SERVICE MANUAL
COMPACT DISC
STEREO SYSTEM
SYSTEM
NSX-SZ1
• This Service Manual contains information about the diference between NSX-SZ1
(HS) and NSX-SZ1 (HR). If requiring other information, see Service Manual of
NSX-SZ1 (HR, HT, EZ), (S/M Code No. 09-009-433-8R1).
NSX-SZ1
BASIC TAPE MECHANISM : ZZM-2 APR1NC
BASIC CD MECHANISM : KSM-213 CDM
CD
SPEAKER
CASSEIVER
CX–NSZ1
SX-NSZ1
S/M Code No. 09-00A-433-8S1
HS
REMOTE
CONTROLLER
RC–AAS08

Advertisement

loading
Need help?

Need help?

Do you have a question about the NSX-SZ1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aiwa NSX-SZ1

Summary of Contents for Aiwa NSX-SZ1

  • Page 1 CONTROLLER NSX-SZ1 CX–NSZ1 SX-NSZ1 RC–AAS08 • This Service Manual contains information about the diference between NSX-SZ1 (HS) and NSX-SZ1 (HR). If requiring other information, see Service Manual of NSX-SZ1 (HR, HT, EZ), (S/M Code No. 09-009-433-8R1). S/M Code No. 09-00A-433-8S1...

  • Page 2: Specifications

    All manuals and user guides at all-guides.com SPECIFICATIONS <FM tuner section> <Compact disc player section> Tuning range 87.5 MHz to 108 MHz Laser Semiconductor laser (λ =780 nm) Usable sensitivity (IHF) 13.2 dBf Antenna terminals 75 ohms (unbalanced) <Speaker system SX–NSZ1> Speaker system 1 way, bass reflex <AM tuner section>...

  • Page 3: Electrical Main Parts List

    All manuals and user guides at all-guides.com ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C127 87-010-759-080 C-CAP,U, 0.1-25F C128 87-010-759-080 C-CAP,U, 0.1-25F 87-A21-756-010 IC,LA4629 C129 87-010-180-080 C-CER 1500P 87-A21-381-040 C-IC,LA9235M C130 87-010-180-080 C-CER 1500P 87-A21-591-010...
  • Page 4 All manuals and user guides at all-guides.com REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C405 87-012-286-080 CAP, U 0.01-25 C800 87-010-829-080 CAP, U 0.047-16 C406 87-012-286-080 CAP, U 0.01-25 C801 87-010-403-080 CAP, ELECT 3.3-50V C407 87-012-286-080 CAP, U 0.01-25 C802...
  • Page 5 All manuals and user guides at all-guides.com REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION CNA351 8A-NEC-634-010 CONN ASSY,8P RPB C517 87-010-759-080 C-CAP,U, 0.1-25F CNA401 8A-NEC-633-010 CONN ASSY,3P (PH) C518 87-012-268-080 C-CAP,U 330P-50 B F101 87-A91-249-010 FUSE,630MA 250V F 50F C523 87-010-248-040...
  • Page 6 All manuals and user guides at all-guides.com WIRING – 1 (MAIN / FRONT) – 6 –...
  • Page 7 All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM – 1 (MAIN 1/3) – 7 –...
  • Page 8 All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM – 2 (MAIN 2/3: TUNER SECTION) – 8 –...
  • Page 9 All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM – 3 (MAIN 3/3: CD SECTION) – 9 –...
  • Page 10 All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM – 4 (FRONT) – 10 –...
  • Page 11 All manuals and user guides at all-guides.com IC DESCRIPTION IC, M38B57MCH - E258FP Pin No. Pin Name Description — Not connected. I-HOLD Hold input. I-TRAY SW CD tray SW AD input. I-D-SW CD door open/close AD detection input (Not used). I-KEY2 Key AD input 2.
  • Page 12 All manuals and user guides at all-guides.com Pin No. Pin Name Description I-WRQ (CD) CD WRQ input. O-CL (CD) CD IC control clock output. O-DATA (CD) CD IC control data output. I-TUNE/IFC Tuner SD detection input/Tuner IF count input. AVSS —...
  • Page 13 All manuals and user guides at all-guides.com ADJUSTMENT <TUNER / DECK / FRONT> < TUNER SECTION > 1. Clock frequency Check 2. Head Azimuth Adjustment (DECK 1, DECK 2) Settings : • Test point : TP2 (CLK) Settings : • Test tape : TTA–330 Method : Set to AM 1710kHz and check that the test point is •...
  • Page 14 All manuals and user guides at all-guides.com MECHANICAL EXPLODED VIEW 1 / 1 PWB,FFC GUIDE KSM213CDM CUSHION,CD A CUSHION,CD A ZZM-2 HT-SINK,TR LOW PWB GUIDE,H-WIRE – 14 –...

  • Page 15: Mechanical Parts List

    All manuals and user guides at all-guides.com MECHANICAL PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 8A-NED-005-010 WINDOW,CASS 1 26 8A-NED-201-010 HLDR,TOP L 27 8A-NED-202-010 HLDR,TOP R 2 8A-NED-006-010 WINDOW,CASS 2 28 8A-NEC-013-010 PANEL,LEFT 3 82-NF7-218-010...
  • Page 16 All manuals and user guides at all-guides.com 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9820572 0251431 Printed in Singapore...
