VSW-4H-USB
4-Input HDMI Switcher with USB Output
QUICKSTART
GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VSW-4H-USB and is the answer not in the manual?

Questions and answers

Related Manuals for Elvid VSW-4H-USB

Summary of Contents for Elvid VSW-4H-USB

  • Page 1 VSW-4H-USB 4-Input HDMI Switcher with USB Output QUICKSTART GUIDE...
  • Page 3 The VSW-4H-USB features four HDMI inputs that support up to full HD 1080p video, and a USB input to upload your graphics, logos, and artwork to the switcher’s media library. Two configurable mic/stereo line inputs can add live narration or music to the production.
  • Page 4 • Do not attempt to disassemble • All images are for illustrative or repair this product—doing purposes only. so will void the warranty, and Elvid will not be responsible for any damage.
  • Page 5 OVERVIEW LINE 1 LINE 2 Mic/Line input Tally port 1 and 2 Power input HDMI inputs 1–4 Multiview output Program (PGM) output USB Type-C™ port (output) LAN port CONTENTS INCLUDE • Power supply (12 V, 2 A) • USB cable (USB Standard-A to Type-C) •...
  • Page 6 3.5 mm headphone output USB Standard-A port (input)
  • Page 7 Downstream Key (DSK) Transition Chroma/Luma selectors key selectors effects Audio controls Multiview Menu Power selector controls VSW-4H-USB MASTER MIC 1 MIC 2 CHROMA ON AIR PIP1 ON AIR WIPE HDMI 1 HDMI 2 HDMI 3 HDMI 4 LUMA ON AIR...

  • Page 8: Powering The Switcher

    POWERING SWITCHER 1. Make source and output device connections. 2. Plug the power cord into the switcher and tighten the locking ring until secure. Plug the power adapter into an outlet. 3. Press the Power button to turn on the switcher. To turn off: 1.

  • Page 9: Connecting The Inputs

    CONNECTING THE INPUTS VIDEO SOURCES Plug HDMI cameras and other HDMI sources into the switcher’s HDMI inputs 1–4. Each of the HDMI windows will display the video signals when viewing in the Multiview screen. COMPUTER CONNECTIONS Computers can be connected to the switcher via an HDMI cable or with an appropriate adapter.

  • Page 10: Audio Connections

    AUDIO CONNECTIONS Connect microphones, an audio player, smartphone, or a wireless receiver to the switcher’s audio inputs with a 3.5 mm TRS audio cable. The audio input accepts stereo unbalanced microphone and line-level signals. To set the inputs to receive a mic- or line- level signal, see the online user manual at elvidcinema.com.

  • Page 11: Connecting The Outputs

    CONNECTING THE OUTPUTS The switcher has a USB and two HDMI outputs. The HDMI outputs can be connected to monitors, a projector, or broadcast device. The USB output lets your computer simultaneously monitor the Multiview, Program (PGM), or a user-selected signal, and stream it to the internet.

  • Page 12: Program (Pgm) Output

    Use the included USB cable to connect the switcher to a computer. The computer can be used as a monitor or to stream video to the internet. Scan to download a PDF of the complete user manual, or visit elvidcinema.com/get/manual/VSW-4H-USB...

  • Page 13: Specifications

    SPECIFICATIONS INPUT/OUTPUT Video Input HDMI Type-A (×4) Audio Input MIC/Line 3.5 mm TRS female (×2) Video Output HDMI Type A (PGM) Connectors HDMI Type A (Multiview) USB 2.0 Type-C ×1 (Streaming on PC) Assignable HDMI 1 to 4 (PGM, Clean PGM, PVW, Color bar, Multiview) Monitor Output Headphone 3.5 mm TRS female...

  • Page 14: Video And Audio

    VIDEO & AUDIO Video Input Formats 1080p: 60/59.94/50/30/29.97/25/24/ 23.98 1080i: 50/59.94/60 720p: 60/59.94 /50/30/25/24 576i: 50 576p: 50 480p: 59.94/60 480i: 59.94/60 Video Output Formats 1080p: 60/59.94/50/48/47.95/30/29.97/ 25/24/23.98 1080i: 60/59.94/50 Video Sampling 4:2:2 Color Precision 8 bit Color Space Color Space Conversion Will convert RGB to YUV 4:2:2 Embedded Audio 2-channel (per output)
  • Page 15 GENERAL Keyers Upstream: Luma Key, Chroma Key, PIP (×2), Downstream: DSK, Logo Generators Pattern generator Color generator (×2) Number of Windows 6 and status (2 styles of Multiview layout) Operating System MacOS and Windows Support Power Input 120 to 240 V, 50/60 Hz Voltage 12 V Power Draw...

  • Page 16: One-Year Limited Warranty

    ONE-YEAR LIMITED WARRANTY This Elvid product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
