- Page 1 View metadata, citation and similar papers at core.ac.uk CORE brought to you by provided by CiteSeerX www.embeddedARM.com TS-ENC720 Enclosure Manual ©Jun, 2009...
-
Page 2: Table Of Contents
GETTING STARTED WITH TS-ENC720 RUGGED METAL ENCLOSURE TABLE OF CONTENTS 1 OVERVIEW.........................3 2 GETTING STARTED......................3 2.1 Handling the Boar Safely.......................3 2.2 Setup and Installation Instructions..................3 2.3 Setup Tools..........................4 2.4 Setup Procedures........................4 2.5 Disconnecting AC Power.......................4 3 COMPONENTS........................4 3.1 TS-782...........................4 3.2 Front and Rear Panels ......................4 3.3 Standard Headers and Connectors..................5... -
Page 3: Overview
TS-7200 family and 8-38 VDC input for the TS-7800 to +5VDC as required by the SBC. The TS-ENC720 Rugged Enclosure provides extra functions, including power conversion and DB9 breakouts of the internal COM ports or additional I/O. Additional features include: Supports TS-7200 family and TS-7800 ✔... -
Page 4: Setup Tools
✔ COMPONENTS TS-782 The TS-782 is the board inserted in to the TS-ENC720 that provides the internal SBC with 2 DB-9 ports and 5VDC power regulation. Front and Rear Panels The TS-ENC720 front panel is shown on the first page of this manual. -
Page 5: Standard Headers And Connectors
Request to Send Clear to Send Note The COM1 port on the TS-ENC720 is the default port used for system console. The RC-DB9 cable must be connected to COM1 in order to have a Linux console via any terminal emulator. -
Page 6: Ts-782 Routing/Connectors
GETTING STARTED WITH TS-ENC720 RUGGED METAL ENCLOSURE Table: DB-9 Pin-out for DIO, A/D, and COM DB-9 COM3 COM2 (TS-7200 & TS- COM2/COM3 (TS- COM2/COM3 (DIO) 7250 MAX197 A/D) 7250 & TS-7800 10 (RS-232) pin On-board A/D) DIO_0 DIO_1 DIO_2 DIO_3... -
Page 7: Product Specifications
RUGGED METAL ENCLOSURE PRODUCT SPECIFICATIONS Dimensions The TS-ENC720 enclosure dimensions are 2.5" x 4.375" x 5.375" Cabling The enclosure includes the following cables for use with the TS-72XX/TS-7800 SBCs: All internal ribbon cables to make connections between the various 10-pin headers ✔... -
Page 8: Further References
Number July 11, 2008 Initial Release July 15, 2008 Format changes June 1, 2009 Updated mailing address APPENDIX B: ENCLOSURE VIEWS TS-ENC720 shown with optional TS-7200 SBC, TS-CAN1 peripheral board; included cables and TS-782 peripheral board © Jun, 2009 www.embeddedARM.com... -
Page 9: Appendix C: Contact Technologic Systems
GETTING STARTED WITH TS-ENC720 RUGGED METAL ENCLOSURE APPENDIX C: CONTACT TECHNOLOGIC SYSTEMS 16525 East Laser Drive Fountain Hills, AZ 85268 TEL 1.480.837.5200 FAX 1.480.837.5300 www.embeddedARM.com support@embeddedARM.com Call us Monday-Friday, from 9 am to 5 pm, Arizona-USA time; or email us at any time.
