Reynolds Building Systems Best Barns Denver Assembly Book page 9

Step 6B Assemble Side Walls for 20' Building Length
1. Select one of the 10' side walls with siding. Butt a 10' wall frame against this wall with
the 'C' marks together. Do Not nail these frames together so they can be separated later.
2. Square the wall frame. Install a full width siding panel using 6d galvanized box nails spaced
8" apart. Do Not nail along the long edge that overlaps the sided wall frame. You can nail
this edge after the wall panels are installed. This will enable you to separate the wall panels
making them easier to handle.
3. Install another full width siding panel and
a 2' wide siding panel with 'LAP' edge.
4. Repeat to apply siding to the other 10' wall frame.
Do Not Nail Along This Edge
C
C
10' Wall Panel from Step 5
LAP Edge
72" Wall Plate
48" Wall Plate
