Read this manual carefully before installing, operating or servicing this equipment. It's the responsi-
bility of the employer to ensure this manual is read by the operator. Please preserve this manual.
This document is issued with Product Serial No
Operation and Maintenance Guide
PW - 200
Descriptions
Pneumatic Pressure Washer - 200 Bar
IMPA Number
59 08 51
Advertisement
Table of Contents
Related Manuals for Teryair PW-200
Summary of Contents for Teryair PW-200
- Page 1 PW - 200 Models Descriptions IMPA Number PW-200 Pneumatic Pressure Washer - 200 Bar 59 08 51 Read this manual carefully before installing, operating or servicing this equipment. It’s the responsi- bility of the employer to ensure this manual is read by the operator. Please preserve this manual.
-
Page 2: Table Of Contents
Operation and Maintenance Guide Pneumatic Pressure Washer Page 2 Table of Contents Introduction Technical Data Operating Instructions Un Packing Assembly & Diassembly Safety checks before and after operating the High Pressure Washer Troubleshooting Maintenance Diassembly and Re-assembly for PW-200 Bill of Materials for PW-200 Exploded View for PW-200 Exploded View pf High Pr. Pump PW200 Bar 17 Test Certificate Of Materials, Performance 18 Eu Declaration Of Conformity 19 Warranty Certificate FF-MM-311-REV - 01... -
Page 3: Introduction
Page 3 Introduction Teryair Pneumatically Operated High Pressure Cleaners are designed for heavy duty cleaning operations in hazardous environments. These Pneumatic High Pressure Cleaners ensure safe cleaning of hazardous areas where inflammable gases & liquid exists. These heavy duty high pressure cleaners are used for removing Dirt, salt, rust deposits from Ship Decks / floors, Paint &... - Page 4 Operation and Maintenance Guide Pneumatic Pressure Washer Page 4 Warning Warning Use only for high pressure cleaning, do not use Eye and face and ear protection must be worn at for any other application. all times during operation of the High Pressure Washer.
-
Page 5: Un Packing
Operation and Maintenance Guide Pneumatic Pressure Washer Page 5 Un Packing Identify all the components as shown earlier, contact your supplier if any parts are missing or dam- aged. Be aware that minor visual differences may be noticed between actual motor/frame/pump and High pressure hoses because this components vary depending on the model ordered. - Page 6 Operation and Maintenance Guide Pneumatic Pressure Washer Page 6 Plug (Red Colour) For Transportation Purpose Only To Replace With Breathing Cap (Shown As Above) Breathing Cap Fill lubricating oil Make Sure to fill Oil in the pump as shown below befor start. Make Sure that the fitted oil plug is removed.
-
Page 7: Safety Checks Before And After Operating The High Pressure Washer
Cleaning solution injection • Turn on the water supply. All Teryair high pressure washers have a fa- Starting the High Pressure Washer cility of injection of Cleaning Fluids to aid in the cleaning process.There are several brands •... - Page 8 Operation and Maintenance Guide Pneumatic Pressure Washer Page 8 Storage • Disconnect the gun from the high pressure hose and the hose from the pump. • Hold gun vertically and depress trigger to re- move all residual water from the gun and lance. •...
-
Page 9: Troubleshooting
Operation and Maintenance Guide Pneumatic Pressure Washer Page 9 Troubleshooting Serial No Causes Remedial Action A loose connection The motor does not turn after energizing Check connections and retry Low voltage Check voltage and verify correct and re try The motor hums but does not turn Pump is stuck Service Pump see Maintenance section Pump is sucking air along with water... -
Page 10: Maintenance
Operation and Maintenance Guide Pneumatic Pressure Washer Page 10 Maintenance Servicing the Pump Follow instructions in “Shutting Down” section earlier in the manual. Dis assemble the hoses and the air hose from the High Pressure Washer and Air motor respectively. FF-MM-311-REV - 01... -
Page 11: Diassembly And Re-Assembly For Pw-200
Operation and Maintenance Guide Pneumatic Pressure Washer Page 11 Diassembly and Re-assembly for PW-200 g. Unscrew Hex bolt (17) with Washer (18) a. Shut off air supply and allow residual Pres- from Bracket for FRL (8) to remove FRL sure to bleed off. -
Page 12: Bill Of Materials For Pw-200
Operation and Maintenance Guide Pneumatic Pressure Washer Page 12 Bill of Materials for PW-200 Illustration Part Number Description PW-200 Number 637 98 11 TROLLEY COMPLETE 637 98 24 AIR MOTOR 637 98 25 HIGH PRESSURE UNIT 637 21 04-R COUPLING... -
Page 13: Exploded View For Pw-200
Operation and Maintenance Guide Pneumatic Pressure Washer Page 13 Exploded View for PW-200 DETAIL A DETAIL B FF-MM-311-REV - 01... - Page 14 Operation and Maintenance Guide Pneumatic Pressure Washer Page 14 Exploded View Detail-A for PW-200 DETAIL A FF-MM-311-REV - 01...
- Page 15 Operation and Maintenance Guide Pneumatic Pressure Washer Page 15 Exploded View Detail-B for PW-200 DETAIL B FF-MM-311-REV - 01...
-
Page 16: Exploded View Pf High Pr. Pump Pw200 Bar
Operation and Maintenance Guide Pneumatic Pressure Washer Page 16 Exploded View pf High Pr. Pump PW200 Bar Bill Of Material High Pressure Pump - PW200 Bar Illustration Part Illustration Part Description Description Number Number Number Number CAP FOR PRESSURE 6429501 PUMP BODY 6429515 REGULATOR... -
Page 17: Test Certificate Of Materials, Performance
Operation and Maintenance Guide Pneumatic Pressure Washer Page 17 TEST CERTIFICATE OF MATERIALS, PERFORMANCE DATE MODEL NUMBER PART DESCRIPTION & S.NO. We Hereby Certify That The Above Referenced Product Has Tested And Inspected In Accordance With Our Standard Test Pro- cedures And Meets The Specifications For Material And Performance Values As Published In Our Literature. -
Page 18: Eu Declaration Of Conformity
Palghar – 401208, Maharashtra, India. CE certification registration no – C E 16832 Issued by – BMQR Certifications Pvt Ltd. www.cemarking-india.com Valid Till – 03/11/2021 Signed for and on behalf of TERYAIR EQUIPMENT PVT. LTD. Place of Issue: Date: FF-MM-311-REV - 01... -
Page 19: Warranty Certificate
Teryair; (vii) the issue with a Product is directly or indirectly attributable to, or directly or indirectly results from or arises out of, compliance with any design, specification or other specific requirement of Dealer/End User;...
