B S D - R A C I N G
1/8 4WD ELECTRIC-POWERED
WATERPROOF BUGGY
BS221T / BS221R
FEATURES:
Length:495mm
Width:305mm
Heigth:190mm
BS221T
ESC: 40A ESC
Motor: RC 550
Battery: 1800mAh NI-MH
BS221R
ESC: 45A ESC
Motor: RC 540 KV3421
Battery: 3200mAh Li-po
Instruction Manual
1/8 4WD ELECTRIC-POWERED
WATERPROOF TRUCK
BS222T / BS222R
FEATURES:
Length:488mm
Width:295mm
Heigth:185mm
BS222T
ESC: 40A ESC
Motor: RC 550
Battery: 1800mAh NI-MH
BS222R
ESC: 45A ESC
Motor: RC 540 KV3421
Battery: 3200mAh Li-po
www.bsdracing.com
20170329

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BS221T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BSD-Racing BS221T

  • Page 1 B S D - R A C I N G 1/8 4WD ELECTRIC-POWERED WATERPROOF BUGGY BS221T / BS221R FEATURES: Length:495mm Width:305mm Heigth:190mm BS221T ESC: 40A ESC Motor: RC 550 Battery: 1800mAh NI-MH BS221R ESC: 45A ESC Motor: RC 540 KV3421...
  • Page 4 TRANSMITTER SPECIFICATIONS TR TYPE: MADGEAR-TRV1 Channel: 3CH Frequency: 2.4GHz Use DC: (4.0V-8.6V); ≤110mA N.W.: 320g RX TYPE: MADGEAR-RXV1 Channel: 3CH Frequency: 2.4GHz 162mm DC: (4.0V-8.6V); ≤20mA N.W.: 8g R/F Power: <20dBm; Sensititity: 1024 Modulation: 2-FSK; Frequency Signal: FHSS Specifications: One Set(200*165*105mm) NOTE: Install the batteries in correct polarity.
  • Page 5 AUX CHANNEL(3CH) Press the CH3 button once, servo turns 90 degrees, press again, servo turns back 90 degrees. NOTE: During the binding process, the CH3 button functions as a bind button and does not provide channel 3 functionality. STEERING DUAL RATES ADJUSTMENT (ST.D/R) Adjust the dual rate for steering by turning the ST D/R knob.
