Nautronic NG12 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Service Manual
NG12
2008 - present

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NG12 and is the answer not in the manual?

Questions and answers

Related Manuals for Nautronic NG12

Summary of Contents for Nautronic NG12

  • Page 1 Service Manual NG12 2008 - present...

  • Page 3: Table Of Contents

    NG12 DIP settings, Stand-alone Squash ......................28 NG12 DIP settings, Stand-alone soccer ......................30 NG12 Board zone SW 2.15, Documentation of how board zone works in NG12 ..........32 NG08 and NG12 generation, How to replace the horn in the main scoreboards ..........39 NG08 and NG12 generation, How to replace digits ..................

  • Page 4: Block Diagram

    Block diagram Naucon-1000 Scoreboard NGIO Peripheral equipment: DCF-receiver Goal lamps NGMCB LED strips for backboard Text displays Digits Danmarksvej 1B Tel.: +45 86 51 11 66 scoreboards@nautronic.com DK-8660 Skanderborg nautronic.com...
  • Page 6 Only a short flash when button is activated. con-1000. Change of fuse. Press top of fuse holder and turn counter-clockwise. Important notice Before calling nautronic for service please go through the above instructions step by step and make notes. NAUCON-1000 – QUICK GUIDE | 10...

  • Page 7: Ng08 And Ng12 Scoreboards, Led Troubleshooting

    LED Troubleshooting NG08 and NG12 Scoreboards Revision: 1 4.2 NT Control Panel. If the Power LED ON: If wired connect NT Control Panel to the Scoreboard. If wireless, turn the NT Control Panel ON. If the NT Control Panel dose not respond and the Displays do not show text, the NT Control Panel is damaged and must be sent to repair.
  • Page 8 Description of Naucon-1000 Naucon-1000 test test menus Revision: 1 Test Menus Naucon-1000 Board info To enter the Board info menu press: ’Menu’ -> ’Exit Sport’ -> ’General Setup’ -> ’Board Info’ Diagnostic menu. The Diagnostics menu can be entered by pressing the desired address button in the Board info menu, example 11 on the display.
  • Page 9 Description of Naucon-1000 Naucon-1000 test test menus Revision: 1 Text Description DIP1 Dip setting of DIP1 in the NGI-85. DIP2 Dip setting of DIP2 in the NGI-85. DIP3 Dip setting of DIP3 in the NGI-85. Diagnostic Shows checksum of diagnostics information Wireless Power Wireless power, which can be adjusted from 0 to 17 for test purpose only.
  • Page 10 Description of Naucon-1000 Naucon-1000 test test menus Revision: 1 Diagnostic troubleshooting guide. This troubleshooting guide explains how the Diagnostic menu can be used. Function Error Fault Relay 1 Error Cable or Horn connected to J7 faulty. Relay 2 Error Cable or Horn connected to J8 faulty. Relay 3 Error NG-Out or LED-Strip connected to J9 faulty.
  • Page 11 Description of Naucon-1000 Naucon-1000 test test menus Revision: 1 Service Menu Tests To enter the service menu press: ‘Menu’->’Exit Sport’->’General Setup’->Service Menu’->enter code:’1166’. Browse to page 6/7. Test menu: This function is used to test the Scoreboard digits, dots and Text displays. Test 1: When selected, all digits and dots are turned on.
  • Page 12 NGMCB in Outdoor How to replace scoreboards Revision: 1 Removing NGMCB in outdoor scoreboards Remove the power cable from the scoreboard. Remove the three screws holding the cover. Remove the cover. Remove the two screws holding the insert. Carefully pull out the insert.
  • Page 13 NGMCB in Outdoor How to replace scoreboards Revision: 1 Remove the 7 screws holding the cover of the insert. Remove the cover from the insert. Use a flat-tip screw driver to pry open the cover starting from the back. The cover is very tight.

