Fujitsu Lifebook P771 User Manual

Fujitsu lifebook p771: user guide
Hide thumbs Also See for Lifebook P771:
Table of Contents

Advertisement

Quick Links

See also: Operating Manual
User's
Guide
Learn how to use
your Fujitsu
LIFEBOOK P771
notebook

Advertisement

Table of Contents
loading

Related Manuals for Fujitsu Lifebook P771

Summary of Contents for Fujitsu Lifebook P771

  • Page 1 User’s Guide Learn how to use your Fujitsu LIFEBOOK P771 notebook...
  • Page 2 © Copyright 2010 Fujitsu America, Incorporated. All rights reserved. No part of this publication may be copied, reproduced, or translated, without prior written consent of Fujitsu. No part of this publication may be stored or transmitted in any electronic form without the written consent of Fujitsu.
  • Page 3 (1) This device may not cause harmful interference, (2) This device must accept any interference received,  including interference that may cause undesired operation. ARNING A CHEMICAL KNOWN TO THE Fujitsu America, Incorporated 1250 E. Arques Avenue, Sunnyvale, CA 94085 (408) 746-6000 Base Model Configuration: LIFEBOOK P771 notebook Complies with Part 15 of the FCC Rules.

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS This unit requires an AC adapter to operate. Use only UL Listed I.T.E. Class II Adapters with an output rating of 19 VDC, with a  current of 3.16 A, 60 W. AC adapter output polarity: When using your notebook equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: •...
  • Page 5 * To order a new battery for your Fujitsu mobile computer, go to the Fujitsu shopping site at www.fujitsu.ca/products/notebooks ** RBRC is an independent third party to which Fujitsu provides funding for battery recycling; RBRC is in no way affiliated with Fujitsu.

  • Page 6: Table Of Contents

    Fujitsu Contact Information ........14...
  • Page 7 Fujitsu Driver Update Utility ........55...
  • Page 8 Power/Suspend/Resume Button ....... . . 56 Sleep Mode ..........56 Hibernation (Save-to-Disk) Feature .
  • Page 9 Installing ExpressCards ........79 Removing ExpressCards.
  • Page 10 Caring for your LIFEBOOK Notebook ......114 Cleaning your LIFEBOOK notebook ......116 Cleaning the dust filter .
  • Page 11 Glossary ........... . . 132 Regulatory Information .
  • Page 12 Introducing the Fingerprint Sensor Device ......166 Getting Started ..........167 Installing OmniPass .

  • Page 13: Preface

    It is powered by the new 2nd Generation Intel® Core™ processor family and integrated Intel HD Graphics. The notebook has a built-in 12.1” wide XGA color display. This manual explains how to operate your LIFEBOOK P771 Series notebook’s hardware and built-in system software. Your notebook comes with Windows 7 Professional edition pre-installed.

  • Page 14: Fujitsu Contact Information

    NOTEBOOK Fujitsu Contact Information Service and Support You can contact Fujitsu Service and Support in the following ways: • Toll free: 1-800-8Fujitsu (1-800-838-5487) • Website: http://www.computers.us.fujitsu.com/support Before you place the call, you should have the following information ready so that the customer support representative can provide you with the fastest possible solution: •...
  • Page 15 OU MUST HAVE AN ACTIVE INTERNET CONNECTION TO USE THE ONLINE Limited Warranty Your LIFEBOOK P771 notebook is backed by a Fujitsu International Limited Warranty. Check the service kit that came with your notebook for the Limited Warranty period and terms and conditions.

  • Page 16: Getting To Know Your Lifebook

    Getting to Know Your LIFEBOOK Overview This section describes the components of your Fujitsu LIFEBOOK P771 notebook. We strongly recommend that you read it before using your notebook – even if you are already familiar with notebook computers. Figure 1. Fujitsu LIFEBOOK P771 notebook...

  • Page 17: Locating The Controls And Connectors

    Locating the Controls and Connectors Status Indicator Panel Headphone Jack Microphone Jack Wireless Device On/Off Switch SD Card Slot Touchpad Pointing Device Air Vents Figure 2. LIFEBOOK notebook with display open 17 - Locating the Controls and Connectors Web Camera Camera LED Digital Microphone Display Panel...

  • Page 18: Front And Display Components

    Front and Display Components The following is a brief description of your LIFEBOOK notebook’s front and display features. Web Camera The 2.0 megapixel web camera allows you to take pictures of yourself to send over the internet. For information on using the microphone and web cam, see the documentation associated with the CyberLink YouCam application.
  • Page 19 Stereo Speakers The built-in dual stereo speakers allow you to listen to sound from your system. Keyboard A full-function keyboard with dedicated Windows keys. See “Keyboard” on page 30. Air Vents The air vents allow proper air circulation to ensure that the system does not overheat O PROTECT YOUR NOTEBOOK FROM DAMAGE AND TO OPTIMIZE SYSTEM PERFORMANCE KEEP ALL AIR VENTS UNOBSTRUCTED CLEANING...
  • Page 20 Wireless Device On/Off Switch The wireless device on/off switch is used to turn on and off the optional wireless devices. Switching the device off when not in use will help to extend battery life. See “Activating the WLAN Device” on page 158.

  • Page 21: Left-Side Panel Components

    ExpressCard Eject Button ExpressCard Slot LAN (RJ-45) Port Anti-theft Lock Slot USB 3.0 Ports Air Vents DC Power Jack HDMI Port Figure 3. LIFEBOOK notebook left-side panel Left-Side Panel Components The following is a brief description of your LIFEBOOK notebook’s left-side components. ExpressCard Slot The ExpressCard slot allows you to insert a flash memory card for data storage.
  • Page 22 LAN (RJ-45) Port The internal LAN (RJ-45) port is used for an internal 10/100/1000 Base-Tx Ethernet. See “Internal LAN (RJ-45) Jack” on page 81. Air Vents The air vents allow proper air circulation to ensure that the system does not overheat O PROTECT YOUR NOTEBOOK FROM DAMAGE AND TO OPTIMIZE SYSTEM PERFORMANCE KEEP ALL AIR VENTS UNOBSTRUCTED CLEANING...

  • Page 23: Right-Side Panel Components

    Flexible Bay Device Figure 4. LIFEBOOK notebook right-side panel Right-Side Panel Components The following is a brief description of your LIFEBOOK notebook’s right-side components. Flexible Bay The flexible bay can accommodate any of the following modular devices. (See “Flexible Bay Devices” on page 38.) •...

  • Page 24: Bottom Components

    Air Vents (various locations) Flexible Bay Memory Upgrade Compartment Flexible Bay Release Button Dust Filter Cover Lithium ion Battery Port Replicator Connector Figure 5. LIFEBOOK notebook bottom panel Bottom Components The following is a brief description of your LIFEBOOK notebook’s bottom panel components. Flexible Bay The flexible bay holds one of the modular flexible bay devices.
  • Page 25 Memory Upgrade Compartment Your notebook comes with high speed Double Data Rate 3 Synchronous Dynamic RAM (DDR3 SDRAM). The memory upgrade compartment allows you to expand the system memory capacity of your notebook, thus improving overall performance. See “Memory Upgrade Module” on page 66. Under normal circumstances, it should not be necessary to open this compartment.

