Signature
Calibration Procedure
The contact image sensor (CIS) of the unit is calibrated properly from the factory. With regular, basic use, the
sensor's sensitivity decreases which can lead to IMAGE errors. To resolve this issue, the unit can be
re-calibrated using the white calibration paper that came with the unit.
Please follow the steps below to calibrate the sensor:
1. Ensure the machine is turned ON.
2. On the front of the machine, press the "ADD" and "PRINT" button at
the same time. A calibration screen will display with a message
instructing you to "Open the Cover and put in the calibration paper".
3. Then turn the machine backside front. Proceed to pull the top-back cover from the machine upwards.
4. Put the provided laminated calibration card inside the top back door opening until it fits securely against the
hopper rollers.
KB-052019
2019 Kolibri USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Signature and is the answer not in the manual?

Questions and answers

Related Manuals for Kolibri Signature

Summary of Contents for Kolibri Signature

  • Page 1 3. Then turn the machine backside front. Proceed to pull the top-back cover from the machine upwards. 4. Put the provided laminated calibration card inside the top back door opening until it fits securely against the hopper rollers. KB-052019 2019 Kolibri USA...
  • Page 2 11. Reset the machine by turning it off, then on. 12. The CIS calibration is done. If, after calibrating the unit, this does not resolve the issue, please see the support section on the Kolibri USA website at www.kolibriusa.com, or contact Kolibri Support at support@kolibriusa.com for further troubleshooting. KB-052019...