  • Page 14: Ngmcb In Outdoor Scoreboards, How To Replace

    NGMCB in Outdoor How to replace scoreboards Revision: 1 Pull out the NGMCB by holding the three RJ45 connectors. Push in the new NGMCB. Make sure the connectors are completely mated. Reassemble the insert and scoreboard. If the scoreboard is controlled by a Naucon-1000 the board zone setup has to be transmitted to the scoreboard.
  • Page 15 MCB sw update Description of how to updateNG08/NG12 scoreboards Revision: 1 How to update software in scoreboard The main board for the scoreboard is placed at the bottom of the scoreboard, where the power cable for the scoreboard is connected.

  • Page 16: Ng08 And Ng12, How To Find The Dip-Switches

    NG08 and NG12 How to find the DIP- switches Revision: 1 How to find the DIP-switches. 1. Turn of the power of the Scoreboard. 2. Locate the NGI-85 power-box in the buttom of the Scoreboard. 3. Remove the four screws and the see-through plastic cover.

  • Page 17: Ng12 Dip-Settings And Functions

    DIP-Settings and Functions Revision: 2 NG12 DIP-Setting information. This document describes how to read, set and edit the functions of the NG12 generation Scoreboards via the DIP-Switches DIP1, DIP2 and DIP3. How to read the DIP-Switch. The black square indicates the position of the switch.
  • Page 18 DIP-Settings and Functions NG12 Revision: 2 DIP-Switch functions. This sheet shows the functions off DIP-Switch 1, 2 and 3. Function ( OFF ) Function ( ON ) Master. No function. Slave. No function. Not used. Not used. Not used. Light sensor connected Not used.
  • Page 19 NG12 DIP-Settings and Functions Revision: 2 4.3 Channel Select. This sheet shows how the channels are selected via DIP switch 2. Channel select. DIP2, No. Naucon-1000 Wireless Channels. Fixed channels. 1 ON. Channel 1. 1 ON. Channel 2. 1 and 3 ON.
  • Page 20 Main Scoreboards NG12 DIP Settings Revision: 1 NG12 DIP Settings for Main Scoreboards. This document describes how the default addresses for Main Scoreboards are set. The black square indicates that the DIP Switch is pushed up/set to ON. Each Scoreboard has its own address.

  • Page 21: Ng12 Dip Settings Main Scoreboards

    Main Scoreboards NG12 DIP Settings Revision: 1 March 26, 2013 Page 2...
  • Page 22 NG12 DIP Settings Revision: 1 NG12 DIP Settings for Main and Side boards. This document describes how the default addresses for Main and Side Scoreboards are set. The black square indicates that the DIP Switch is pushed up/set to ON.
  • Page 23 Main and Side Scoreboards NG12 DIP Settings Revision: 1 February 7, 2013 Page 2...

  • Page 24: Ng12 Dip Settings Main And Side Scoreboards

    Main and Side Scoreboards NG12 DIP Settings Revision: 1 1.2 Home Sideboards. Address DIP3 DIP2 DIP1 February 7, 2013 Page 3...
  • Page 25 Main and Side Scoreboards NG12 DIP Settings Revision: 1 1.3 Guest Sideboards. Address DIP3 DIP2 DIP1 February 7, 2013 Page 4...
  • Page 26 Synchronized Shot Clocks NG12 DIP Settings Revision: 1 NG12 DIP Settings for Synchronized Shot Clocks. This document describes how the default addresses for Synchronized Shot Clocks are set. The black square indicates that the DIP Switch is pushed up/set to ON.

  • Page 27: Ng12 Dip Settings Synchronized Shot Clocks

    Synchronized Shot Clocks NG12 DIP Settings Revision: 1 February 6, 2013 Page 2...

  • Page 28: Ng12 Dip Settings, Stand-Alone Tennis

    Stand-alone Tennis NG12 DIP Settings Revision: 2 NG12 DIP Settings for Stand-alone Tennis. This document describes how the default addresses for Stand-alone Tennis is set. The black square indicates that the DIP Switch is pushed up/set to ON. Each Stand-alone Tennis Scoreboard has its own address.
  • Page 29 Stand-alone Tennis NG12 DIP Settings Revision: 2 No. Address DIP3 DIP2 DIP1 Naucon-30 No. Address DIP3 DIP2 DIP1 Naucon-30 No. Address DIP3 DIP2 DIP1 Naucon-30 No. Address DIP3 DIP2 DIP1 Naucon-30 March 8, 2013 Page 2...

