MTD Bolens 11A-414A065 Fast Start Manual

A
(A) Lift handle
to extended
position.
(B) Tighten star
knobs.
B
Place ends of lower
handle onto handle
brackets. Insert
carriage bolts and
tighten with wing nuts.
11A-414 © 2008
IMPORTANT: READ OPERATOR'S MANUAL AND ENGINE MANUAL THOROUGHLY AND
Read and understand all instruction, warning, and danger labels.
Lea el manual de operación anexo sobre ensamblaje e inicio.
1
Starter
Rope
2
Refer to Operator's Manual for instructions on attaching the grass catcher.
Call 1-888-TO-HELP-U
Need Help?
FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING .
Blade Control Handle
Star Knobs
(1-888-864-3578)
3
(A) Hold blade
control handle
against upper
handle.
(B)(C) Slowly
pull starter rope
from engine and B
slip starter rope
into rope guide.
C
(D) Tighten
rope guide wing
knob.
Use cable tie to
secure cable to
lower handle.
4
A
D
778-11649
