- Page 1 R5099 Compact Multimeter with NCV White background Transparent background 1 AN 1 YEAR White Instruction Manual REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com...
-
Page 2: Table Of Contents
Auto Power Off ..................11 Backlight ....................11 Battery Replacement ................11 Applications ....................11 Product Care .................... 12 Product Warranty ..................12 Product Disposal and Recycling .............. 12 Product Support ..................13 REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com... -
Page 3: Introduction
Introduction Thank you for purchasing your REED R5099 Compact Multimeter with NCV. Please read the following instructions carefully before using your instrument. By following the steps outlined in this manual your meter will provide years of reliable service. Product Quality... -
Page 4: Safety Symbols
400, 600V ±(2% rdg.+ 10 dgt.) DC: 400mV ±(1% rdg.+ 8 dgt.) 4, 40V ±(0.5% rdg.+ 5 dgt.) 400, 600V ±(0.8% rdg.+ 5 dgt.) Resolution: AC: 0.01, 0.01, 0.1, 1V DC: 0.1mV, 0.001, 0.01, 0.1, 1V continued... REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com... - Page 5 0.001Hz to 0.001Mz General Specifications Range Selection: Autoranging Display: 4,000 count LCD display Display Hold: Diode Test: Continuity Check: Audible signal if resistance ≤10Ω Non-Contact Voltage Detector: Auto Power Off: Yes (after 30 minutes) continued... REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com...
-
Page 6: Instrument Description
32 to 104°F (0 to 40°C) Storage Temperature: 14 to 122°F (-10 to 50°C) Dimensions: 4.4 x 2.3 x 1.4" (112 x 58 x 35mm) Weight: 6.3oz (180g) Instrument Description R5099 nm FVA Mk Ω Hz % AUTO Compact Multimeter HOLD SELECT... -
Page 7: Display Description
AUTO 1. Auto Range Indicator 4. Data Hold Indicator 2. Low Battery Indicator 5. 4000 Count Display 3. AC/DC Indicators 6. Units of measurement Operating Instructions R5099 Ω nm FVA Mk Hz % AUTO DC Voltage Measurement Compact Multimeter HOLD... -
Page 8: Dc Current Measurement
DC Current Measurement Set the function dial to the position. R5099 nm FVA Mk Ω Hz % AUTO Press the SELECT button to indicate "DC" on the LCD display. Compact Multimeter HOLD SELECT Hz % Remove power from the circuit under test, then open up the circuit at the point where you wish to measure the current. -
Page 9: Capacitance Measurement
Capacitance Measurement R5099 nm FVA Mk Ω Hz % AUTO Set the function dial to the position. Press the SELECT button to select capacitance Compact Multimeter HOLD SELECT Hz % as indicated by "nF" on the LCD display. Measure the capacitance by touching the test probe tips to the load in parallel. -
Page 10: Continuity Measurement
Continuity Measurement R5099 nm FVA Mk Ω Hz % AUTO Set the function dial to the position. Compact Multimeter Press the SELECT button to select continuity HOLD SELECT Hz % as indicated by on the LCD display. Measure the continuity by touching the test probe tips to the load in parallel. -
Page 11: Data Hold
Replace the 2 x "AAA" batteries. Secure the battery cover back and tighten the screw. Applications • Testing batteries • Testing household wiring • Testing electric motors • Testing power supplies REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com... -
Page 12: Product Care
REED Instruments guarantees this instrument to be free of defects in material or workmanship for a period of one (1) year from date of shipment. During the warranty period, REED Instruments will repair or replace, at no charge, products or parts of a product that proves to be defective because of improper material or workmanship, under normal use and maintenance. -
Page 13: Product Support
Product Support If you have any questions on your product, please contact your authorized REED distributor or REED Instruments Customer Service by phone at 1-877-849-2127 or by email at info@reedinstruments.com. Please visit www.REEDINSTRUMENTS.com for the most up-to-date manuals, datasheets, product guides and software. - Page 14 TEST & MEASURE WITH CONFIDENCE CHECK OUT OUR LATEST PRODUCTS! REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com...