  • Page 30: Ng12 Dip Settings, Stand-Alone Squash

    Stand-alone Squash NG12 DIP Settings Revision: 1 NG12 DIP Settings for Stand-alone Squash. This document describes how the default addresses for Stand-alone Squash is set. The black square indicates that the DIP Switch is pushed up/set to ON. Each Stand-alone Squash Scoreboard has its own address.
  • Page 31 Stand-alone Squash NG12 DIP Settings Revision: 1 No. Address DIP3 DIP2 DIP1 Naucon-30 No. Address DIP3 DIP2 DIP1 Naucon-30 No. Address DIP3 DIP2 DIP1 Naucon-30 No. Address DIP3 DIP2 DIP1 Naucon-30 February 15, 2013 Page 2...

  • Page 32: Ng12 Dip Settings, Stand-Alone Soccer

    Stand-alone Soccer NG12 DIP Settings Revision: 1 NG12 DIP Settings for Stand-alone Soccer. (Naucon-10B) This document describes how the default addresses for Stand-alone Soccer is set. The black square indicates that the DIP Switch is pushed up/set to ON. Each Stand-alone Soccer Scoreboard has its own address.
  • Page 33 Stand-alone Soccer NG12 DIP Settings Revision: 1 No. Address DIP3 DIP2 DIP1 Naucon-10 No. Address DIP3 DIP2 DIP1 Naucon-10 No. Address DIP3 DIP2 DIP1 Naucon-10 No. Address DIP3 DIP2 DIP1 Naucon-10 May 12, 2015 Page 2...

  • Page 34: Description Of Board Zone For Ng12 Scoreboards

    SW 2.15 Revision: 1 Description of Board zone for NG12 scoreboards This document describes how the setup of multiple scoreboards works in NG12 scoreboard systems controlled by a Naucon-1000. For software version 2.15 and forward Content Description of Board zone for NG12 scoreboards ....................1 General Information ..............................

  • Page 35: Standard Scoreboard Addresses

    Documentation of NG12 Board Zone How board zone works in NG12 SW 2.15 Revision: 1 2.1 Standard Scoreboard addresses. Each Scoreboard type has an address. 10-19: Addresses Main Scoreboards. Default is 11. 20-29: Addresses Sideboard Home/Left side. Default is 21.

  • Page 36: Board Zone Selection

    Documentation of NG12 Board Zone How board zone works in NG12 SW 2.15 Revision: 1 It is important that the scoreboard is turned on and within range of the Naucon-1000 when pressing accept. The addresses on the scoreboard are only used as identification of the scoreboard for diagnostics and for setting the zone for a scoreboard.

  • Page 37: Wireless Channel

    Documentation of NG12 Board Zone How board zone works in NG12 SW 2.15 Revision: 1 2.5 Wireless channel If more than one Scoreboard System is placed in one arena or within 150 meters of each other, each Naucon-1000 unit must be configured to transmit on its own Wireless channel. This is obtained through the board zone selection, where the wireless channel is determined by the lowest zone ON.

  • Page 38: Example

    Documentation of NG12 Board Zone How board zone works in NG12 SW 2.15 Revision: 1 Example Shows an example of how to setup and control 4 scoreboard systems separately in the same arena. Example of how to setup Naucon-1000 to control 4 scoreboards at the same time...

  • Page 39: Setup Of 4 Scoreboards In One Arena

    Documentation of NG12 Board Zone How board zone works in NG12 SW 2.15 Revision: 1 3.1 Setup of 4 scoreboards in one arena Board zone setup The following pictures show examples on how the four Naucon-1000 units could be configured for the four courts, all 4 Naucon-1000 should be setup identically in board zone setup.
  • Page 40 Documentation of NG12 Board Zone How board zone works in NG12 SW 2.15 Revision: 1 Board zone selection Next the board selection is set for each Naucon-1000. For scoreboard 1 Zone 1 is ON. For scoreboard 2 Zone 2 is ON.
  • Page 41 6. Mount the new Horn with the washer and bolt. 7. Reconnect the cable from the new Horn on 8. Reassemble the Scoreboard 9. Done. November 8, 2012 C:\Documents and Settings\TEKNIK08.NAUTRONIC\Skrivebord\Færdigt Page 1 dokumantation af AP\Scoreboads\NG08 and NG12 HowToReplaceHorn\DOK\NG08 and NG12 HowToReplaceHorn.doc...

