (four filter model shown) Port Better Water LLC; rev. Apr 2015 Page 6 of 22... -
Page 13: General Operation
* Location of these two valves is based on the left-to-right or right-to-left orientation of the system flow. 4. Open the REJECT VALVE. 5. Verify that the reject flow is 5% to 10% of product flow. Reject Valve Better Water LLC; rev. Apr 2015 Page 7 of 22... -
Page 14: Monitoring Procedures
* Do not over tighten the reject needle valve in the closed position as this can damage the needle valve. * This is done to prevent draining the storage tank dry during after- hours recirculation. Better Water LLC; rev. Apr 2015 Page 8 of 22... -
Page 15: Valves Legend And Operation
By-Pass Valve Prevents water from being filtered * CLOSED during normal operation Reject Valve Allows reject water to flow to drain. * OPEN during normal operation, but CLOSED during recirculation. Better Water LLC; rev. Apr 2015 Page 9 of 22... -
Page 16: Disinfecting Overview
6% household bleach is 60,000 ppm Sodium Hypochlorite Better Water LLC recommends using IRON FREE bleach. Care should be taken to select iron free bleach because many discount or generic brands will have high iron content. Iron will be harmful to the equipment and shorten its lifespan. - Page 17 5. Slowly open and close the sample ports a few times during the disinfect rinse process to allow these ports to be rinsed. Better Water LLC; rev. Apr 2015 Page 11 of 22...
-
Page 18: System Maintenance: Changing The Membranes
4” x 40” Ultra Filter System Operator Manual SYSTEM MAINTENANCE: Changing the Membranes Better Water LLC recommends that the membranes be changed every 3 years, unless otherwise dictated by, bacteria/endotoxin testing, and/or higher Delta-P pressure across the system. Before starting you will need the following: a. -
Page 19: Service Help: Ultra Filter System
PLHOPA00448 Current models are equipped with Stainless Steel Membrane Housings, whereas older models have Fiberglass Membrane Housings. See NEXT PAGE for parts list specific to the type of housing utilized. Better Water LLC; rev. Apr 2015 Page 13 of 22... -
Page 20: Membranes, End-Caps, O-Rings, And Adapters
Product Adapter for Fiberglass Housing EQFHOO02009 Membrane and Adapter Subassembly EQSUBUF002 - includes 4”x40” Sanitary/Full-Fit Membrane and adapters Pictures do not reflect the size of the item in relation to the other pictures Better Water LLC; rev. Apr 2015 Page 14 of 22... -
Page 21: Related Consumable Items
EQSUBUF001 * For Membrane + Adapters Kit for Fiberglass Housing use part number EQSUBUF002 Pictures do not reflect the size of the item in relation to the other pictures Better Water LLC; rev. Apr 2015 Page 15 of 22... -
Page 22: Trouble-Shooting Guide
Delta P at the initial adjustment (typically 20-30 psi, for tank-feed qualification with zero 2. Membranes are fouled systems with no demand). demand 3. Membranes exceed 2. Perform a disinfect recommended change out time Better Water LLC; rev. Apr 2015 Page 16 of 22... -
Page 23: Limited Warranty Terms And Conditions
Buyer shall be responsible for all travel expenses and freight charges at all times. f. Better Water LLC shall have no obligation to repair or replace any defective part if buyer fails to follow the procedure set forth in “HOW TO OBTAIN A REPLACEMENT PART UNDER LIMITED WARRANTY”. - Page 24 Damage to or caused by filters/membranes or other replacement parts not purchased from Better Water LLC or damage caused by modification, alteration, repair or service of the equipment or any of its parts by anyone other than Better Water LLC or its expressly authorized representatives.
-
Page 25: Appendix A, Sample Quality Assurance Checklist
(if used) PSI Post-4 x 40 (if used) Product Flow in GPM Reject Flow in GPM Loop Return Flow in GPM (if used) Loop Return Pressure (at Pressure Bypass) Technician's Initials Better Water LLC; rev. Apr 2015 Page 19 of 22... -
Page 26: Appendix B, Calculations & Conversions
Formula: Gallon * 128 = Ounces Example: 1 gal * 128 = 128 ounces OUNCES to GALLONS Formula: Ounces / 128 = Gallons Example: 128 ounces / 128 = 1 Gallon Better Water LLC; rev. Apr 2015 Page 20 of 22... -
Page 27: Calculation For Area Of Pipe Volume
The above flow rates should be set with all dialysis machines running. c. If bicarb or acid makeup water is required, both should have the proper flow controls to maintain flow velocity. Better Water LLC; rev. Apr 2015 Page 21 of 22... - Page 28 4” x 40” Ultra Filter System Operator Manual Better Water LLC; rev. Apr 2015 Page 22 of 22...
