- Page 2 Thank you for purchasing a Pro‐LIFT SLK Cart. This mobile product is designed to enhance your interactive LCD/LED. Please follow all assembly instructions correctly to provide optimal use. Only a qualified contractor should install the Pro‐LIFT SLK Cart. If you do not understand any of the assembly instructions, please contact your local re‐seller. IMPROPER INSTALLATION CAN CAUSE DAMAGE TO YOUR Pro‐LIFT SLK Cart AND LEAD TO SERIOUS PHYSICAL INJURY. JORO Manufacturing cannot take any responsibility for damage or injury resulting from improper installation. Do not maneuver Pro‐LIFT SLK Cart if the locking screws are not present or there are any obstructions within the Pro‐LIFT SLK Cart vicinity. Doing so may cause unit malfunction or lead to serious physical injury. The supplied mounting hardware is for use on the Pro‐LIFT SLK Cart stands only. If you encounter any problems or insufficient hardware during installation, please contact your local re‐seller. ...
- Page 3 SLK Cart Kit 3/8" x 2" Lg. - 5/16" Hex Socket Head Shoulder Bolt 5/16" Acorn Nut 1/4" ID x 3/8" Lg. Nylon Spacer 5/16 Jam Nut 5/16 Hex Nut 1/4" Washer USS Tube1020 End Cap 5/32" Allen (Hex) Key 3/16"...
- Page 4 M6 x 8mm Socket Cap Screw 1 Mount Casters Use the M6 x 8mm Socket Cap Screws DO NOT over tighten www.joromfg.com www.proliftstand.com COPYRIGHT 2017 SLK Cart ASSY Instructions : 0.001...
- Page 5 2 M6x25mm Button Head Left Leg Right Leg Left Foot Label - Circle NOTE: MATCH THE LABELS ON THE FOOT AND LEG Right Foot Mount the feet to the main frame Be sure to match circle label on foot and leg Use the M6x25mm Button Head screws supplied DO NOT over tighten www.joromfg.com...
- Page 6 M6x25mm Button Head 3 SLK Cart Top Platform Mount SLK Cart top platform Use the M6x25mm Button Head screws supplied DO NOT over tighten www.joromfg.com www.proliftstand.com COPYRIGHT 2017 SLK Cart ASSY Instructions : 0.001...
- Page 7 4 5/16" Acorn Nut 3/8" x 2" Lg. - 5/16" Hex Socket Head Shoulder Bolt 3/8" x 2" Lg. - 5/16" Hex Socket Head Shoulder Bolt Fasten the shoulder bolts 5/16" Acorn Nut Note three (3) mounting positions, see above for details Use the 3/8"...
- Page 8 Tube1020 End Cap 5/16 Jam Nut 1/4" Washer USS Tube1020 End Cap 1/4" Washer USS 5 5/16x1" SILVER Button Head Fasten the 5/16x1" SILVER Button Head Screws to the TUBE1020 DO NOT over tighten Use a rubber mallet to knock the Tube1020 End Caps into place 5/16x1"...
- Page 9 6 Please use the appropriate mounting holes for your LCD (not included)as shown above G5-ACC-SLK1000 G5-ACC-SLK1000 LCD Fastener from LCD TV Kit provided Fasten the G5-ACC-SLK1000 to your LCD (not included) using the fasteners from the LCD TV Kit Use the appropriate fasteners as specified in the LCD owners manual Please note spacers/washers may be required to acheive length.
- Page 10 7 1/4" ID x 3/8" Lg. Nylon Spacer JORO Button Head Fasten bumpers to outside face as shown Use the JORO Button Head and nylon spacers supplied DO NOT over tighten 8 1/4" Washer USS SLK Cart Left Arm 1/4" Washer USS...
- Page 11 9 SLK Cart Right Arm SLK Cart Left Arm M6 x 12mm Socket Cap Screw SILVER Locking Hole M6 x 12mm Socket Cap Screw SILVER Locking Hole 1/4" Washer USS Hang the SLK Cart Arms for locking Hang both SLK Cart Arms over shoulder bolts Locate the locking holes and insert fasteners Lock the SLK Cart Arms Use the M6 x 12mm Socket Cap Screw SILVER and 1/4 Washer USS supplied...
-
Page 12: Customer Satisfaction Survey
CUSTOMER SATISFACTION SURVEY JORO Manufacturing would like to know what you think about our Pro‐LIFT product line, so we can continue to provide you with best product/service we can. Please help us by taking a few moments to fill out the survey below. 1. What are the two things you like most about our product/service? ...................... ...................... 2. Would you recommend our product/service to a friend? Yes No 3. If so, what reason would you give them for the recommendation? ...................... ...................... ...................... 4. Have you bought other products/services like ours? Yes (Please give details)............. No ............. ........ 5. Why did you buy those particular products/services? ...................... ...................... 6. Why did you stop buying those products/services to buy ours? ...................... ...................... 7. On a scale of 1 to 10, with 1 being not at all satisfied and 10 extremely satisfied, where would you rank your experience with our product/service? (Please circle one) 1 2 3 4 5 6 7 8 9 10 Thank you. Now please return the completed survey to JORO Manufacturing: JORO Manufacturing Ltd. 48 East Lake Green NE Airdrie, AB, Canada ...