  • Page 26: Status Indicator Panel

    Status Indicator Panel The Status Indicator displays LEDs adjacent to symbols that correspond with specific components of your notebook. These lights tell you how each of those components is operating. When you turn off the system, all indicators will go off, except when the AC adapter is connected (Charging LED will be lit). Battery Power Charging...

  • Page 27: Power Saving Utility Indicator

    Power Saving Utility Indicator The Power Saving Utility indicator glows when the power saving utility is running. The power saving utility is a special power-saving mode that is initiated with the ECO button on the application panel. Hard Disk/Optical Drive Access Indicator The Hard Disk/Optical Drive access indicator lights when the hard disk or optical drive is being accessed.

  • Page 28: Power Indicator

    Power Indicator The Power indicator symbol shows whether your system is operational. It has several different states, each of which tells you what mode your notebook is in at that time. • Steady On: This means that there is power to your notebook and that it is ready for use. •...

  • Page 29: Battery Level Indicators

    Battery Level Indicators The Battery 1 indicator refers to the main battery; the Battery 2 indicator refers to a second battery, if installed in the flexible bay. The Battery Level indicators display the charge level of the battery packs, as follows: •...

  • Page 30: Keyboard

    Fn Key Start Key Using the Keyboard Your LIFEBOOK P771 Series notebook has an integral 82-key keyboard. The keys perform all the standard functions of a 101-key keyboard, including the Windows keys and other special function keys. This section describes the following keys. (Figure 7) •...
  • Page 31 Windows Keys Your LIFEBOOK P771 notebook has two Windows keys: a Start key and an Application key. The Start key displays the Start menu. This button functions the same as your onscreen Start menu button. The Application key functions the same as your right mouse button and displays shortcut menus for the selected item.
  • Page 32 Function Keys Your LIFEBOOK notebook has 12 function keys, F1 through F12. The functions assigned to these keys differ for each application. You should refer to your software documentation to find out how these keys are used. • [Fn+F3]: Pressing [F3] while holding [Fn] will toggle the Audio Mute on and off. •...

  • Page 33: Touchpad Pointing Device

    Touchpad Pointing Device Left Button Fingerprint Recognition Sensor Right Button Scroll Wheel Touchpad Cursor Control Figure 8. Touchpad pointing device The Touchpad pointing device comes built into your LIFEBOOK notebook. It is used to control the movement of the pointer to select items on your display panel. The Touchpad is composed of a cursor control, a left and right button, and a fingerprint recognition sensor.
  • Page 34 To the right of the touchpad is a circular dimple, approximately an inch in diameter. This is known as the “scroll wheel” and is used for scrolling up and down pages and zooming in and out on photos. Note that the scroll wheel does not actually move;...
  • Page 35 Dragging Dragging means pressing and holding the left button, while moving the cursor. To drag, move the cursor to the item you wish to move. Press and hold the left button while moving the item to its new location and then release it. Dragging can also be done using the Touchpad.

  • Page 36: Touchpad Control Adjustment

    The Windows Control Panel allows you to customize your Touchpad with selections made from within the Mouse Properties dialog box. Navigating Using Gestures The touchpad lets you use gestures to zoom, flick, rotate, and scroll on a page or scroll quickly through large documents.
  • Page 37 Figure 14. Zooming out with Touchpad Figure 13. Zooming in with Touchpad Figure 16. Using inertia Figure 15. Continuous scrolling 37 - Touchpad Pointing Device...

  • Page 38: Volume Control

    Volume Control Your Fujitsu LIFEBOOK notebook has multiple volume controls which interact with each other. NY SOFTWARE THAT CONTAINS AUDIO FILES WILL ALSO CONTAIN A VOLUME CONTROL OF ITS OWN YOU INSTALL AN EXTERNAL AUDIO DEVICE THAT HAS AN INDEPENDENT VOLUME CONTROL...

  • Page 39: Flexible Bay Devices

    Flexible Bay Devices Your Fujitsu LIFEBOOK notebook contains a Flexible Bay. The Flexible Bay can house an optical drive, a Lithium ion battery, or a weight saver. Your Flexible Bay will have one of the following devices installed. • Modular Dual-Layer Multi-Format DVD Writer: This allows you to access movies, software, and audio DVD/CDs and record to DVD, CD, and DVD-RAM discs.
  • Page 40 Cold-swapping To cold-swap modular devices in your Flexible Bay follow these easy steps: Close any open files. Shut down your LIFEBOOK notebook and turn your system upside down. As you press the Flexible Bay release button as shown in Figure 19, pull out the Flexible Bay module until it is clear of the bay.

  • Page 41: Lifebook Application Panel/Support Button

    Fujitsu Support Center utility or to launch a user-defined application. The default settings for the buttons are as follows: • Support Button - Starts the Fujitsu Support Center (See “Opening the Fujitsu Support Center with the Support Button” on page 44)

  • Page 42: Launching Applications With The Application Panel

    • Internet Button - Automatically launches Internet Explorer. • Email Button - Automatically launches Microsoft Outlook Express, from which you can read, create, and send email. Note that when the notebook is turned off, pressing this button allows you to see the current battery status on the battery level and battery charging indicators. •...
  • Page 43 Click on Application Panel Setup. The Application Panel Setup utility will appear. There are tabs that correspond to the application buttons on the LIFEBOOK Application Panel. When you receive your notebook, these buttons are pre-configured to launch specific programs, as referenced above. HE TABS IN PPLICATION LIFEBOOK...

  • Page 44: Opening The Fujitsu Support Center

    The Support button performs different actions when the system is off or when it is on. When the system is booting, pressing the Support button will open the Fujitsu Start Boot Menu which allows you to select Recovery and Utility to perform a number of other functions, including recovery of your system.

  • Page 45: Getting Started With Your Lifebook

    Chapter 2 Getting Started with Your LIFEBOOK DC Power Jack AC Adapter DC Output Cable AC Cable Power Plug Figure 21. Connecting the AC Adapter...

  • Page 46: Power Sources

    Power Sources Your Fujitsu LIFEBOOK notebook has three possible power sources: a primary Lithium ion battery, an AC adapter or an optional Auto/Airline adapter. Connecting the Power Adapters The AC adapter or optional Auto/Airline adapter provides power for operating your notebook and charging the batteries.

  • Page 47: Display Panel

    Figure 22. Opening the Display Panel Display Panel Your Fujitsu LIFEBOOK notebook contains a display panel that is backlit for easier viewing in bright environments and maintains top resolution through the use of active-matrix technology. Opening the Display Panel Lift the display backwards, being careful not to touch the screen, until it is at a comfortable viewing angle.

  • Page 48: Adjusting Display Panel Brightness

    Once you have turned on your system, you may want to adjust the brightness level of the screen to a more comfortable viewing level. There are three ways to adjust the brightness, keyboard, power management utility, and Fujitsu menu. Additionally, you can change the brightness using the Power Options in the Control Panel.
  • Page 49 Using the Fujitsu Menu to Adjust Brightness To adjust brightness using the Fujitsu menu, click on the Fujitsu Menu icon in the system tray in the lower right corner of the screen. (You can also open the Fujitsu menu by clicking the [Fn] button twice in succession.) Scroll down to the Mobility Center and double-click it, then double-click the icon adjacent...

