FOOD WARMER , 4/3rd Size
Model
Voltage ~ Hz
FW-L600
120V ~ 50/60Hz
BEFORE OPERATING ANY EQUIPMENT, READ AND FAMILIARIZE YOURSELF WITH THESE USE AND SAFETY INSTRUCTIONS
Congratulations on your purchase of this WINCO® commercial equipment. WINCO takes pride in the quality of
its products. When used as intended and with proper care and maintenance, you will experience years of reliable
operation from this equipment. To ensure best results, it is important that you read and follow the instructions in this
manual carefully. It's important to save these instructions for future reference.
COMMERCIAL
Operating Instruction Manual
Power (W) Amperage
1500W
12.5A
ELECTRIC
FW-L600
Dimensions - Overall
Power Cord
Length
29-3/4"
15A
(755mm)
Plug Type
Well Opening
27"
NEMA 5-15P
(658mm)
Width
Height
14-5/8"
10-11/16"
(370mm)
(270mm)
11-13/16"
6-5/16"
(300mm)
(160mm)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Winco FW-L600
Summary of Contents for Winco FW-L600
-
Page 1: Specifications
BEFORE OPERATING ANY EQUIPMENT, READ AND FAMILIARIZE YOURSELF WITH THESE USE AND SAFETY INSTRUCTIONS Congratulations on your purchase of this WINCO® commercial equipment. WINCO takes pride in the quality of its products. When used as intended and with proper care and maintenance, you will experience years of reliable operation from this equipment. -
Page 2: Warnings
Introduction Congratulations on the purchase of your WINCO® countertop equipment. Please take the time to carefully read through this manual to ensure the machine is operated and maintained properly, to ensure the best possible performance from this product for many years. -
Page 3: Table Of Contents
This unit is intended to be used in commercial food-service operations only. It is not intended for household, industrial or laboratory use. Recommended to use with WINCO® stainless steel steam table pans, covers and adaptor bars, or high-heat poly pans and lids. -
Page 4: Important Safeguards
Important Safeguards To ensure safe installation and operation, please carefully read and understand the following statements. Unless the operator is adequately trained and supervised there is a possibility of serious injury. Owners of this equipment bear the responsibility to make certain that this equipment is used properly and safely, and to strictly follow all of the instructions contained in this manual and the requirements of local, state or federal law. - Page 5 7. The use of accessory attachments not recommended by anything other than its intended use. WINCO® may cause fire, electric shock or injury. 2. Do not touch surfaces that may be hot - be sure to always use 8. Not intended for outdoor installation.
-
Page 6: Operation
Always unplug the electrical power from the unit before cleaning. Proper cleaning instructions must be followed; otherwise, operation of the unit may be seriously impaired. Do not wash parts in an automatic dishwasher. WINCO authorized service personnel must perform any other servicing. -
Page 7: Steam Table Pan Configurations
Steam Table Pan Configuration Examples Utilize stainless steel steam table pans, insets, round adaptor plates and adaptor bars (sold separately) by WINCO® to achieve the following popular pan configurations, or customize for all of your serving needs:... -
Page 8: Features, Wiring Diagram
Model FW-L600 11-13/16" (300mm) 27" (658mm) 6-5/16" (160mm) 10-11/16" (270mm) 29-3/4" (755mm) 14-5/8" (370mm) Wiring Diagram THERMAL CONTROL SWITCH POWER SUPPLY 120V AC 50/60Hz DS (RED) HEATING GROUND HEATING ELEMENT LAMP... -
Page 9: Exploded View, Parts Listing
Exploded View Parts List model fW-l600 pARts Item# Creep-Style Thermostat FWS500-P7 Tubular Heating Element FWS600-P3 Adjustable Power Knob for Thermostat FWS600-P5 Red Power Indicator Light FWS500-P10 Rubber Feet FWS500-P59 #14 AWG Power Cord FWS600-P6 Terminal Block FW-TB... -
Page 10: Safety & Troubleshooting
DO NOT send unit to WINCO without first contacting our customer service department. See "Limited Warranty" section on page 11 for details. Troubleshooting If your WINCO appliance does not operate, please check the following prior to placing a service call. pRoblem mIGht be cAused by couRse of ActIoN Power supply Check power source &... -
Page 11: Limited Warranty
Limited Warranty WINCO® warrants to the original purchaser of new equipment that said equipment, when installed in accordance with our instructions within North America and subjected to normal use, is free from defects in material or workmanship for a period of 1 year. The labor warranty is one year from original installation or 18 months from actual factory shipment date, whichever date occurs first. - Page 12 Model: FW-L600 www.wincous.com...
