Summary of Contents for Edic PTAC
- Page 1 PTAC CLEANING CRADLE PROFESSIONAL PTAC CLEANING EQUIPMENT OWNER’S/OPERATOR’S MANUAL PROUDLY MANUFACTURED BY WWW.EDIC-USA.COM Revised 9-28-21...
- Page 2 Always read and understand your chemical’s MSDS (Material Safety Data Sheet) before use. • the CRADLE and the PTAC unit are heavy. Use prop- er lifting techniques to accomodate equipment. ask PLEASE READ BEFORE OPERATING YOUR for assistance if something is too heavy.
- Page 3 Jack adjustment handles Barn doors CRADLE Tilt controls...
- Page 4 STEP 1. Gather Hardware A, B, and C and attach the jack uprights to the base. Make sure that the mounting brackets on the jacks face each other.
- Page 5 STEP 2 Place the cradle inbetween the jack uprights and use Hardware D to secure the cradle to the jacks.
- Page 6 Front Cover INSTRUCTIONS 1. Unplug the PTAC power cord from the wall outlet and position it where it will remain dry. 2. Remove the front panel that covers the front of the entire PTAC unit. 3. Place a Shower cap over the switch panel to protect electronics.
- Page 7 8. Turn the jack handle cranks so that the front touches the bottom of the ptac. Do not let the jacks lift or put upward force on the ptac. Only a bare minimum of contact is necessary. Since the jacks lift independently of each other, make sure your cradle is level.
- Page 8 This can prevent future clogs. Place pan treatment tablets in pan and on fornt evaporator core. Raise or lower the cradle so that the PTAC is at the appropriate level to be easily inserted. In one swift motion, push the PTAC unit back into the sleeve with hands on top of PTAC.
- Page 9 Standard Rates, during the warranty period set forth above. This warranty excludes transportation charges unless authorized in writing by EDIC. No warranty returns for refund or credit will be permitted. In the event of a defect, these are your exclusive remedies. Warranty claims must be made in writing to EDIC prior to returning the product and no products will be accepted for repair or replacement without prior authorization by EDIC.
