- Page 1 INSTRUCTION MANUAL 15 17 "/ "/19"/20.1" COLOR TFT-LCD MONITOR Please read this manual thoroughly before use, and keep it handy for future reference.
- Page 3 WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS. CAUTION: CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER(OR BACK).
- Page 4 FCC COMPLIANCE STATEMENT INFORMATION TO THE USER: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS B DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE IN A RESIDENTIAL INSTALLATION.
- Page 5 IMPORTANT SAFEGUARDS READ INSTRUCTIONS -- All the safety and operating POWER CORDS -- Do not allow anything to rest on the instructions should be read before the appliance is operated. power cord. Do not locate video monitor or equipment where the cord will be abused by persons walking on it.
-
Page 6: Table Of Contents
TABLE OF CONTENTS Features Installation Connections Operating Instructions - Controls Backside Connections User Controls - Menu Operations Specifications Bracket Features Stand Features - 5 -... -
Page 7: Features
FEATURES - Go-Anywhere Professional Color LCD Monitor High Bright, High Quality Picture NTSC and PAL in Composite and Y/C Thin and Lightweight, Rugged Metal Cabinets Many Mounting and Installation Options Low-Power Consumption-12 volts DC Operation Full Set of Video Controls, Flexible Input Connections - 6 -... -
Page 8: Installation
INSTALLATION LCD monitors may be mounted in any position or orientation. Considerations for mounting include regard for how the monitor is going to be used, routing of connecting cords, and locations away from heat sources (including direct sunshine on the black case). Mounting hard points include 10-32 inserts. - Page 9 Click Add New Hardware Click Next - 8 -...
- Page 10 Click Next Click Next after selecting No, the device isn't in the list - 9 -...
- Page 11 Click Next after selecting No, I want to select the hardware from a list Click Next after selecting Monitors - 10 -...
- Page 12 Click Have Disk... Insert the supplied 3.5" floppy disk in A Drive. Select - 11 -...
- Page 13 15" LCD MONITOR Select Next after selecting the same model which you purchased. Click Finish - 12 -...
- Page 14 Installaion Guide for Video Driver Microsoft Windows 2000 Operating System 1. Click "Start" "Setting" "Control Panel" 2. Double click the "Display" Icon. 3. Choose the "Settings" tab and then click "Advanced.." 4. Choose "Monitor" Case1: If the "Properties" button is inactive, it means your monitor is properly configured. Please stop installation Case2: If the "Properties"...
-
Page 15: Connections
CONNECTIONS To make a normal connection to the monitor, bring a cord from a camera or other video source to one of the BNC jacks or from a PC to the PC jack on the back of the monitor. Either the left or right BNC jack can be used for input. The other jack may be optionally connected to another user of the same signal. -
Page 16: Operating Instructions - Controls
OPERATING INSTRUCTIONS - Controls Control Buttons, Video Monitor Front. Use a cloth dampened with a mild cleaner to clean the screen. 1. Power On/Off When power is applied, the monitor will come on. This button then turns the monitor on and off. 2. -
Page 17: Backside Connections
BACKSIDE CONNECTIONS 15",17", 19" 20.1" DC1 2V DC1 2V S-VID EO AUDIO VIDEO VIDEO AUDI O S-VID EO Typical Color LCD Video Monitor Back 1. Input Connector Wall Recessed wiring location for all cables. Place the plug from the supplied table- top power supply into the DC 12V connector. -
Page 18: User Controls - Menu Operations
USER CONTROLS - Menu Operations Brightness : 25 Contrast : 41 Clock : 125 Phase : 16 Auto : Stop H Position V Position RGB Offset Image Effect Volume : 10 Language : English Input : PC Recall : No Pushing the MENU button will bring up the Menu shown above. - Page 19 Language: English sets the OSD language of the menu to English. Deutsch sets the OSD language of the menu to German. Fran ais sets the OSD language of the menu to French. Italiano sets the OSD language of the menu to Italian. Espa ol sets the OSD language of the menu to Spanish.
- Page 20 Sharpness sets the desired sharpening enhancement to the picture. Color adds coloring to the block and white picture content (of a color signal), and is usually set for pleasing faces. Tint adjusts all the colors on the screen, but is most noticeable to the eye in reds and yellows, and is also usually set for pleasing face tones.