  • Page 50: Starting Your Lifebook Notebook

    Starting Your LIFEBOOK Notebook Power On Power/Suspend/Resume Button The Power/Suspend/Resume button is used to turn on your LIFEBOOK from its off state. Once you have connected your AC adapter or charged the internal Lithium ion battery, you can power on your notebook. HEN YOU TURN ON YOUR MEANS THAT AT LEAST ONE BATTERY IS INSTALLED AND CHARGED ADAPTER IS CONNECTED AND HAS POWER...

  • Page 51: Boot Sequence

    This information is in the BIOS program. Each time you power up or restart your notebook, it goes through a boot sequence which displays a Fujitsu logo until your operating system is found. During booting, your notebook is performing a standard boot sequence including a Power On Self Test (POST).

  • Page 52: Bios Setup Utility

    Turn on or restart your LIFEBOOK. To enter the BIOS Setup Utility, press the [F2] key once the Fujitsu logo appears on the screen. This will open the main menu of the BIOS Setup Utility with the current settings displayed.

  • Page 53: Booting The System

    When you turn on your notebook for the first time, it will display a Fujitsu logo on the screen. If you do nothing the system will load the operating system, and then the Windows Welcome will begin.

  • Page 54: Installing Clickme

    • F YOU REJECT THE TERMS OF THE LICENSE AGREEMENT YOU WILL BE ASKED TO REVIEW THE LICENSE AGREEMENT FOR INFORMATION ON RETURNING • OU CANNOT USE YOUR NOTEBOOK UNTIL YOU HAVE ACCEPTED THE PROCESS YOUR NOTEBOOK WILL RETURN TO THE BEGINNING OF THE YOU SHUT YOUR NOTEBOOK DOWN AND START IT UP AGAIN Several additional windows will appear, prompting you to enter a name and description for your computer, an Administrator password, and a domain name.

  • Page 55: Fujitsu Driver Update Utility

    Your system has a convenient tool called the Fujitsu Driver Update (FDU) utility. With FDU, you can choose to automatically or manually go to the Fujitsu site to check for new updates for your system. For more information about the FDU utility, refer to “Automatically Downloading Driver Updates” on page 113.

  • Page 56: Power Management

    Power Management Your LIFEBOOK notebook has many options and features for conserving battery power. Some of these features are automatic and need no user intervention. However, others depend on the parameters you set to best suit your operating conditions, such as those for the display brightness. Internal power management for your notebook may be controlled from settings made in your operating system, pre-bundled power management application, or from settings made in BIOS setup utility.

  • Page 57: Hibernation (Save-To-Disk) Feature

    • Pressing the Power/Suspend/Resume button when your system is turned on. • Selecting Sleep or Standby from the Windows Shut Down menu. • Timing out from lack of activity. • Allowing the battery to reach the Dead Battery Warning condition. Your notebook’s system memory typically stores the file on which you are working, open application information, and any other data required to support operations in progress.

  • Page 58: Windows Power Management

    Enable or Disable the Hibernation Feature The Hibernate is enabled by default. To disable or enable the Hibernation feature follow these steps: From the Start menu, select Control Panel, then select the Power Options icon. Select “Choose what the power button does” or “Choose what closing the lid does”, then make your selections (Do Nothing, Sleep, Hibernate, or Shut Down).

  • Page 59: Powering Off

    Before turning off the power, check that the hard drive/optical drive access indicator is off. If you turn off the power while accessing a disk there is a risk of data loss. To ensure that your notebook shuts down without error, use the Windows shut down procedure. E SURE TO CLOSE ALL FILES PRIOR TO TURNING OFF THE POWER LOSE ANY CHANGES THAT HAVE NOT BEEN SAVED...

  • Page 60: Energy Star® Compliance

    Sleep mode, press the Suspend/Resume Button. Energy saving benefits: Fujitsu ENERGY STAR qualified mobile PCs use about half as much electricity as standard equipment – saving half in utility costs. But more than that, ENERGY STAR also makes a difference for the environment.

  • Page 61: User-Installable Features

    Chapter 3 User-Installable Features Lithium ion Battery Your LIFEBOOK notebook has a Lithium ion battery that provides power for operating your notebook when no external power source is available. The battery is durable and long lasting, but should not be exposed to extreme temperatures, high voltages, chemicals or other hazards.

  • Page 62: Recharging The Batteries

    • ATTERY LIFE WILL VARY BASED ON SCREEN BRIGHTNESS SETTINGS BATTERY CONDITION AND OTHER CUSTOMER PREFERENCES MAY ALSO HAVE A SIGNIFICANT IMPACT ON BATTERY LIFE BATTERY AGES F YOUR BATTERY IS RUNNING LOW QUICKLY • NDER FEDERAL STATE TRASH AKE CARE OF OUR ENVIRONMENT AND DISPOSE OF BATTERIES PROPERLY GOVERNMENT AUTHORITY FOR DETAILS ON RECYCLING OR DISPOSING OF BATTERIES INFORMATION ELSEWHERE Recharging the Batteries...

  • Page 63: Replacing The Battery

    Low Battery State When the battery is running low, the Battery Level indicator will glow red. If you do not respond to the low battery alarm, the batteries will continue to discharge until they are too low to operate. Your notebook will then go into Sleep mode to try and protect your data for as long as possible.
  • Page 64 Shut down your notebook. If connected, disconnect the AC Adapter and turn the system over. Battery Latch Figure 24. Removing the Battery While sliding the battery lock towards the front of the system and holding it in place, slide the battery latch towards the edge of the notebook;...
  • Page 65 Figure 25. Installing a Battery Swapping batteries when another power source is available To swap batteries in your battery compartment when you have an additional power source (such as an AC Adapter), follow these easy steps: Plug in an AC Adapter to ensure power is supplied to the system. Slide and hold the battery lock, then slide the battery latch to unlock the battery.

  • Page 66: Memory Upgrade Module

    The memory upgrade must be a dual-in-line (DIMM) SDRAM module. To ensure 100% compatibility, purchase the memory module only from the Fujitsu web store at us.fujitsu.com/computers. •...

  • Page 67: Accessing The Memory Compartment

    To gain access to the upgradeable memory compartment, follow these steps OU MUST TURN OFF POWER BEFORE INSTALLING THE MEMORY UPGRADE MODULE Turn off power to your LIFEBOOK notebook, and remove any power adapter (AC or auto/airline) and battery pack. Place your LIFEBOOK notebook with the bottom facing up on a clean work surface.

  • Page 68: Removing A Memory Module

    Perform steps 1 through 3 of Accessing the Memory Compartment. Pull the module clips sideways away from each side of the memory module simultaneously. While holding the clips out, remove the module from the slot by lifting it up and pulling towards the back of your LIFEBOOK notebook.

  • Page 69: Installing A Memory Module

    Align the connector edge of the memory upgrade module, chip side up, with the connector slot in the (Figure 28) compartment. Figure 28. Inserting a Memory Module Insert the memory upgrade module at a 45 Press the memory upgrade module down into the compartment until it locks underneath the retaining clip. You will hear a click when it is properly in place.

  • Page 70: Checking The Memory Capacity

    Once you have changed the system memory capacity by replacing the installed module with a larger one, be sure to check that your notebook has recognized the change. Check the memory capacity by clicking [Start] -> Control Panel -> System and Security -> System. The amount of memory is displayed next to “Installed memory - RAM:”...

