    INstallINg a sONIhull sYsteM Congratulations on your purchase of the Sonihull ultrasonic antifouling system. This manual will help you go through the simple steps of installing either the Sonihull Mono or Sonihull Duo systems, or multiples thereof depending on the size of your yacht. The Sonihull is suitable for fiberglass, aluminum, steel and cement hulls, where the transducer can be bonded to the inside of the outer skin of the hull.

  • Page 3: Components Included

    COMPONeNts INCluDeD SONIHULL MONO SONIHULL DUO • Sonihull control unit • Sonihull control unit • 1 ultrasonic transducer with 18 feet of • 2 ultrasonic transducers with 18 cable feet of cable • Mains cable with 3 pin UK standard •...
  • Page 4 ChOOse sONIhull MONO OR DuO POsItIONINg aCCORDINg tO WhICh tYPe OF YaCht YOu haVe For vessels in excess of the sizes shown please contact recommendations. NOTE: Twin hull vessels will require the recommendations on the image to the ≤ 32 FEET = MONO left to be doubled.
  • Page 5 For yachts over 60 feet please consult with PYI Inc for advise on the best location for MAINS AC supply only. 100-240 VAC 50/60 the transducers. Hz. Replace lid and plug into suitable AC socket.
  • Page 6 eNsuRe that the suPPlY Is IsOlateD BeFORe staRtINg the DC CaBle INstallatION Mains cable can be totally removed or simply coiled for potential future use. Connect to DC through a 5 amp inline fuse. Please ensure correct polarity. Once you have located a suitable location for the mounting the transducer, close to the center line of the hull, paying special attention to be sure that there is enough head room to replace the floor / deck plate, and that there is suitable access for running the cables back to the Sonihull controller.

  • Page 7: Installing A Transducer

    INstallINg a tRaNsDuCeR MOUNTING RING 1. Apply a thin layer of petroleum jelly to the thread of the mounting ring. Ensuring to keep the outer face of the ring free from any grease. (This is to stop any epoxy from accidently getting stuck in the threads).