  • Page 42: Ng08 And Ng12 Generation, How To Replace Digits

    DIP-Setting scheme that was filled in the top. 10. Turn on the power for the Scoreboard, and check that new Digit is working. 11. Reassemble the Scoreboard. May 8, 2012 H:\Dok_service\NG-2000-\NG08 and NG12 Page 1 HowToReplaceDigit\ENG\DOK\NG08 and NG12 HowToReplaceDigit.doc...

  • Page 43: Ng08 And Ng12, Dip Settings For Main Scoreboard

    DIP Settings for Main Scoreboard Revision: 1 1.NG08 and NG12 DIP Settings. This sheet is developed, to check all the DIP settings that are possible. 1.1Main Scoreboard (Middle section) with 21 cm digits and lower. RTC - Time of Day Clock 24.
  • Page 44 NG08 and NG12 DIP Settings for Main Scoreboard Revision: 1 1.2 Main Scoreboard (Middle section) with 21-33 cm digits. 24. may 2012 Page 2...

  • Page 45: Ng12, Ng12 Sideboard And Text Display Dip Settings

    NG12 Sideboard NG12 and Text Display DIP Settings Revision: 2 1.NG12 DIP Settings. This sheet shows the addresses of the Sideboards 1.1Sideboards. Home: 12-05-2015 Page 1...
  • Page 46 NG12 Sideboard NG12 and Text Display DIP Settings Revision: 2 Home (continued): 12-05-2015 Page 2...
  • Page 47 NG12 Sideboard NG12 and Text Display DIP Settings Revision: 2 Guest: 15. November 2012 Page 2...
  • Page 48 NG12 Sideboard NG12 and Text Display DIP Settings Revision: 2 Guest (Continued): 12-05-2015 Page 4...
  • Page 49 NG12 Sideboard NG12 and Text Display DIP Settings Revision: 2 1.1 Team Text-display. Home: Guest: 12-05-2015 Page 5...
  • Page 50 Description of Cable connection Naucon-1000 Cable for Naucon-1000 to scoreboards Connection Revision: 1 Description This document describes the important issues with a wired scoreboard system controlled from a Naucon-1000 and recommended cable setup for scoreboard system. Connection 2.1 Recommended wiring For correct wiring the standard RS-485 is used as the physical layer for communication.
  • Page 51 Description of Cable connection Naucon-1000 Cable for Naucon-1000 to scoreboards Connection Revision: 1 2.1.2 Scoreboard connection The best connection between the scoreboards is a daisy-chain as shown below. The star connection as shown below or other connections like this should be avoided. As this will effect the quality of the signal greatly. The final scoreboard in the chain needs a termination resistor NG-term to avoid reflections which will affect the quality of the signal.
  • Page 52 Description of Cable connection Naucon-1000 Cable for Naucon-1000 to scoreboards Connection Revision: 1 2.1.3 Solution with repeater An option for improving the signal in an arena is to use a repeater attached to the cable between the scoreboards. It can be very useful for arenas with very long wires or many star configurations. Multiple repeaters can be used to further improve the signal.

  • Page 53: Find Spareparts For Ngmcb

    Find spareparts for NGMCB Delivered: 2010-2012 NQA2164 NQA2130 NC21750 NHA4619 Sparepart: Sparepart: Sparepart: Sparepart: 92050000 92050002 92050002-10 92050002-20 (SW-T08-01) (SW-T08-01) (SW-T08-10) (SW-T08-20) Naucon-20 Naucon-10 NT pult NT pult Delivered: 2012 – present NA2164 NA2130 NC21750 NHA4619 Sparepart: Sparepart: 92050004 92050006 (SW-T12) (SW-T12) Naucon-10B...