  • Page 71: Optical Drive

    Optical Drive The Dual Layer Multi Format DVD Writer is an optional device that can be installed in the Flexible Bay (See “Flexible Bay Devices” on page 39.) Multi-Format DVD Writers are also known as “optical drives”. There is a variety of media available to use with the Dual Layer Multi Format DVD Writer in your system. Your optical drive allows you to access movies, software, and audio DVD/CDs as well as to read and write to CD-R, CD-RW, DVD-R, DVD+R, DVD-RW, DVD+RW, and DVD RAM discs.

  • Page 72: Media Player Software

    THAT YOU CAN ONLY CHANGE THE REGION CODE UP TO FOUR TIMES 72 - Optical Drive NOTEBOOK IS SITTING ON A FLAT SURFACE MOVIE WILL SUBSTANTIALLY REDUCE YOUR FUJITSU COMPUTERS FOR THE MOST WHICH IS IFFERENT REGION CODES ARE F THE REGIONAL CODE...
  • Page 73 F YOU HAVE DISABLED THE NSERT DRIVE EITHER BY USING OMPUTER OR FROM WITHIN NOTEBOOK WILL NOT AUTOMATICALLY RECOGNIZE THAT MEDIA HAS BEEN LOADED Figure 31. Loading/Ejecting Media 73 - Optical Drive OTIFICATION UNCTION YOU WILL HAVE TO START THE INDOWS XPLORER SINCE YOUR...

  • Page 74: Removing Media

    Push and release the eject button on the front of the optical drive. This will stop the drive and the holder tray will come out of the notebook a short distance. Gently pull the tray out and carefully remove the media disc from the holder tray. Gently push the holder tray back in until you hear a click.

  • Page 75: Using The Optical Drive On Battery Power

    • N ADDITIONAL FULLY ON BATTERY POWER AT US FUJITSU To Watch a Movie on Battery Power: Have an additional full-charged battery or your AC adapter ready for use. Start watching your DVD movie. If a low battery warning occurs, immediately stop the movie and exit the DVD/CD-RW application...

  • Page 76: Auto Insert Notification Function

    Manually place your notebook into Sleep mode by depressing the Suspend button then replace the discharged battery with a fully-charged battery. If you removed the optical drive from the Flexible Bay in step 4, reinstall it now. Resume your notebook by pressing the Suspend button again. This step is not required if you attached AC power without entering Sleep mode.

  • Page 77: Secure Digital (Sd)/Secure Digital High Capacity (Sdhc) Cards

    SD Card SD Card Slot Figure 33. Installing an SD Card Secure Digital (SD)/Secure Digital High Capacity (SDHC) Cards Your LIFEBOOK notebook supports Secure Digital (SD) and Secure Digital High Capacity (SDHC) cards, on which you can store and transfer data to and from a variety of digital devices. These cards use flash memory architecture, which means they don’t need a power source to retain data.

  • Page 78: Inserting Sd/Sdhc Cards

    SD and SDHC cards are inserted in the SD Card slot (Figure 33). To insert a card, follow these steps • NSERTING OR REMOVING AN PROCESS MAY DAMAGE THE CARD AND • O NOT INSERT A CARD INTO A SLOT IF THERE IS WATER OR ANY OTHER SUBSTANCE ON THE CARD AS YOU MAY PERMANENTLY DAMAGE THE CARD See your card manual for instructions on the insertion of your card.

  • Page 79: Expresscards

    ExpressCards Your LIFEBOOK notebook supports ExpressCards which can perform a variety of functions depending on which type of card you install. There are two different width ExpressCards: 34 mm and 54 mm. The connector inside the slot is located on the left-hand side of the slot. If you insert a 34 mm card, be sure to align it with the left side of the slot when inserting it.

  • Page 80: Removing Expresscards

    OU MAY BE REQUIRED TO LOG ON AS AN ROUP TO COMPLETE THIS PROCEDURE POLICY SETTINGS MAY ALSO PREVENT YOU FROM COMPLETING THIS PROCEDURE See your ExpressCard manual for instructions on the installation of your card. Some cards may require that your notebook is off while installing them.

  • Page 81: Device Ports

    Device Ports Your LIFEBOOK P771 Series notebook and the optional Port Replicator (see “Port Replicator” on page 85) come equipped with multiple Device Ports to which you can connect an external device including: disk drives, keyboards, modems, printers, etc. Internal LAN (RJ-45) Jack The internal LAN (RJ-45) jack is used for an internal 10/100/1000 BaseTx Ethernet connection.

  • Page 82: Universal Serial Bus Ports

    The three Universal Serial Bus (USB) ports (two USB 3.0 ports on the left side, one USB 2.0 port on the right) allow you to connect USB devices such as external floppy disk drives, external DVD drives, game pads, pointing devices, keyboards and/or speakers.

  • Page 83: Microphone Jack

    The microphone jack allows you to connect an external stereo microphone. Your microphone must be equipped with a 1/8”(3.5 mm) stereo mini-plug in order to fit into the microphone jack of your notebook. In order to connect a microphone follow these easy steps: Align the connector with the port opening.

  • Page 84: External Video Port

    The external video port allows you to connect an external monitor or LCD projector. In order to connect an external device follow these easy steps:. There is also an external VGA monitor port on the port replicator (Figure 39). Align the connector with the port opening. Push the connector into the port until it is seated.

  • Page 85: Port Replicator

    Port Replicator An optional Port Replicator is available from Fujitsu to extend the functionality of your LIFEBOOK® notebook by providing ports to connect an external VGA monitor, a LAN (RJ-45) cable, four USB 2.0 devices, DC Power, and DVI and e-SATA devices...
  • Page 86 USB 2.0 Ports (Qty. 4) Universal Serial Bus (USB) 2.0 ports allow you to connect USB devices. USB 2.0 ports are backward- compatible with USB 1.1 devices. eSATA Port eSATA (external Serial Advanced Technology Attachment) is an external version of SATA, and connects the computer to the hard drive.

  • Page 87: Attaching/Detaching Port Replicator

    External Video Port The external video port lets you connect an external monitor or projector. Note that if a Port Replicator is attached, you must use the external video port on the Port Replicator, not the one on your system. Security Lock Slot The security lock slot allows you to attach an optional physical lock down device.
  • Page 88 Docking Connector Release Latch Figure 40. Attaching Figure 41. Unlatching Figure 42. Removing 88 - Port Replicator...

  • Page 89: Chapter 4 Troubleshooting Your Lifebook

    Chapter 4 Troubleshooting Your LIFEBOOK Troubleshooting There may be occasions when you encounter simple setup or operating problems that you can solve on the spot, or problems with peripheral devices that can be solved by replacing the device. The information in this section helps you isolate and resolve some of these straightforward issues and identify failures that require service.
  • Page 90 If you have tried the solutions suggested in the Troubleshooting Table without success, contact your support representative: Toll free: 1-800-8Fujitsu (1-800-838-5487)  Web site: http://www.computers.us.fujitsu.com/support. Before you place the call, you should have the following information ready so that the customer support representative can provide you with the fastest possible solution: •...

  • Page 91: Specific Problems

    Using the Troubleshooting Table When you have problems with your LIFEBOOK, try to find the symptoms under the Problem column of the troubleshooting table for the feature giving you difficulty. You will find a description of common causes for that symptom under the column Possible Cause and what, if anything, you can do to correct the condition under Possible Solutions.