-
Page 21: Specifications
SPECIFICATIONS-15inch LCD panel 15.0 inches TFT LCD Panel Active display area (Diagonal) 15.0 inches Pixel format 1024(H) x 768(V), RGB vertical stripe Pixel pitch 0.297mm x 0.297mm Color depths 8 Bit / 16.0M Colors Contrast ratio 400:1 (Typical) Brightness 250 cd/m (Typical) Viewing angles (L/R/U/D) 65/65/45/60 (Typical) Light source / Lifetime... - Page 22 Bright, Contrast, Tint, Color, Sharpness, etc User controls English / French / German / Italian / Spanish / Polish OSD Language 12VDC, 3.0A Power requirement 30 Watts (Standby 2Watts Power consumption Barrel, 5.5/2.1mm(+ Center) DC power connector IEC-320 Male, 100 - 240VAC AC power connector Net: 349.2mm(W) x 285.7mm(H) x 43mm(D) Dimensions...
- Page 23 SPECIFICATIONS-17inch LCD panel 17.0 inches TFT LCD Panel Active display area (Diagonal) 17.0 inches Pixel format 1280(H) x 1024(V), RGB vertical stripe Pixel pitch 0.264mm x 0.264mm Color depths 8 Bit / 16.2M Colors Contrast ratio 350:1 (Typical) Brightness 250 cd/m (Typical) Viewing angles (L/R/U/D) 75/75/65/60 (Typical) Light source / Lifetime...
- Page 24 Bright, Contrast, Tint, Color, Sharpness, etc User controls English / French / German / Italian / Spanish / Polish OSD Language 12VDC 3.25A Power requirement 41 Watts (Standby 2Watts Power consumption Barrel, 5.5/2.1mm(+ Center) DC power connector IEC-320 Male, 100 - 240VAC AC power connector Net: 398mm(W) x 334mm(H) x 49.5mm(D) Dimensions...
- Page 25 SPECIFICATIONS-19inch LCD panel 19.0 inches TFT LCD Panel Active display area (Diagonal) 19.0 inches Pixel format 1280(H) x 1024(V), RGB vertical stripe Pixel pitch 0.294mm x 0.294mm Color depths 8 Bit / 16.7M Colors Contrast ratio 500:1 (Typical) Brightness 250 cd/m (Typical) Viewing angles (L/R/U/D) 85/85/85/85 (Typical) Light source / Lifetime...
- Page 26 Bright, Contrast, Tint, Color, Sharpness, etc User controls English / French / German / Italian / Spanish / Polish OSD Language 12VDC 3.5A Power requirement 45 Watts (Standby 2Watts Power consumption Barrel, 5.5/2.1mm(+ Center) DC power connector IEC-320 Male, 100 - 240VAC AC power connector Net: 419mm(W) x 362mm(H) x 54mm(D) Dimensions...
- Page 27 SPECIFICATIONS-20.1inch LCD panel 20.1 inches TFT LCD Panel Active display area (Diagonal) 20.1 inches Pixel format 640(H) x 480(V), RGB vertical stripe Pixel pitch 0.6375mm x 0.6375mm Color depths 8 Bit / 16.7M Colors Contrast ratio 400:1 (Typical) Brightness 400 cd/m (Typical) Viewing angles (L/R/U/D) 70/70/55/65 (Typical) Light source / Lifetime...
- Page 28 User controls Bright, Contrast, Tint, Color, Sharpness, etc OSD Language English / French / German / Italian / Spanish / Polish Power requirement 12VDC, 4.25A Power consumption 60 Watts(Standby 2Watts DC power connector Barrel, 5.5/2.5mm(+ Center) AC power connector IEC-320 Male, 100 - 240VAC Dimensions(W x H x D) Net: 471mm(W) x 380mm(H) x 56mm(D) Packing: 589mm(W) x 499mm(H) x 170mm(D)
-
Page 29: Bracket Features
BRACKET FEATURES-Optional - Light duty wall & ceiling mount - Adjustable swivel head - Die cast and aluminum - Cable feed through hole conceals wiring - PT 1 threaded pipe - Maximum load 20 lb ( 9.0kg ) The Bracket is light duty wall & ceiling mount designed for use with LCD monitor. -
Page 30: Stand Features
STAND FEATURES-15",17",19",20.1" Optional 1-1. FH4X6 size SCREW 1-2. M4 size SCREW METAL PLATE HINGE HINGE_COVER STAND SECTION MONITOR STAND In order to install the desk-top stand at LCD monitor properly, First, fix the metal plate provided to LCD monitor with 4 screws of only FH4X6 size only and the desk-top stand to the metal plate with 4 screw of M4 size. - Page 32 COLOR 15"/17"/19"/20.1" TFT-LCD MONITOR 50301679A...