  • Page 54: Find Spare Parts For Naucon 10, 20, 30, 40

    Find spareparts for Naucon 10, 20, 30, 40 Delivered: 2013-present Delivered: 2010-2013 Naucon-10 Naucon-10B Standard DIP settings Standard DIP settings 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 Sparepart: Sparepart: 92051011 92051010 Delivered: 2013-present Delivered: 2010-2013 Naucon-20...

  • Page 55: Find Spareparts For Ngi-85

    Find spareparts for NGI-85 NGI-85spareparts Spareparts, cables for digits: Cables for digits: BK7-300: 92050940 BK7-300, 7 headers, 300cm BK7-395: 92050941 BK7-395, 7 headers, 395cm BK13-510: 92050942 BK13-510, 13 header, 510cm NGCON Sparepart: 92050020 NG-LS Sparepart: 9205094 NGIO / NGIO-DCF NGMAIN NG-OUT Spareparts: Sparepart:...

  • Page 56: Find Spareparts For Naucon-1000

    Find spareparts for Naucon-1000 Naucon-1000 accessories NG112 Wall box Cable KNGM50 Naucon-1000 Power suply Sparepart: Sparepart: Sparepart: Sparepart: 92050916 92050915 92051000 92050080 Naucon-1000 Internal Spareparts Battery 12v Li Spareparts: 92050912 NGCHARGE-C Sparepart: 92050910 Naucon-1000UPC Sparepart: 92050900 NGNaubee Radio (on backside of baord) Sparepart: 920509500 3:Display TFT5,7T...
  • Page 57 NG12 Spareparts list Spareparts Revision: 1 Main spareparts Sparepart number Name 92050000 NGMCB, SW-T08-01 sc. Board 92050002 NGMCB-R SW-T08-01 sc. Board 92050002-10 NGMCB-R SW-T08-10 shot clock 92050002-20 NGMCB-R SW-T08-20 football 92050004 NGMCB-12 SW-T12 sc. Board, no radio 92050006 NGMCB-12R SW-T12 sc. Board w/ radio...
  • Page 58 NG12 Spareparts list Spareparts Revision: 1 Digits and text displays Sparepartnumber Name Description Inddor/Outdoor textline sw version 92040108 DG-PKT, sparepart 15cm 1 Rows Fouls dots big Indoor 92040109 DG-2PKT, sparepart 12cm 2 Rows. Fouls dots small Indoor 92040110 DG-4PKT, sparepart 4 Rows.
  • Page 59 NG12 Spareparts list Spareparts Revision: 1 92043315 DG21-99BH, sparepart DisplayH 21cm. red 99 Outdoor 92044101 D26, sparepart Display 26cm. Red Indoor 92044103 DG26-99, sparepart Display 26cm. red :99# Indoor 92044104 DG26-X99, sparepart Display 26cm. red :99/199 Indoor 92044107 D26T, sparepart...