  • Page 92: Audio Problems

    Problem Possible Cause Audio Problems There is no sound coming The volume is turned too low. from the built-in speaker. The software volume control is set too low. Headphones are plugged into your notebook. Software driver is not  configured correctly. The speakers have been muted using the Volume icon in the system tray.

  • Page 93: Keyboard Or Mouse Problems

    Problem Possible Cause Keyboard or Mouse Problems The built-in keyboard does The notebook has gone into not seem to work. Sleep mode. Your application has locked out your keyboard. NumLock key has been set. You have installed an  Your external device is not external keyboard or properly installed.

  • Page 94: Expresscard Problems

    Problem Possible Cause You have installed a USB The device may have been device. Your notebook installed while an application does not recognize the was running, so the notebook device, or the device does is not aware of its installation. not seem to work properly.
  • Page 95 Problem Possible Cause You turn on your LIFE- The power adapter (AC or BOOK notebook and noth- auto/airline) is not plugged in ing seems to happen. properly. (continued) The power adapter (AC or auto/airline) has no power from the AC outlet, airplane jack, or car cigarette lighter.

  • Page 96: Shutdown And Startup Problems

    Close all applications and try the button again. Set the operating source by pressing the [ESC] key while the Fujitsu logo is on screen or use the [F2] key and enter the setup utility and adjust the source settings from the Boot menu.

  • Page 97: Video Problems

    Problem Possible Cause An error message is  Power On Self Test (POST) displayed on the screen has detected a problem. during the boot sequence. Your notebook appears to BIOS changes were not change setup parameters saved when you exited. when you start it.

  • Page 98: Miscellaneous Problems

    Problem Possible Cause The display goes blank by Power management timeouts itself after you have been may be set for short intervals using it. and you failed to notice the (continued) display come on then go off. The display does not A foreign object, such as a close.

  • Page 99: Power On Self Test Messages

    Power On Self Test Messages The following is an alphabetic list of error-and-status messages that Phoenix BIOS and/or your operating system can generate and an explanation of each message. Error messages are marked with an *. If an error message is displayed that is not in this list, write it down and check your operating system documentation both on screen and in the manual.
  • Page 100 *Fixed Disk x Failure or Fixed Disk Controller Failure (where x = 1-4) The fixed disk is not working or not configured properly. This may mean that the hard drive type identified in your setup utility does not agree with the type detected by the Power On Self Test. Run the setup utility to check for the hard drive type settings and correct them if necessary.
  • Page 101 *Keyboard error nn BIOS discovered a stuck key and displays the scan code for the stuck key. You may have to replace your keyboard but may be able to use an external keyboard until then. Contact your support representative. *Monitor type does not match CMOS – Run SETUP Monitor type not correctly identified in Setup.
  • Page 102 *Previous boot incomplete – Default configuration used Previous Power On Self Test did not complete successfully. The Power On Self Test will load default values and offer to run Setup. If the previous failure was caused by incorrect values and they are not corrected, the next boot will likely fail also.
  • Page 103 *System RAM Failed at offset: nnnn System memory failed at offset nnnn of in the 64k block at which the error was detected. This means that there is a fault in your built-in memory. If you continue to operate, you risk corrupting your data. Contact your support representative for repairs.

  • Page 104: Restoring Your Pre-Installed Software

    Restoring Your Pre-installed Software It is very important that you create DVD copies of your Factory Image before beginning to use your system. To do so, follow the instructions below in the “Saving Your Factory Image” section. Along with instructions on saving your Factory Image, this document outlines several other important procedures, such as making a system image, restoring your Factory Image and system images, managing your images, and restoring the partitions on a hard drive.

  • Page 105: Creating Backup Images Of Factory Image, Dar, And Discs

    Factory Image to DVD discs. You will need several blank discs (DVD-R or DVD+R discs are recommended) in order to create the copy. After creating the copy, be sure to label the discs and keep them in a safe place to ensure they do not get damaged. Creating Backup Images of Factory Image, DAR, and Discs OME CONFIGURATIONS OF CERTAIN RATHER...

  • Page 106: Recovering Your Factory Image

    Repeat the process for the remaining three images on disc (Bootable Disc, Drivers and Applications Restore Disc, and Application Disc). The number of images available may vary depending on your system model; some models do not have the applications loaded on the hard drive. Recovering Your Factory Image In the event you need to restore your original Factory Image, perform the following steps.
  • Page 107 After rebooting, the “Creating of the backup image” window appears, in which you can either click [Create the image on D drive] or [Select the drive] if you want to save to an external hard disk drive. An image appears showing you graphically how the image will be stored. Click the [Next] button. Click [Execute] to start the backup.

  • Page 108: Managing Your Backup Images

    Recovery and Utility Tools, but you will still be able to boot from the disc. Determining whether Recovery and Utility is pre-loaded Turn on or reboot your system. When the Fujitsu logo appears, press [F12] key. 108 - Restoring Your Pre-installed Software...
  • Page 109 HE BOOTABLE DISC CAN ONLY BE USED WITH THE SYSTEM WITH WHICH IT WAS PURCHASED Power on your system. When the Fujitsu logo appears on the screen. press the [Enter] key or click on the left mouse or touchpad button; the SecureCore™ Menu will appear.
  • Page 110 Highlight the CD/DVD option. Insert the bootable disc into the drive tray. Click [OK]. While the files are being loaded from the disc, a progress bar will appear at the bottom of the screen. When the System Recovery Options dialog opens, select a new keyboard layout, if necessary, then click [Next]. When the Operating System dialog appears, click [Next].

  • Page 111: Recovering Your Factory Image (New Or Non-Bootable Hard Drive)

    Factory Image: Power on your system. When the Fujitsu logo appears on the screen. press the [Enter] key or click on the left mouse or touchpad button; the SecureCore™ Menu will appear.
  • Page 112 “3. Restoring Factory Image to hidden partition” will be in bold with the message “Please insert the Recovery Disk#1 into the optical drive”. Click [Next] to proceed. After completion, the tool will automatically go back to "3.Restoring Factory Image to hidden partition" but will include the note "Please insert your Application Disc(s) starting with #1, then click [OK].

  • Page 113: Automatically Downloading Driver Updates

    Your system has a convenient tool called the Fujitsu Driver Update (FDU) utility. With FDU, you can choose to automatically or manually go to the Fujitsu site to check for new updates for your system. The FDU icon should appear in the system tray at the bottom right of your screen (roll the cursor over the icons to find the correct one).

  • Page 114: Chapter 5 Care And Maintenance

    Chapter 5 Care and Maintenance Caring for your LIFEBOOK Notebook If you use your Fujitsu LIFEBOOK notebook carefully, you will increase its life and reliability. This section provides some tips for looking after the notebook and its devices. • N THE EVENT YOU DROP YOUR NOTEBOOK OR DAMAGE THE HOUSING IN ANY WAY...
  • Page 115 Let it dry out for 24 hours, or longer if needed. If your notebook will not boot after it has dried out, call your support representative. • Do not use your Fujitsu LIFEBOOK notebook in a wet environment (near a bathtub, swimming pool).

