WLL-TR-1p-II
Transmitter Box Contents
1- WLL-TX1 wireless transmitter
1- Power supply
Output: 5VDC 1.2A
2- Half rack mount adapters
2- Antenna
RX unit- Receiver/Amp
RX unit- Receiver/Amp
FCC ID: XCO-HSWLLT IC:7756A-HSWLLT
Warning
SoundTube products must be installed by a professional audio installer/contractor. For safety
and for optimum audio performance, installer must follow all directions issued by SoundTube.
Install Instructions For:
WLL-TR-1p-II (WLL-TX1-II transmitter and WLL-RX1p-II receiver/amp).
Receiver Box Contents
1- WLL-RX1p wireless receiver/amp unit
1- Power supply
Output: 32VDC 3.75A
2- Half rack mount adapters
2- Antenna
2- Two-pin Euro-block connectors
Front
TX unit- Transmitter
-II
-II
© 2020 MSE Audio. All rights reserved.
Avis
Les produits SoundTube doit être installé par un installateur professionnel audio/contractuer.
Pour plus de sûreté et pour des performances audio optimales, l'installateur doit suivre toutes
les instructions émises par SoundTube.
Antenna (4)
Rear
TX unit- Transmitter
RX unit- Receiver/Amp
1.855.663.5600 | mseaudio.com | soundtube.com
PN INS-WLL-TR-1p-II Rev 02.04.2020
TX unit- Transmitter
Advertisement
Table of Contents
Related Manuals for SoundTube WLL-TR-1p-II
Summary of Contents for SoundTube WLL-TR-1p-II
- Page 1 SoundTube products must be installed by a professional audio installer/contractor. For safety Pour plus de sûreté et pour des performances audio optimales, l'installateur doit suivre toutes and for optimum audio performance, installer must follow all directions issued by SoundTube. les instructions émises par SoundTube.
- Page 2 WLL-TR-1p-II Install Instructions For: WLL-TR-1p-II (WLL-TX1-II transmitter and WLL-RX1p-II receiver/amp). WLL-TX1-II Install Instructions 2. Determine location for 3. Connect desired input source to 4. If desired, the variable LINE 1. Remove unit from box. placement of WLL-TX1-II. The rear panel. You may use balanced...
- Page 3 WLL-TR-1p-II Install Instructions For: WLL-TR-1p-II (WLL-TX1-II transmitter and WLL-RX1p-II receiver/amp). WLL-RX1p-II Install Instructions 2. Determine location for 1. Remove unit from box. 3. Connect 4 ohm or 8 ohm 4. If desired, a direct audio source placement of WLL-RX1p-II. The...
- Page 4 WLL-TR-1p-II Install Instructions For: WLL-TR-1p-II (WLL-TX1-II transmitter and WLL-RX1p-II receiver/amp). Transmitter Interference: If the WLL-TX1-II causes interference with other wireless devices in the area, try the following: (a) select a different channel setting on both the transmitter and receiver (step 10); (b) change RF Gain switch to Low setting (step 7); (c) alter antenna positions on both transmitter and receiver (antenna positions should match each other).
