Fujitsu Stylistic ST5021D Specifications page 2

Tablet pc


Fujitsu recommends Microsoft
Tablet PC Edition 2005 for Mobile Computing.
Operating Systems
Bundled Software
Microsoft Office OneNote™ 2003, Fujitsu Display Controls, Fujitsu Hot Key
Utility, Fujitsu Security Application Panel, Adobe
Note: Microsoft Office OneNote™ requires product activation
Software on CD
Depending upon your optional Tablet Dock configuration, you may also
receive the following: Sonic RecordNow!, InterVideo
WinDVD Creator Plus
Key Specifications
400 MHz FSB)
10.4" XGA TFT indoor/outdoor (Reflective FL) display
Electromagnetic (Active)
System Memory
256 MB minimum, two DIMM slots available; maximum memory to 2 GB
(1 GB x 2)
Memory Type
DDR 333MHz; 200-pin SO DIMM
Hard Drive
80 GB, 60 GB, or 40 GB ATA 100, 4200 rpm shock-mounted hard drive
Video Controller
Integrated 32-bit 3D/2D gfx core with up to 64 MB dynamic video memory
SigmaTel STAC9753A AC'97 Rev 2.3 compliant, 20-bit audio; built-in
microphone; headphone, microphone, and stereo line-in jacks
download); 10/100/1000 Base-T/TX Ethernet
Optional integrated Wi-Fi 802.11a+b/g wireless LAN; Atheros Super AG
supports 108 Mbps; diversity antenna
Two USB 2.0, Infrared port (IrDA 1.1-compatible, 4 Mbps), external monitor,
modem (RJ-11), Ethernet (RJ-45), IEEE 1394, wireless IR keyboard receivers,
and system interface connector
(Optional) Trusted Platform Module (TPM); dedicated SmartCard reader slot;
Fujitsu Security Application Panel; Kensington™ lock slot
PC Card Slots
One Type I or Type II slot; 32-bit PC CardBus architecture
Media Slot
One shared slot for MemoryStick and Secure Digital (SD) card.
Battery (Options)
Standard lithium ion (6-cell: 10.8V, 4800 mAh); rated up to 6.0 hours
(51 WHr capacity)
High-capacity lithium ion (9-cell: 10.8V, 7200 mAh); rated up to 9.0 hours
(77 WHr capacity)
AC Adapter
Auto-sensing dual voltage support, 100-240V AC; DC 16V, 3.75A
Standard battery: 12.77"(h) x 8.66"(w) x .82-.88"(d); approximately 3.5 lbs.
High-capacity battery: 13.51"(h) x 8.66"(w) x .82-.88"(d); approximately 3.9 lbs.
Operating temperature
Non-operating temperature
Service & Regulatory Information
Agency Approval
Emissions: EN55022 (CISPR22) Class B; FCC 15, Class B; FCC15C, 15.247;
EN 300-328; ICES-003; Canada RSS-210
Immunity: EN55024 (1998); EN 301-489-17 V.1.1.1 (2000-9)
Safety: UL and cUL Listed, UL 1950, 3rd edition; TuV T-Mark, EN60950
Telecom: FCC Part 68; IC CS-03
One-year or three-year International Limited Warranty
support; Fujitsu Premium Care Service Plans available
Visit or call 1-877-372-3473 for a complete listing of
Fujitsu accessories
XP Tablet PC Edition 2005
M Processor Ultra Low Voltage 733 (1.10 GHz, 2 MB L2 cache,
V.90 modem (software upgradeable to V.92 via driver
41°F to 95°F (ambient temperature); 20%
to 85% relative humidity, non-condensing
5°F to 140°F; 8% to 85% relative humidity,
Reader, MS Reader
WinDVD 5, InterVideo
; 24/7 technical
Fujitsu Computer Systems Corporation
1) Optional feature 2) Accessible capacity may be less due to
formatting, applications, and backup utilities. 3) The internal
modems on all Tablet PCs from Fujitsu Computer Systems
Corporation are only qualified for use with telephone systems in
selected countries, including the United States and Canada. For
a list of certified countries, please check http://www.comput- 4) Actual speeds over U.S. tele-
phone lines vary, and are less than 56Kbps due to the current
FCC regulations and line conditions. 5) Battery life estimates
reflect the results of Ziff Davis Business Winstone 2001
BatteryMark 1.0 as performed upon systems with maximum
battery life settings enabled. Actual battery life will vary based
on screen brightness, applications used, features selected,
power management settings, battery conditioning, and other
customer preferences. CD, DVD, CD-RW, or hard drive
usage may also have an impact on battery life. 6) Service and
warranty turnaround time may vary by country and product.
International warranty valid only for products purchased in
North, Central, and South America.
Fujitsu and the Fujitsu logo, are registered trademarks of Fujitsu
Limited. Stylistic is a registered trademark of Fujitsu Computer
Systems Corporation. Intel, the Intel Inside logo, Pentium, and
Intel SpeedStep are trademarks or registered trademarks of
Intel Corporation or its subsidiaries in the United States and
other countries. Microsoft and Windows are registered trade-
marks of Microsoft Corporation. Atheros is a registered trade-
mark and Super AG is a trademark of Atheros
Communications, Inc. All other trademarks mentioned herein
are the property of their respective owners. Product description
data represents Fujitsu design objectives and is provided for
comparative purposes; actual results may vary based on a vari-
ety of factors. Specifications are subject to change without
© 2004 Fujitsu Computer Systems Corporation. All rights
FPC58-1301-01 12/04