  • Page 116: Cleaning Your Lifebook Notebook

    • Always disconnect the power plug. (Pull the plug, not the cord.) • Clean your LIFEBOOK notebook with a damp, lint-free cloth. Do not use abrasives or solvents. • Use a soft cloth to remove dust from the screen. Never use glass cleaners. •...

  • Page 117: Cleaning The Dust Filter

    Wipe the surface with a soft cloth wipe and a 50% ethanol solution or use another ethanol-based germicide which has been registered as a hospital disinfectant by the EPA. • SE OF INCORRECT CLEANERS CAN RESULT IN OPTICAL IMPAIRMENT OF THE THE COMPUTER SAFETY DATA SHEETS FOR PROPER HANDLING AND USE OF THE PRODUCTS •...
  • Page 118 To remove the dust filter cover: Turn off the computer and disconnect the AC adapter. Close the display and turn the system upside down. Remove the dust filter access cover by pressing the latch toward the center of the cover and lifting it out (Fig.43).

  • Page 119: Storing Your Lifebook Notebook

    In addition, a faulty battery might damage your LIFEBOOK. • Store your Fujitsu LIFEBOOK in a cool, dry location. Temperatures should remain between 13ºF  (-25ºC) and 140ºF (60ºC). •...

  • Page 120: Batteries

    personnel. You can however, put your notebook through a properly tuned X-ray machine. To avoid problems, place your notebook close to the entrance of the machine and remove it as soon as possible or have your notebook hand-inspected by security personnel. Security officials may require you to turn your notebook on, so make sure you have a charged battery on hand.

  • Page 121: Media Care

    battery life. • Do not leave a battery in storage for longer than 6 months without recharging it. Increasing Battery Life • Power your LIFEBOOK notebook through the AC or optional auto/airline adapter whenever possible. • If your notebook is running on battery power all day, connect it to the AC adapter overnight to recharge the battery.
  • Page 122 • Do not scratch or get dust on media discs. • Never write on the label surface with a ballpoint pen or pencil. Always use a felt pen. • If a media disc is subjected to a sudden change in temperature, cold to warm condensation may form on the surface.

  • Page 123: Chapter 6 System Specifications

    Chapter 6 System Specifications Specifications This section provides the hardware and environmental specifications for your Fujitsu LIFEBOOK notebook. Specifications of particular configurations will vary. Configuration Label The configuration label located on the bottom of your notebook contains specific information regarding the options you’ve chosen for your notebook.

  • Page 124: Microprocessor

    Intel® Core™ i7-2617 processor, 1.5 GHz Chipset • Mobile Intel® QM67 Express Memory System Memory • DDR3-1333 MHz SDRAM dual-channel memory module. • Two DIMM slots; one slot is fixed, one is upgradeable. System memory is upgradeable to 8 GB of total memory.

  • Page 125: Audio

    Audio • Realtek codec ALC269 with High Definition (HD) audio. • Headphones: Stereo headphone jack, 3.5 mm, 1 V • Microphone: Stereo microphone jack, 3.5 mm, 100 mV (AC) and 2K ohms (DC) • Two built-in stereo speakers, 15 mm diameter •...

  • Page 126: Device Ports

    Trusted Platform Module Trusted Platform Module (TPM) for added system security. Theft Prevention Lock Lock slots for use with security restraint systems. Device Ports On the LIFEBOOK notebook: • ExpressCard slot • Secure Digital (SD) Card slot • One 15-pin D-SUB connector for VGA external video device (see Display specifications) •...

  • Page 127: Keyboard

    • One DC-in connector • One DVI-D connector • One DisplayPort connector Keyboard Built-in keyboard with all functions of 101 key PS/2 compatible keyboards. • Total number of keys: 82 • Function keys: F1 through F12, plus Fn extension key •...

  • Page 128: Dimensions And Weight

    Operating: 20% to 85%, relative, non-condensing. Non-operating: 8% to 85%, relative, non-condensing Altitude Operating: 10,000 feet (3,048 m) maximum Popular Accessories For ordering or additional information on Fujitsu accessories please visit our Web site at  www.shopfujitsu.com or call 1-800-FUJITSU. 128 - Specifications...

  • Page 129: Included Software

    Included Software Depending on your pre-installed operating system, your notebook comes with software for playing audio and video files of various formats. In addition there is file transfer software, virus protection software and Power Management software. The following list indicates the software included with your system. •...
  • Page 130 Adobe Reader The Adobe Reader allows you to view, navigate, and print PDF files from across all of the major computing platforms. Norton Internet Security Your system is preinstalled with a free 60-day trial version of Norton Internet Security™. Internet Security is a suite of tools designed to protect your LIFEBOOK notebook from computer viruses, hackers, spyware, and spam.
  • Page 131 OmniPass Fingerprint application The fingerprint sensor uses Softex OmniPass which provides password management capabilities to Microsoft Windows operating systems. OmniPass lets you use a "master password" for all Windows, applications, and on-line passwords, and presents a convenient user interface through which you can securely manage passwords, users, and multiple identities for each user.

  • Page 132: Glossary

    Glossary AC Adapter A device which converts the AC voltage from a wall outlet to the DC voltage needed to power your LIFEBOOK notebook. Access point Wireless network device used to bridge wireless and wired network traffic. ACPI Advanced Configuration and Power Interface Active-Matrix Display A type of technology for making flat-panel displays which has a transistor or similar device for every pixel on the screen.
  • Page 133 Accelerated Graphics Port. Graphics port specifically designed for graphics-intensive devices, such as video cards and 3D accelerators. Auto/Airline Adapter A device which converts the DC voltage from an automobile cigarette lighter or aircraft DC power outlet to the DC voltage needed to power your LIFEBOOK notebook. BIOS Basic Input-Output System.
  • Page 134 Cache Memory A block of memory built into the micro-processor which is much faster to access than your system RAM and used in specially structured ways to make your overall data handling time faster. CardBus A faster, 32-bit version of the PC Card interface which offers performance similar to the 32-bit PCI architecture.
  • Page 135 Cathode Ray Tube. A display device which uses a beam of electronic particles striking a luminescent screen. It produces a visual image by varying the position and intensity of the beam. Data The information a system stores and processes. Direct current. A voltage or current that does not fluctuate periodically with time. Default Value A pre-programmed value to be used if you fail to set your own.
  • Page 136 Direct Memory Access. Special circuitry for memory to memory transfers of data which do not require CPU action. Desktop Management Interface. A standard that provides PC management applications with a common method of locally or remotely querying and configuring PC computer systems, hardware and software components, and peripherals.
  • Page 137 Encryption Key (Network Key) Data encryption key used to encrypt message text and for computing message integrity checks. Data encryption protects data from unauthorized viewing. This device uses the same encryption key to encode and decode the data, and the identical encryption key is required between the sender and receiver.
  • Page 138 IEEE802.11a Wireless LAN standard that supports a maximum data rate of 54 Mbps. 802.11a devices operate in the 5 GHz lower and middle UNII bands. IEEE802.11b Wireless LAN standard that supports a maximum data rate of 11 Mbps. 802.11b devices operate in the 2.4 GHz ISM band.
  • Page 139 Class B - supports 65,000 hosts on each of 16,000 networks Class C - supports 254 hosts on each of 2 million networks The number of unassigned Internet addresses is running out, so a new classless scheme called CIDR is gradually replacing the system based on classes A, B, and C and is tied to adoption of IPv6. An abbreviation for infrared.
  • Page 140 LPT Port Line Printer Port. A way of referring to parallel interface ports because historically line printers were the first and latter the most common device connected to parallel ports. MAC Address Media Access Control Address. A unique physical address of a network card. For Ethernet, the first three bytes are used as the vendor code, controlled and assigned by IEEE.
  • Page 141 Maximum Transmission Unit The maximum data size that can be transferred at a time through the Internet or other networks. You can set a smaller MTU size to obtain successful communication, if you have difficulty transferring data due to the fact that the maximum size is too large. Network key Data that is used for encrypting data in data communication.
  • Page 142 PCMCIA PCMCIA is a trademark of the Personal Computer Memory Card International Association. The Personal Computer Memory Card International Association is an organization that sets standards for add-in cards for personal computers. Peripheral Device A piece of equipment which performs a specific function associated with but not integral to a computer.
  • Page 143 Protocol Procedures and rules use to send and receive data between computers. - Method of sending and receiving data - Process used to handle communication errors Conditions required for communication are organized in procedures for correct transfer of information. Random Access Memory. A hardware component of your LIFEBOOK notebook that holds binary information (both program and data) as long as it has the proper power applied to it.
  • Page 144 SDRAM Synchronous Dynamic Random Access Memory. Shared key authentication 802.11 network authentication method in which the AP sends the client device a challenge text packet that the client must then encrypt with the correct WEP key and return to the AP. If the client has the wrong key or no key, authentication will fail and the client will not be allowed to associate with the AP.
  • Page 145 Subnet mask TCP-IP network is controlled by being divided into multiple smaller networks (subnets). IP address consists of the subnet address and the address of each computer. Subnet mask defines how many bits of IP address comprise the subnet address. The same value shall be set among computers communicating with each other.
  • Page 146 Wired for Management is Intel’s broad-based initiative to reduce the total cost of ownership (TCO) of business computing without sacrificing power and flexibility. Wi-Fi Compatible Wi-Fi (Wireless Fidelity) Identifies that the product has passed the interoperability test, supplied by the WECA (Wireless Ethernet Compatibility Alliance), which guarantees the interoperability of wireless IEEE 802.11 LAN products.