  • Page 60: Ngio, Description Of Connections For Ngio

    Description of connections for NGIO NGIO Revision: 3 Description This document describes the connection possibilities for NGIO extension board for a MCB Connections 2.1 NG-DCF Connection NGIO J7 Wire Function White White Signal Brown Ground Brown 13-03-2015 Page 1...
  • Page 61 Description of connections for NGIO NGIO Revision: 3 2.2 Temperature sensors ( 3 possible) Three temperature sensor can be connected to the NGIO. 24VDC and ground are common for all three sensor. The number of sensors is detected automatically. J4 NGIO Wire Temp.
  • Page 62 Description of connections for NGIO NGIO Revision: 3 2.4 NS255 Goal lamp connection Goal lamp J3 NGIO Wire Function Pin 3 Blue Brown Red lamp 24VDC Black Ground Brown Pin 1 Blue Green lamp 24VDC Black Pin 2 2.5 Shot Clock yellow LED strip (NG270) When the NGI DIP settings is set as a synchronized shot clock (DIP address 4x), Relay 2 is activated when shot clock time runs out (From sw.
  • Page 63 How to change Addresses NG08 Naucon Handle and Scoreboard Revision: 2 How to change Addresses. The Handle ID of the Scoreboard and Naucon handle must be changed, if more than one Scoreboard is placed within 150 meters, to avoid any interfere with each other. 1.1 How to get to the DIP-Switch in the Naucon Remote.
  • Page 64 How to change Addresses NG08 Naucon Handle and Scoreboard Revision: 2 1.2 How to get to the DIP-Switch in the Scoreboard. 1. Unscrew the two upper screws holding the See-through Acryl plate, in front of the NGI-85 power module. 2. Remove the See-through Acryl plate. 3.
  • Page 65 DIP-Switch settings. NG08 Standalone Shot Clocks PAN ID Revision: 1 NG08 Standalone Shot Clocks PAN ID. This instruction describes how the DIP-switches are accessed and set in the Shot Clocks and Naucom-20 to edit the PAN ID, if multiple Standalone Shot Clocks must function in one arena, without disturbing each other.
  • Page 66 DIP-Switch settings. NG08 Standalone Shot Clocks PAN ID Revision: 1 5. Orient the Naucon-20 like shown on the picture, with the numbers readable in the bottom of the DIP-Switch. How to read the DIP-Switch. If a black square is shown at the top, it indicates that the switch is ON.
  • Page 67 DIP-Switch settings. NG08 Standalone Shot Clocks PAN ID Revision: 1 3.1.2 PAN ID 9. NGI-85 DIP-Switch. Primary. DIP 2 Secondary. DIP 2 Naucon-20 DIP-Switch: 3.1.3 PAN ID 10. NGI-85 DIP-Switch. Primary. DIP 2 Secondary. DIP 2 Naucon-20 DIP-Switch: August 21, 2012 Page 3...
  • Page 68 DIP-Switch settings. NG08 Standalone Shot Clocks PAN ID Revision: 1 3.1.4 PAN ID 11. NGI-85 DIP-Switch. Primary. DIP 2 Secondary. DIP 2 Naucon-20 DIP-Switch: 3.1.5 PAN ID 12. NGI-85 DIP-Switch. Primary. DIP 2 Secondary. DIP 2 Naucon-20 DIP-Switch: August 21, 2012 Page 4...
  • Page 69 DIP-Switch settings. NG08 Standalone Shot Clocks PAN ID Revision: 1 3.1.6 PAN ID 13. NGI-85 DIP-Switch. Primary. DIP 2 Secondary. DIP 2 Naucon-20 DIP-Switch: 3.1.7 PAN ID 14. NGI-85 DIP-Switch. Primary. DIP 2 Secondary. DIP 2 Naucon-20 DIP-Switch: August 21, 2012 Page 5...
  • Page 70 DIP-Switch settings. NG08 Standalone Shot Clocks PAN ID Revision: 1 3.1.8 PAN ID 15. NGI-85 DIP-Switch. Primary. DIP 2 Secondary. DIP 2 Naucon-20 DIP-Switch: August 21, 2012 Page 6...

  • Page 71: How To Open The Scoreboard

    How to open the scoreboard 1: Remove the screws in the side of the scoreboard. 2: Slide the coverplate to the side. Important , When you slide the coverplate back in place, be careful not to hit any electronics in the scoreboard. This can destroy or shorten the lifetime of the scoreboard.

  • Page 72: Ng08 Dip Settings - Standard

    NG08 DIP SETTINGS - standard MAIN BOARD ADDR. (PAN ID = 14) 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8...

  • Page 73: Ng08 Dip Settings - Football Etc

    NG08 DIP SETTINGS - football etc. Standalone soccer controlled by Naucon-10 2 TIME DIGITS BOARD ADDR. (PAN ID = 14) PRIMARY 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 4 TIME DIGITS BOARD ADDR.

  • Page 74: Ng08 Dip Settings - Shot Clocks

    NG08 DIP SETTINGS - shot clocks Standalone shot clocks controlled by Naucon-20 NC21750, NC26750 BOARD ADDR. (PAN ID = 8) PRIMARY 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 SECONDARY 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8...
