- Page 2 Thank you u for purchas ing a KS42P. T This mobile p product is des signed to enh ance your int teractive SMA ART kapp™. Pl ease follow a all assembly in nstructions co orrectly to pr rovide optima al use. Only a qu alified contra actor should i nstall the KS4 42P. If you do o not understa and any of th he assembly instructio ns, please co ntact your lo cal re‐seller. IMPROPE R INSTALLATI ION CAN CAU USE DAMAGE TO YOUR KS4 42P AND LEA D TO SERIOU S PHYSICAL INJURY. JO ORO Manufac...
- Page 3 5/16" Acorn Nut 1/4" ID x 3/8" Lg. Nylon Spacer 1/4" Washer 5/32" Allen (Hex) Key 3/16" Allen (Hex) Key Note: Parts may not be exactly as shown and not to scale www.joromfg.com COPYRIGHT 2014 KS42P ASSY Instructions : 0.005...
- Page 4 M6 x 40mm Partial Thread Socket Cap Screw 1/4" Washer Mount KS42P Upright For ease of installation lay the KS42P Uprights on sides as shown above Be sure KS42P locking holes are to the inside/facing each other Be sure KS42P uprights lean away from concave cut...
- Page 5 M6 x 20mm Socket Cap Screw Low Profile Mount KS42P top platform Be sure to use the M6 x 20mm Socket Cap Screw Low Profile supplied Be sure to NOT over tighten www.joromfg.com COPYRIGHT 2014 KS42P ASSY Instructions : 0.005...
- Page 6 Be aware of two mounting positions, see above for details Be sure to use the 3/8" x 2" Lg. - 5/16" Hex Socket Head Shoulder supplied Be sure to NOT over tighten www.joromfg.com COPYRIGHT 2014 KS42P ASSY Instructions : 0.005...
- Page 7 Nylon Spacer JORO Button Head Fasten the bumpers Be aware of angle positions, see above for details Be sure to use the JORO Button Head and nylon spacers supplied Be sure to NOT over tighten 5 KS42P Right Arm KS42P Left Arm...
- Page 8 M6 x 12mm Socket Cap Screw SILVER M6 x 12mm Socket Cap Screw SILVER Hang the KS42P Arms for locking Be sure to hang both KS42P Arms over shoulder bolts Once hung, locate the locking holes Lock the KS42P Arms...