  • Page 147: Regulatory Information

    Regulatory Information Notice Changes or modifications not expressly approved by Fujitsu could void this user’s authority to operate the equipment. FCC NOTICES Notice to Users of Radios and Television This equipment has been tested and found to comply with the limit for class B digital devices, pursuant to parts 15 of the FCC Rules.
  • Page 148 DOC (INDUSTRY CANADA) NOTICES Notice to Users of Radios and Television This Class B digital apparatus meets all requirements of Canadian Interference-Causing Equipment Regulations. CET appareil numérique de la class B respecte toutes les exigence du Réglement sur le matérial brouilleur du Canada.

  • Page 149: Appendix A: Wlan User's Guide

    Appendix A: WLAN User’s Guide FCC Regulatory Information Please note the following regulatory information related to the optional wireless LAN device. Regulatory Notes and Statements Wireless LAN, Health and Authorization for use Radio frequency electromagnetic energy is emitted from Wireless LAN devices. The energy levels of these emissions, however, are much less than the electromagnetic energy emissions from wireless devices such as mobile phones.
  • Page 150 Regulatory Information/Disclaimers Installation and use of this Wireless LAN device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment.
  • Page 151 (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operation. Modifications not expressly authorized by Fujitsu America, Inc. may invalidate the user's right to operate this equipment.
  • Page 152 Canadian Notice The device for the 5150 - 5250 MHz band is only for indoor usage to reduce the potential for harmful interference to co-channel mobile satellite systems. The maximum antenna gain of 6 dBi permitted (for devices in the 5250 - 5350 MHz, 5470 - 5725 MHz and 5725 - 5825 MHz bands) to comply with the e.i.r.p.

  • Page 153: Before Using The Optional Wireless Lan

    Before Using the Optional Wireless LAN This manual describes the procedures required to properly set up and configure the optional integrated Wireless LAN Mini-PCI device (referred to as "WLAN device" in the rest of the manual). Before using the WLAN device, read this manual carefully to ensure it's correct operation. Keep this manual in a safe place for future reference.

  • Page 154: Wireless Lan Modes Using This Device

    Wireless LAN Modes Using this Device Ad Hoc Mode "Ad Hoc Mode" refers to a wireless network architecture where wireless network connectivity between multiple computers is established without a central wireless network device, typically known as Access Point(s). Connectivity is accomplished using only client devices in a peer-to-peer fashion. That is why Ad Hoc networks are also known as peer-to-peer networks.
  • Page 155 Access Point (Infrastructure) Mode Infrastructure mode refers to a wireless network architecture in which devices communicate with wireless or wired network devices by communicating through an Access Point. In infrastructure mode, wireless devices can communicate with each other or with a wired network. Corporate wireless networks operate in infrastructure mode because they require access to the WLAN in order to access services, devices, and computers (e.g., file servers, printers, databases).

  • Page 156: Wireless Network Considerations

    Deactivating the WLAN Device Deactivation of the WLAN device may be desired in certain circumstances (to extend battery life) or where certain environments require it (i.e. hospitals, clinics, airplanes, etc.). Fujitsu mobile computers employ three methods with which to deactivate the WLAN device: •...
  • Page 157 To enable or disable either one of the devices individually, perform the following steps: Slide the Wireless Device on/off switch to On position. In the Control Panel, double-click the Fujitsu Radio Control icon. In the window that appears, click the button associated with Bluetooth and/or Wireless LAN Status to enable or disable the individual devices.

  • Page 158: Activating The Wlan Device

    Activation of the WLAN device can be accomplished using the same methods as the deactivation process • Using the Wireless On/Off Switch • By right-clicking the WLAN icon then clicking “Connect to a network” 158 Before Using the Optional Wireless LAN...

  • Page 159: Configuring The Wireless Lan

    Configuring the Wireless LAN The optional WLAN device can be configured to establish wireless network connectivity using software that is built into Windows. Support for most standard security solutions is contained in this software. Pre-defined parameters will be required for this procedure. Please consult with your network administrator for these parameters: Configuring the WLAN Click the Start button, then select Control Panel.

  • Page 160: Troubleshooting The Wlan

    Troubleshooting the WLAN Troubleshooting Causes and countermeasures for troubles you may encounter while using your wireless LAN are described in the following table. If you are unfamiliar with the steps required, consult your System Administrator or go to [Start] > Help and Support > Networking and the Web Problem Possible Cause Unavailable...
  • Page 161 Problem Possible Cause Unavailable The computer to network  be connected is connection turned off (continued) RF interference from Access Points or other wireless networks Wireless network authentication has failed Incorrectly configured network settings Incorrect IP address configuration 161 Troubleshooting the WLAN Possible Solution Check if the computer to be connected is turned ON.

  • Page 162: Wlan Specifications

    WLAN Specifications Specifications Item Type of network Transfer rate Active frequency Typical operating distances** Number of channels Security Maximum recommended number of computers to be connected over wireless LAN (ad hoc connection) Specification The Intel Wireless Advanced-N 6205 and Atheros XSPAN 802.11abgn WLAN devices conform to IEEE 802.11a, 802.11b/g, and 802.11n, Wi-Fi based*.
  • Page 163 * “Wi-Fi based” indicates that the interconnectivity test of the organization which guarantees the interconnectivity of wireless LAN (Wi-Fi Alliance) has been passed. ** The communication ranges shown above will increase or decrease depending on factors such as number of walls, reflective material, or interference from external RF sources. *** Encryption with network key (WEP) is performed using the above number of bits, however, users can set 40 bits/ 104 bits after subtracting the fixed length of 24 bits.

  • Page 164: Using The Bluetooth Device

    Using the Bluetooth Device The Integrated Bluetooth module (EYSMJCSFX) is an optional device available for Fujitsu mobile computers. What is Bluetooth Bluetooth technology is designed as a short-range wireless link between mobile devices, such as laptop computers, phones, printers, and cameras. Bluetooth technology is used to create Personal Area Networks (PANs) between devices in short-range of each other.
  • Page 165 Users are not authorized to modify this product. Any modifications invalidate the warranty. This equipment may not be modified, altered, or changed in any way without signed written permission from Fujitsu. Unauthorized modification will void the equipment authorization from the FCC and Industry Canada and the warranty.

  • Page 166: Appendix B: Fingerprint Sensor Device

    Appendix B: Fingerprint Sensor Device Introducing the Fingerprint Sensor Device Your system has a fingerprint sensor device between the left and right buttons, below the touchpad. Backward Swipe With a fingerprint sensor, you can avoid having to enter a username and password every time you want to: •...

  • Page 167: Getting Started

    Microsoft Windows operating systems. OmniPass enables you to use a "master password" for all Windows, applications, and on-line passwords. OmniPass requires users to authenticate themselves using the fingerprint sensor before granting access to the Windows desktop. This device results in a secure authentication system for restricting access to your computer, applications, web sites, and other password-protected resources.
  • Page 168 Installing the OmniPass Application If OmniPass is already installed on your system, go to “User Enrollment” on page 169. Otherwise continue with this section on software installation. • NSTALLATION OF THE APPLICATION REQUIRES THAT YOU HAVE AN EXTERNAL OPTICAL DRIVE ATTACHED TO YOUR SYSTEM •...

  • Page 169: User Enrollment

    Panel, and the OmniPass Control Center will appear. If it does not appear, then the program is not properly installed, or, Click the Start button, select Programs, and from the submenu select the Softex program group, from that submenu click OmniPass Control Center. Select the About tab at the top of the OmniPass Control Panel.
  • Page 170 “replaces” all other passwords for sites you register with OmniPass. Example: A user, John, installs OmniPass on his system (his home computer) and enrolls an OmniPass user with username “John_01” and password “freq14”. He then goes to his webmail site to log onto his account.
  • Page 171 Enter the password you use to log in to Windows. This will become the “master password” for this OmniPass user. In most cases, the Domain: value will be your Windows computer name. In a corporate environment, or when accessing corporate resources, the Domain: may not be your Windows computer name. Click [Next] to continue.

  • Page 172: Using Omnipass

    rectangle. To capture a fingerprint, gently swipe or pull your fingertip over the sensor (starting at the second knuckle) towards yourself. Swiping too fast or too slow will result in a failed capture. The Choose Finger screen has a [Practice] button; click it to practice capturing your fingerprint. When you are comfortable with how your fingerprint is captured, proceed to enroll a finger.
  • Page 173 When prompted to authenticate, you must supply the appropriate credentials: an enrolled finger for the fingerprint capture window or your master password for the master password prompt (the key icon). Remembering a Password OmniPass can remember any application, GUI, or password protected resource that has a password prompt.
  • Page 174 not prompt for authentication. Check the upper box to get this setting, and each time you navigate to this site OmniPass will log you into the site without prompting you to authenticate HIS SETTING IS MORE CONVENIENT IN THAT WHENEVER YOU GO TO A SITE REMEMBERED WITH THIS SETTING YOU WILL BYPASS ANY AUTHENTICATION PROCEDURE AND GAIN INSTANT ACCESS TO THE SITE...
  • Page 175 Logging into Windows with a Fingerprint Device When logging into Windows with a fingerprint device, the fingerprint capture window will now appear next to the Windows Login screen. Place your enrolled fingertip on the sensor to authenticate. You will be simultaneously logged into Windows and OmniPass. The capture window will also appear if you have used Ctrl-Alt-Del to lock a system, and the fingerprint device can be used to log back in as stated above.
  • Page 176 Windows, the next time you login to Windows, OmniPass will detect the password change and prompt you to “Update” or “Reconfirm” the password with OmniPass. Enter your new Windows password in the prompt and click OK. Your OmniPass "master password" will still be your Windows password. OmniPass User Identities Identities allow OmniPass users to have multiple accounts to the same site (e.g., bob@biblomail.com and boballen@biblomail.com).

  • Page 177: Configuring Omnipass

    To choose your identity during login, type your username in the User Name: field. Press [Tab] and see that the Domain: field self-populates. Click the Password: field to bring the cursor to it, and you will see the pull-down menu in the Identity: field. Select the identity to login as, then click OK. Switch User Identity To switch identities at any time, right-click the OmniPass system tray icon and click Switch User Identity from the submenu.
  • Page 178 process backs up all remembered sites, credentials, and enrolled fingerprints for an OmniPass user. All OmniPass data for a user is backed up to a single encrypted database file. During the import process, the Windows login of the exported user is required. If the proper credentials cannot be supplied, the user profile will not be imported •...

  • Page 179: Omnipass Control Center

    will need User Name, Password, and Domain. If you don’t remember the value for Domain, in a PC or SOHO environment Domain should be your computer name. OmniPass will notify you if the user was successfully imported. Things to Know Regarding Import/Export •...
  • Page 180 double-click the Softex OmniPass icon. User Management The User Management tab has two major interfaces: Add/Remove User and Import/Export User. Import/Export User functionality is documented in “Exporting and Importing Users” on page 177. Add/Remove User functionality is straightforward. If you click Adds a new user to OmniPass you will start the OmniPass Enrollment Wizard. The Enrollment Wizard is documented in “User Enrollment”...

  • Page 181: Troubleshooting

    System Settings The OmniPass Startup Options interface can be found in the System Settings tab. With these options you can specify how your OmniPass Logon is tied to your Windows Logon. The first option, Automatically log on to OmniPass as the current user, will do just as it says; during Windows login, you will be logged on to OmniPass using your Windows login credentials.
  • Page 182 Cannot add a User with a Blank Password to OmniPass If you experience difficulties adding a user with a blank password to OmniPass, you may need to adjust your local security settings. First attempt the procedure explained in the Cannot add Windows user to OmniPass section.

  • Page 183: Appendix C: Using Intel® Wireless Display

    Appendix C: Using Intel® Wireless Display Using the Wireless Display technology Intel® Wireless Display (WiDi) is a new technology that is available as an option on selected Fujitsu LIFEBOOK computers. If you have Intel WiDi on your system, please read these instructions and information regarding its use.

  • Page 184: Starting The Widi Application

    The PC content is displayed on the big screen TV. After the initial set-up between the laptop and a compatible display adapter, you can set the adapter as the default to auto-connect. In the future, simply opening the application will automatically connect the two.

  • Page 185: Index
